Switch & Relay & Computer ([09.2007 - ] ｴﾝｼﾞﾝ & ﾄﾗﾝｽﾐｯｼｮﾝ (0709- )URS190) Diagram Toyota LEXUS GS
- Year
- 2007 - 2011
- Sales region
- Japan
- Frame
- URS190
- ENGINE
- 1URFSE
- TRANSMISSION
- ATM
- Model
- GS460
- From
- 09.2007
- To
- 12.2011
- Vehicle Model
- GS460
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
83530
|
83530
83530-28020 Switch Assy, Oil Pressure (For Engine)[09.2007 - 04.2011] URS190 |
83530-28020 |
US $29.94 |
||
| replacements | |||||
|
83530
|
83530
83530-60020 Switch Assy, Oil Pressure (For Engine)ＹＡＺＡＫＩ→ＤＥＮＳＯ [09.2007 - 04.2011] URS190 |
83530-60020 |
from US $25.55 |
||
|
83530
|
83530
83530-0E010 Switch Assy, Oil Pressure (For Engine)[09.2007 - 04.2011] URS190 |
83530-0E010 |
from US $51.25 |
||
|
83530
|
83530
83530-60020 Switch Assy, Oil Pressure (For Engine)ＹＡＺＡＫＩ→ＤＥＮＳＯ [04.2011 -] URS190 ＹＡＺＡＫＩ |
83530-60020 |
from US $25.55 |
||
|
83531A
|
83531A
83531-50010 Switch, Oil Pressure[09.2007 - 12.2011] URS190 |
83531-50010 |
US $10.92 |
||
|
84540
|
84540
84540-71010 Switch Assy, Neutral Start[09.2007 - 12.2011] GRS19#,URS190 |
84540-71010 |
from US $112.48 |
||
|
89465
|
89465
89465-30790 Sensor, Oxygen[09.2007 - 12.2011] URS190 左側 |
89465-30790 |
US $126.67 |
||
|
89465
|
89465
89465-30800
Sensor, Oxygen
[09.2007 - 12.2011] URS190 右側 |
89465-30800 |
— | ||
|
89467B
|
89467B
89467-30030 Sensor, Air Fuel Ratio[09.2007 -] URS190 右側 |
89467-30030 |
from US $200.69 |
||
|
89467B
|
89467B
89467-30040 Sensor, Air Fuel Ratio[09.2007 -] URS190 左側 |
89467-30040 |
from US $210.89 |
||
|
89491
|
89491
89491-50041 Sensor, Engine Oil Level[09.2007 - 12.2011] URS190 |
89491-50041 |
US $106.56 |
||
|
89491A
|
89491A
89493-60010 Gasket, Engine Oil Level Sensor[09.2007 -] GRS19#,URS190 |
89493-60010 |
from US $2.24 |
||
|
89615
|
89615
89615-20090 Sensor, Knock Control[09.2007 -] URS190 |
89615-20090 |
from US $36.02 |
||
|
91511B0830
|
91511B0830
91511-B0830 Bolt Or Ring, Exhaust Pipe Front (For Front) |
91511-B0830 |
from US $0.98 |
||
|
91553A0810
|
91553A0810
91553-A0810 New Genuine Part |
91553-A0810 |
US $1.16 |
||
|
91621B0616
|
91621B0616
91621-B0616 Bolt |
91621-B0616 |
from US $0.84 |
||
|
8271530L60
|
8271530L60
82715-30L60
Bracket,wiring Harness Clamp
|
82715-30L60 |
— | ||
|
8271530L70
|
8271530L70
82715-30L70 Bracket,wiring Harness Clamp |
82715-30L70 |
US $5.39 |
||
|
8271530L80
|
8271530L80
82715-30L80 Bracket,wiring Harness Clamp |
82715-30L80 |
US $3.49 |
||
|
9011908C62
|
9011908C62
90119-08C62 New Genuine Part |
90119-08C62 |
US $1.28 |
||
|
9167180816
|
9167180816
91671-80816 Bolt (For Transmission Control Cable Bracket) |
91671-80816 |
from US $0.84 |
||
|
9167380614
|
9167380614
91673-80614 BOLT, FLANGE W/WASER |
91673-80614 |
US $0.96 |
||
