Heating & Air Conditioning - Control & Air Duct ([04.2009 - ] ｾﾝｻ (0904- )) Diagram Toyota LEXUS IS
- Year
- 2009 - 2014
- Sales region
- Japan
- Frame
- GSE20
- grade
- 250C
- ENGINE
- 4GRFSE
- TRANSMISSION
- ATM
- Model
- IS250
- From
- 04.2009
- To
- 08.2014
- Gear Shift Type
- 6FC
- Vehicle Model
- IS250C
Difficulties in parts search?
Parts list
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
88625K
|
88625K
88625-47021 Thermistor, Cooler No.3[04.2009 - 08.2014] GSE2# |
88625-47021 |
from US $14.68 |
||
|
88625P
|
88625P
88790-22131 Thermistor, Cooler[04.2009 - 08.2014] GSE2# |
88790-22131 |
from US $26.05 |
||
|
88669
|
88669
88669-30050
Hose, Cooler Air
[04.2009 - 08.2014] GSE2# |
88669-30050 |
— | ||
|
91551A0612
|
91551A0612
91551-A0612 New Genuine Part |
91551-A0612 |
US $1.08 |
||
|
8868853010
|
8868853010
88688-53010
Bracket, Cooler Diaphragm
|
88688-53010 |
— | ||
|
9011906782
|
9011906782
90119-06782 BOLT WWASHER |
90119-06782 |
from US $0.65 |
