Disc Wheel & Wheel Cap ([08.2005 - ] (0508- )) Diagram Toyota LEXUS IS
- Year
- 2005 - 2010
- Sales region
- Europe
- Frame
- GSE20
- grade
- LUX
- body
- SED
- ENGINE
- 4GRFSE
- TRANSMISSION
- MTM
- Model
- IS250
- From
- 09.2005
- To
- 08.2010
- Vehicle Model
- IS250
- Driver's Position
- LHD
- Fuel Induction
- D4
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
42601
|
42601
42611-53250 Wheel, DiscDISC [08.2005 - 08.2007] GSE20..LHD 18X8J,TIRE & DISC WHEEL-225/40R18+255/40R18,SUMMER TIRE,ALUMI,FR,T/P C:SEE ILLUST |
42611-53250 |
US $713.44 |
||
|
42601
|
42601
42611-53260 Wheel, DiscDISC [08.2005 - 08.2007] GSE20..LHD 18X8.5J,TIRE & DISC WHEEL-225/40R18+255/40R18,SUMMER TIRE,ALUMI,RR,T/P C:SEE ILLUS T |
42611-53260 |
US $719.26 |
||
|
42601
|
42601
42611-53270 Wheel, DiscDISC [08.2005 - 08.2008] ALE20,GSE20..LUX 16X7JJ,TYPE A:REFER ILLUST. |
42611-53270 |
US $548.91 |
||
|
42601
|
42601
42611-53280
Wheel, Disc
[08.2005 - 08.2007] ALE20,GSE20..LUX 17X8JJ,TIRE & DISC WHEEL-225/45R17+245/45R17,SUMMER TIRE,ALUMI,TYPE B:REFER ILLUST . |
42611-53280 |
— | ||
| replacement | |||||
|
42601
|
42601
42611-53361 Wheel, Disc[08.2005 - 08.2007] ALE20,GSE20..LUX 17X8JJ,TIRE & DISC WHEEL-225/45R17+245/45R17,SUMMER TIRE,ALUMI,TYPE B:REFER ILLUST . |
42611-53361 |
US $668.30 |
||
|
42601
|
42601
42611-53290
Wheel, Disc
[08.2007 - 08.2008] ALE20..SPO 17X8JJ,TYPE B:REFER ILLUST.; ALE20,GSE20..LUX 17X8JJ,TIRE & DISC WHEEL-225/45R17+245/45R17,SUMMER TIRE,ALUMI,TYPE B:REFER ILLUST .; GSE20..LHD 17X8JJ,TURKEY SPEC&TIRE & DISC WHEEL-225/45R17+245/45R17,GENERAL COUNTRIES,TYPE B |
42611-53290 |
— | ||
| replacement | |||||
|
42601
|
42601
42611-53381 Wheel, Disc[08.2007 - 08.2008] ALE20..SPO 17X8JJ,TYPE B:REFER ILLUST.; ALE20,GSE20..LUX 17X8JJ,TIRE & DISC WHEEL-225/45R17+245/45R17,SUMMER TIRE,ALUMI,TYPE B:REFER ILLUST .; GSE20..LHD 17X8JJ,TURKEY SPEC&TIRE & DISC WHEEL-225/45R17+245/45R17,GENERAL COUNTRIES,TYPE B |
42611-53381 |
US $668.30 |
||
|
42601
|
42601
42611-53310 Wheel, DiscDISC [08.2008 - 08.2009] GSE20..LHD 17X8J,TURKEY SPEC&TIRE & DISC WHEEL-225/45R17+245/45R17,GENERAL COUNTRIES,TYPE E:R EFER ILLUST. |
42611-53310 |
US $626.08 |
||
|
42601
|
42601
4261A-53060 Wheel, DiscDISC [08.2007 - 08.2008] GSE20..LHD 18X8J,RUSSIA SPEC&TIRE & DISC WHEEL-225/40R18+255/40R18,SUMMER TIRE,ALUMI,FR,T/P C :SEE ILLUST; GSE20..LHD 18X8J,MOROCCO SPEC&TIRE & DISC WHEEL-225/40R18+255/40R18,SUMMER TIRE,ALUMI,FR,T/P C:SEE ILLUST; ALE20..SPO;GSE20..LHD |
4261A-53060 |
US $748.38 |
||
|
42601
|
42601
4261A-53080 Wheel, DiscDISC [08.2007 - 08.2008] GSE20..LHD 18X8.5J,RUSSIA SPEC&TIRE & DISC WHEEL-225/40R18+255/40R18,SUMMER TIRE,ALUMI,RR,T/P C:SEE ILLUST; GSE20..LHD 18X8.5J,MOROCCO SPEC&TIRE & DISC WHEEL-225/40R18+255/40R18,SUMMER TIRE,ALUMI,RR,T/ P C:SEE ILLUST; ALE20..SPO;GSE20. |
4261A-53080 |
US $754.21 |
||
|
42601
|
42601
4261A-53160 Wheel, DiscDISC [08.2008 - 10.2008] GSE20..LHD..MTM 18X8J,RUSSIA SPEC&TIRE & DISC WHEEL-225/40R18+255/40R18,SUMMER TIRE,ALUMI,FR,T/P F :SEE ILLUST |
4261A-53160 |
US $736.74 |
||
|
42601
|
42601
4261A-53180 Wheel, DiscDISC [08.2008 - 10.2008] GSE20..LHD..MTM 18X8.5J,RUSSIA SPEC&TIRE & DISC WHEEL-225/40R18+255/40R18,SUMMER TIRE,ALUMI,RR,T/P F:SEE ILLUST |
4261A-53180 |
US $742.56 |
||
|
42601A
|
42601A
42611-30A60 Wheel, Disc (For Spare)[08.2005 - 08.2008] ALE20,GSE20 17X4T,TYPE D:REFER ILLUST. |
42611-30A60 |
US $142.69 |
||
|
42601A
|
42601A
42611-53270 Wheel, DiscDISC [07.2006 - 08.2008] GSE20..LHD 16X7JJ,TURKEY SPEC,TYPE A:REFER ILLUST.; GSE20..LHD..ATM 16X7JJ,ISRAEL SPEC,TYPE A:REFER ILLUST.; GSE20..RHD..ATM 16X7JJ,HONG KONG SPEC&SPARE TIRE-GROUND TIRE(205/55R16),TYPE A:REFER ILLUST.; GSE20..RHD..ATM 16X7JJ,SINGAPORE |
42611-53270 |
US $548.91 |
||
|
42601A
|
42601A
42611-53280
Wheel, Disc
[07.2006 - 08.2007] GSE20..LHD 17X8JJ,TURKEY SPEC&TIRE & DISC WHEEL-225/45R17+245/45R17,GENERAL COUNTRIES,TYPE B: REFER ILLUST.; GSE20..RHD..ATM 17X8JJ,HONG KONG SPEC&TIRE & DISC WHEEL-225/45R17+245/45R17,GENERAL COUNTRIES&SPAR E TIRE-GROUND(225/45R17),TY |
42611-53280 |
— | ||
| replacement | |||||
|
42601A
|
42601A
42611-53361 Wheel, Disc[07.2006 - 08.2007] GSE20..LHD 17X8JJ,TURKEY SPEC&TIRE & DISC WHEEL-225/45R17+245/45R17,GENERAL COUNTRIES,TYPE B: REFER ILLUST.; GSE20..RHD..ATM 17X8JJ,HONG KONG SPEC&TIRE & DISC WHEEL-225/45R17+245/45R17,GENERAL COUNTRIES&SPAR E TIRE-GROUND(225/45R17),TY |
42611-53361 |
US $668.30 |
||
|
42601A
|
42601A
42611-53290
Wheel, Disc
[08.2007 - 08.2008] GSE20..LHD 17X8JJ,TURKEY SPEC&TIRE & DISC WHEEL-225/45R17+245/45R17,GENERAL COUNTRIES,TYPE B: REFER ILLUST.; GSE20..RHD..ATM 17X8JJ,HONG KONG SPEC&TIRE & DISC WHEEL-225/45R17+245/45R17,GENERAL COUNTRIES&SPAR E TIRE-GROUND(225/45R17),TY |
42611-53290 |
— | ||
| replacement | |||||
|
42601A
|
42601A
42611-53381 Wheel, Disc[08.2007 - 08.2008] GSE20..LHD 17X8JJ,TURKEY SPEC&TIRE & DISC WHEEL-225/45R17+245/45R17,GENERAL COUNTRIES,TYPE B: REFER ILLUST.; GSE20..RHD..ATM 17X8JJ,HONG KONG SPEC&TIRE & DISC WHEEL-225/45R17+245/45R17,GENERAL COUNTRIES&SPAR E TIRE-GROUND(225/45R17),TY |
42611-53381 |
US $668.30 |
||
|
42601A
|
42601A
42611-53310 Wheel, DiscDISC [08.2008 - 08.2009] GSE20..LHD 17X8J,TURKEY SPEC&TIRE & DISC WHEEL-225/45R17+245/45R17,GENERAL COUNTRIES,TYPE E:R EFER ILLUST. |
42611-53310 |
US $626.08 |
||
|
42601A
|
42601A
42611-53320 Wheel, Disc (For Spare)DISC (FOR SPARE) [08.2009 - 08.2010] ALE20,GSE20 17X4T,TYPE D:REFER ILLUST. |
42611-53320 |
US $142.69 |
||
|
42601C
|
42601C
90942-01033 Nut, Hub (For Axle)[08.2005 - 08.2008] ALE20,GSE20 |
90942-01033 |
from US $2.22 |
||
|
42611G
|
42611G
90942-05028 Valve (For Tubeless Tire)[08.2005 - 08.2008] GSE20;ALE20..RHD;ALE20..LHD..LUX TYPE B:REFER ILLUST. |
90942-05028 |
from US $6.81 |
||
|
42611J
|
42611J
90942-05009 Valve (For Tubeless Tire)[08.2005 - 08.2008] ALE20,GSE20 TYPE A:REFER ILLUST. |
90942-05009 |
from US $6.99 |
||
| replacement | |||||
|
42611J
|
42611J
90080-94031 Valve (For Tubeless Tire)[08.2005 - 08.2008] ALE20,GSE20 TYPE A:REFER ILLUST. |
90080-94031 |
US $1.46 |
||
|
42611J
|
42611J
90942-05028 Valve (For Tubeless Tire)[07.2006 - 08.2008] GSE20..LHD TURKEY SPEC,TYPE B:REFER ILLUST.; GSE20..LHD..ATM ISRAEL SPEC,TYPE B:REFER ILLUST.; GSE20..LHD TURKEY SPEC&TIRE & DISC WHEEL-225/45R17+245/45R17,GENERAL COUNTRIES,TYPE B:REFER I LLUST.; GSE20..RHD..ATM HONG KONG SPEC&TIRE & |
90942-05028 |
from US $6.81 |
||
|
42611U
|
42611U
90942-05029 Cap, Tire Valve[08.2005 - 08.2008] ALE20,GSE20 |
90942-05029 |
from US $2.15 |
||
|
42611W
|
42611W
90942-05029 Cap, Tire Valve[07.2006 - 08.2008] GSE20..LHD TURKEY SPEC; GSE20..LHD..ATM ISRAEL SPEC; GSE20..LHD TURKEY SPEC&TIRE & DISC WHEEL-225/45R17+245/45R17,GENERAL COUNTRIES; GSE20..RHD..ATM HONG KONG SPEC&TIRE & DISC WHEEL-225/45R17+245/45R17,GENERAL COUNTRIES&SPARE TIRE- GRO |
90942-05029 |
from US $2.15 |
||
|
42652
|
42652
42652-53170
Tire
[08.2005 - 08.2008] ALE20,GSE20..LHD..LUX 205/55R16 *B/S; GSE20..LHD 205/55R16 *B/S,TIRE & DISC WHEEL-225/45R17+245/45R17,GENERAL COUNTRIES |
42652-53170 |
— | ||
|
42652
|
42652
42652-53210
Tire
[08.2005 - 08.2008] ALE20,GSE20..LHD..LUX 225/45R17 90W *D/L,TIRE & DISC WHEEL-225/45R17+245/45R17,SUMMER TIRE,ALUMI |
42652-53210 |
— | ||
|
42652
|
42652
42652-53230
Tire
[08.2005 - 08.2008] ALE20,GSE20..LHD..LUX 225/45R17 90W *B/S,TIRE & DISC WHEEL-225/45R17+245/45R17,SUMMER TIRE,ALUMI |
42652-53230 |
— | ||
|
42652
|
42652
42652-53250
Tire
[08.2005 - 08.2008] ALE20,GSE20..LHD..LUX 245/45R17 95W *D/L,TIRE & DISC WHEEL-225/45R17+245/45R17,SUMMER TIRE,ALUMI |
42652-53250 |
— | ||
|
42652
|
42652
42652-53270
Tire
[08.2005 - 08.2008] ALE20,GSE20..LHD..LUX 245/45R17 95W *B/S,TIRE & DISC WHEEL-225/45R17+245/45R17,SUMMER TIRE,ALUMI |
42652-53270 |
— | ||
|
42652
|
42652
42652-53330
Tire
[08.2005 - 08.2008] GSE20..LHD 225/40R18 *D/L,TIRE & DISC WHEEL-225/40R18+255/40R18,SUMMER TIRE,ALUMI,FRONT |
42652-53330 |
— | ||
|
42652
|
42652
42652-53350
Tire
[08.2005 - 08.2008] GSE20..LHD 255/40R18 *D/L,TIRE & DISC WHEEL-225/40R18+255/40R18,SUMMER TIRE,ALUMI,REAR |
42652-53350 |
— | ||
|
42652
|
42652
42652-53380
Tire
[08.2005 - 08.2008] ALE20,GSE20..LHD..LUX 225/45R17 *T/Y,TIRE & DISC WHEEL-225/45R17+245/45R17,SUMMER TIRE,ALUMI |
42652-53380 |
— | ||
|
42652
|
42652
42652-53400
Tire
[08.2005 - 08.2008] ALE20,GSE20..LHD..LUX 245/45R17 *T/Y,TIRE & DISC WHEEL-225/45R17+245/45R17,SUMMER TIRE,ALUMI |
42652-53400 |
— | ||
|
42652
|
42652
42652-53420
Tire
[07.2006 - 08.2008] GSE20..LHD 225/45R17 *B/S,TURKEY SPEC&TIRE & DISC WHEEL-225/45R17+245/45R17,GENERAL COUNTRIES; GSE20..LHD..ATM 225/45R17 *B/S,ISRAEL SPEC&TIRE & DISC WHEEL-225/45R17+245/45R17,GENERAL COUNTRIES |
42652-53420 |
— | ||
| replacement | |||||
|
42652
|
42652
42652-53421
Tire
[07.2006 - 08.2008] GSE20..LHD 225/45R17 *B/S,TURKEY SPEC&TIRE & DISC WHEEL-225/45R17+245/45R17,GENERAL COUNTRIES; GSE20..LHD..ATM 225/45R17 *B/S,ISRAEL SPEC&TIRE & DISC WHEEL-225/45R17+245/45R17,GENERAL COUNTRIES |
42652-53421 |
— | ||
|
42652
|
42652
42652-53440
Tire
[07.2006 - 08.2008] GSE20..LHD 245/45R17 *B/S,TURKEY SPEC&TIRE & DISC WHEEL-225/45R17+245/45R17,GENERAL COUNTRIES; GSE20..LHD..ATM 245/45R17 *B/S,ISRAEL SPEC&TIRE & DISC WHEEL-225/45R17+245/45R17,GENERAL COUNTRIES |
42652-53440 |
— | ||
| replacement | |||||
|
42652
|
42652
42652-53441
Tire
[07.2006 - 08.2008] GSE20..LHD 245/45R17 *B/S,TURKEY SPEC&TIRE & DISC WHEEL-225/45R17+245/45R17,GENERAL COUNTRIES; GSE20..LHD..ATM 245/45R17 *B/S,ISRAEL SPEC&TIRE & DISC WHEEL-225/45R17+245/45R17,GENERAL COUNTRIES |
42652-53441 |
— | ||
|
42652
|
42652
42652-53570
Tire
[05.2006 - 12.2006] ALE20..LHD..SPO 225/40R18 *B/S,FRONT RH; GSE20..LHD 225/40R18 *B/S,TIRE & DISC WHEEL-225/40R18+255/40R18,SUMMER TIRE,ALUMI,FRONT RH |
42652-53570 |
— | ||
| replacement | |||||
|
42652
|
42652
42652-53571
Tire
[05.2006 - 12.2006] ALE20..LHD..SPO 225/40R18 *B/S,FRONT RH; GSE20..LHD 225/40R18 *B/S,TIRE & DISC WHEEL-225/40R18+255/40R18,SUMMER TIRE,ALUMI,FRONT RH |
42652-53571 |
— | ||
|
42652
|
42652
42652-53571
Tire
[01.2007 - 08.2008] GSE20..LHD 225/40R18 *B/S,TIRE & DISC WHEEL-225/40R18+255/40R18,SUMMER TIRE,ALUMI |
42652-53571 |
— | ||
|
42652
|
42652
42652-53580
Tire
[05.2006 - 01.2007] ALE20..LHD..SPO 225/40R18 *B/S,FRONT LH; GSE20..LHD 225/40R18 *B/S,TIRE & DISC WHEEL-225/40R18+255/40R18,SUMMER TIRE,ALUMI,FRONT LH |
42652-53580 |
— | ||
|
42652
|
42652
42652-53600
Tire
[05.2006 - 12.2006] ALE20..LHD..SPO 255/40R18 *B/S,REAR; GSE20..LHD 255/40R18 *B/S,TIRE & DISC WHEEL-225/40R18+255/40R18,SUMMER TIRE,ALUMI,REAR |
42652-53600 |
— | ||
| replacement | |||||
|
42652
|
42652
42652-53601
Tire
[05.2006 - 12.2006] ALE20..LHD..SPO 255/40R18 *B/S,REAR; GSE20..LHD 255/40R18 *B/S,TIRE & DISC WHEEL-225/40R18+255/40R18,SUMMER TIRE,ALUMI,REAR |
42652-53601 |
— | ||
|
42652
|
42652
42652-53601
Tire
[01.2007 - 08.2008] GSE20..LHD 255/40R18 *B/S,TIRE & DISC WHEEL-225/40R18+255/40R18,SUMMER TIRE,ALUMI |
42652-53601 |
— | ||
|
42652A
|
42652A
42652-05250
Tire (For Spare)
[08.2005 - 08.2008] ALE20,GSE20..LUX T125/70D17,MICHELIN; GSE20..LHD T125/70D17,MICHELIN,TIRE & DISC WHEEL-225/45R17+245/45R17,GENERAL COUNTRIES; GSE20..RHD T125/70D17,MICHELIN,SPARE TIRE-GROUND TIRE(205/55R16); GSE20..RHD T125/70D17,MICHELIN,TIRE & DISC |
42652-05250 |
— | ||
|
42652A
|
42652A
42652-53130
Tire (For Spare)
[08.2005 - 08.2008] GSE20..LHD T145/70D17,TIRE & DISC WHEEL-225/40R18+255/40R18,SUMMER TIRE,ALUMI |
42652-53130 |
— | ||
|
42652A
|
42652A
42652-53170
Tire
[07.2006 - 08.2008] GSE20..LHD 205/55R16 *B/S,TURKEY SPEC; GSE20..LHD..ATM 205/55R16 *B/S,ISRAEL SPEC |
42652-53170 |
— | ||
|
42652A
|
42652A
42652-53420
Tire
[07.2006 - 08.2008] GSE20..LHD 225/45R17 *B/S,TURKEY SPEC&TIRE & DISC WHEEL-225/45R17+245/45R17,GENERAL COUNTRIES; GSE20..LHD..ATM 225/45R17 *B/S,ISRAEL SPEC&TIRE & DISC WHEEL-225/45R17+245/45R17,GENERAL COUNTRIES |
42652-53420 |
— | ||
| replacement | |||||
|
42652A
|
42652A
42652-53421
Tire
[07.2006 - 08.2008] GSE20..LHD 225/45R17 *B/S,TURKEY SPEC&TIRE & DISC WHEEL-225/45R17+245/45R17,GENERAL COUNTRIES; GSE20..LHD..ATM 225/45R17 *B/S,ISRAEL SPEC&TIRE & DISC WHEEL-225/45R17+245/45R17,GENERAL COUNTRIES |
42652-53421 |
— | ||
|
42652A
|
42652A
4265A-0F020
Tire (For Spare)
[08.2009 - 08.2010] ALE20,GSE20..RHD T145/70D17,*B/S,CYPRUS SPEC&TIRE & DISC WHEEL-225/40R18+255/40R18,SUMMER TIRE,ALUM I&SPARE TIRE-TEMPORARY(T145/70D17); ALE20,GSE20..LHD T145/70D17,*B/S,TIRE & DISC WHEEL-225/40R18+255/40R18,SUMMER TIRE,ALUMI&SPARE TIRE |
4265A-0F020 |
— | ||
