Switch & Relay & Computer ([08.2005 - ] ｴﾝｼﾞﾝ & ﾄﾗﾝｽﾐｯｼｮﾝ (0508- )) Diagram Toyota LEXUS IS
- Year
- 2005 - 2013
- Sales region
- Japan
- Frame
- GSE20
- body
- SED
- ENGINE
- 4GRFSE
- TRANSMISSION
- ATM
- Model
- IS250
- From
- 08.2005
- To
- 04.2013
- Vehicle Model
- IS250
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
83530
|
83530
83530-28020 Switch Assy, Oil Pressure (For Engine)[08.2005 - 08.2008] GSE2# |
83530-28020 |
US $33.10 |
||
| replacement | |||||
|
83530
|
83530
83530-60020 Switch Assy, Oil Pressure (For Engine)ＹＡＺＡＫＩ→ＤＥＮＳＯ [08.2005 - 08.2008] GSE2# |
83530-60020 |
US $33.10 |
||
|
83530
|
83530
83530-60020 Switch Assy, Oil Pressure (For Engine)ＹＡＺＡＫＩ→ＤＥＮＳＯ [08.2010 -] GSE2# ＹＡＺＡＫＩ |
83530-60020 |
US $33.10 |
||
|
84540
|
84540
84540-71010 Switch Assy, Neutral Start[08.2005 - 08.2008] GSE2# |
84540-71010 |
US $124.64 |
||
|
89465
|
89465
89465-30730 Sensor, Oxygen[08.2005 - 08.2008] GSE20,21 右側＆左側 |
89465-30730 |
US $154.16 |
||
|
89467B
|
89467B
89467-22050 Sensor, Air Fuel RatioAIR FUEL RATIO [08.2010 -] GSE2# |
89467-22050 |
US $209.60 |
||
|
89467B
|
89467B
89467-30010 Sensor, Air Fuel Ratio[08.2005 - 02.2008] GSE20 マーク ８９４６７−３００１０ |
89467-30010 |
US $249.60 |
||
|
89467B
|
89467B
89467-30040 Sensor, Air Fuel Ratio[02.2008 - 08.2008] GSE20 マーク ８９４６７−３００４０ |
89467-30040 |
US $254.40 |
||
|
89467C
|
89467C
89467-22030 Sensor, Air Fuel RatioAIR FUEL RATIO [08.2010 -] GSE20,21 |
89467-22030 |
US $162.36 |
||
|
89467C
|
89467C
89467-30010 Sensor, Air Fuel Ratio[08.2005 - 02.2008] GSE20 マーク ８９４６７−３００１０ |
89467-30010 |
US $249.60 |
||
|
89467C
|
89467C
89467-30030 Sensor, Air Fuel Ratio[02.2008 - 08.2008] GSE20 マーク ８９４６７−３００３０ |
89467-30030 |
US $254.40 |
||
|
89491
|
89491
89491-30060
Sensor, Engine Oil Level
[08.2005 - 08.2008] GSE20,21 |
89491-30060 |
— | ||
| replacement | |||||
|
89491
|
89491
89491-30061 Sensor, Engine Oil Level[08.2005 - 08.2008] GSE20,21 |
89491-30061 |
US $155.80 |
||
|
89491
|
89491
89491-30061 Sensor, Engine Oil Level[09.2011 -] GSE20,21 |
89491-30061 |
US $155.80 |
||
|
89491A
|
89491A
89493-60010 Gasket, Engine Oil Level Sensor[08.2005 - 08.2008] GSE2# |
89493-60010 |
US $2.51 |
||
|
89615
|
89615
89615-20090 Sensor, Knock Control[08.2005 - 08.2008] GSE2# |
89615-20090 |
from US $39.82 |
||
|
91621B0616
|
91621B0616
91621-B0616 Bolt |
91621-B0616 |
US $1.79 |
||
|
9094901B45
|
9094901B45
90949-01B45 Clamp(For Clutch Master Cylinder Tube) |
90949-01B45 |
US $3.94 |
||
|
8271522850
|
8271522850
82715-22850 Bracket,wiring Harness Clamp |
82715-22850 |
US $2.62 |
||
|
9155180830
|
9155180830
91551-80830 Bolt, Compressor, No.2 |
91551-80830 |
US $1.43 |
||
|
9165140830
|
9165140830
91651-40830 Bolt, Radiator Side Support Plate |
91651-40830 |
US $1.31 |
||
|
9167380612
|
9167380612
91673-80612 BOLT FLANGE |
91673-80612 |
US $1.08 |
||
