Rear Axle Shaft & Hub ([08.2005 - ] (0508- )) Diagram Toyota LEXUS IS
- Year
- 2005 - 2013
- Sales region
- U.S.A.
- Frame
- GSE20
- body
- SED
- ENGINE
- 4GRFSE
- TRANSMISSION
- ATM
- Model
- IS250
- From
- 08.2005
- To
- 04.2013
- Vehicle Model
- IS250
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
42311N
|
42311N
90177-26001 Nut (For Rear Axle Shaft Rh)[08.2005 - 08.2008] GSE2# |
90177-26001 |
from US $2.72 |
||
|
42311U
|
42311U
90942-02070
Bolt, Hub
[08.2005 - 08.2008] GSE2# |
90942-02070 |
— | ||
| replacements | |||||
|
42311U
|
42311U
90942-02049 Bolt, Hub[08.2005 - 08.2008] GSE2# |
90942-02049 |
US $4.30 |
||
|
42311U
|
42311U
90942-02082 Bolt, Hub[08.2005 - 08.2008] GSE2# |
90942-02082 |
from US $2.26 |
||
|
42312B
|
42312B
90177-26001 Nut (For Rear Axle Shaft Rh)[08.2005 - 08.2008] GSE2# |
90177-26001 |
from US $2.72 |
||
|
42312E
|
42312E
90942-02070
Bolt, Hub
[08.2005 - 08.2008] GSE2# |
90942-02070 |
— | ||
| replacements | |||||
|
42312E
|
42312E
90942-02049 Bolt, Hub[08.2005 - 08.2008] GSE2# |
90942-02049 |
US $4.30 |
||
|
42312E
|
42312E
90942-02082 Bolt, Hub[08.2005 - 08.2008] GSE2# |
90942-02082 |
from US $2.26 |
||
|
42330
|
42330
42330-22090 Shaft Assy, Rear Drive, Rh[08.2005 - 08.2008] GSE20 |
42330-22090 |
US $710.53 |
||
| replacement | |||||
|
42330
|
42330
42330-22091 Shaft Assy, Rear Drive, Rh[08.2005 - 08.2008] GSE20 |
42330-22091 |
from US $632.51 |
||
|
42330
|
42330
42330-22091 Shaft Assy, Rear Drive, Rh[09.2010 -] GSE20,25 |
42330-22091 |
from US $632.51 |
||
|
42330G
|
42330G
90311-43009 Seal, Oil (For Rear Differential Side Gear Shaft)[08.2005 - 08.2008] GSE20 |
90311-43009 |
from US $9.68 |
||
|
42340B
|
42340B
42340-22180 Shaft Assy, Rear Drive, Lh[08.2005 - 08.2008] GSE20 |
42340-22180 |
US $693.06 |
||
| replacement | |||||
|
42340B
|
42340B
42340-22181 Shaft Assy, Rear Drive, Lh[08.2005 - 08.2008] GSE20 |
42340-22181 |
from US $573.65 |
||
|
42340B
|
42340B
42340-22181 Shaft Assy, Rear Drive, Lh[09.2010 -] GSE20,25 |
42340-22181 |
from US $573.65 |
||
|
42340D
|
42340D
90311-43009 Seal, Oil (For Rear Differential Side Gear Shaft)[08.2005 - 08.2008] GSE20 |
90311-43009 |
from US $9.68 |
||
|
42360L
|
42360L
90521-34003 Ring, Hole Snap (For Diff Side Gear Intermeddiate Shaft)[08.2005 - 08.2008] GSE20,21 |
90521-34003 |
from US $1.75 |
||
|
42360M
|
42360M
90521-34003 Ring, Hole Snap (For Diff Side Gear Intermeddiate Shaft)[08.2005 - 08.2008] GSE20,21 |
90521-34003 |
from US $1.75 |
||
|
42431
|
42431
42431-30280 Disc, Rear[08.2005 - 08.2008] GSE20,25 |
42431-30280 |
from US $147.60 |
||
|
42431
|
42431
42431-30290 Disc, Rear[08.2010 - 04.2013] GSE21,26; GSE20 SUSPENSION-SPORTS |
42431-30290 |
from US $224 |
||
|
42450A
|
42450A
42410-30020
Hub & Bearing Assy, Rear Axle
[08.2005 - 08.2008] GSE2# |
42410-30020 |
— | ||
| replacement | |||||
|
42450A
|
42450A
42410-30021 Hub & Bearing Assy, Rear Axle[08.2005 - 08.2008] GSE2# |
42410-30021 |
from US $181.98 |
||
|
42450B
|
42450B
42410-30020
Hub & Bearing Assy, Rear Axle
[08.2005 - 08.2008] GSE2# |
42410-30020 |
— | ||
| replacement | |||||
|
42450B
|
42450B
42410-30021 Hub & Bearing Assy, Rear Axle[08.2005 - 08.2008] GSE2# |
42410-30021 |
from US $181.98 |
||
|
42452A
|
42452A
42451-30020 Deflecter, Rear Wheel Bearing Dust, No.2[08.2005 - 08.2008] GSE2# |
42451-30020 |
from US $15.88 |
||
|
42452B
|
42452B
42451-30020 Deflecter, Rear Wheel Bearing Dust, No.2[08.2005 - 08.2008] GSE2# |
42451-30020 |
from US $15.88 |
||
|
42491
|
42491
47491-50010 Plug, Shoe Adjusting Hole (For Parking Brake)[08.2005 - 08.2008] GSE2# |
47491-50010 |
from US $0.86 |
||
