Armrest & Visor ([04.2009 - ] ARMREST (0904- )GCC) Diagram Toyota LEXUS IS
- Year
- 2010 - 2015
- Sales region
- General
- Frame
- GSE20
- grade
- 250C
- ENGINE
- 4GRFSE
- TRANSMISSION
- ATM
- DESTINATION
- GCC
- Model
- IS250
- From
- 08.2010
- To
- 07.2015
- Gear Shift Type
- 6FC
- Vehicle Model
- IS250C
- Driver's Position
- LHD
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
74230A
|
74230A
74230-53390-B0
Panel Assy, Front Door Armrest Base, Rh
[08.2010 - 07.2015] GSE20 POWER WINDOW-W(WOOD BASE) & PASSENGER=AUTO DOWN ONLY,GRAY,TRIM01,11,21,34,37,41 |
74230-53390-B0 |
— | ||
|
74230A
|
74230A
74230-53390-E0
Panel Assy, Front Door Armrest Base, Rh
[08.2010 - 07.2015] GSE20 POWER WINDOW-W(WOOD BASE) & PASSENGER=AUTO DOWN ONLY,LT.BROWN,TRIM00,10,20,33,36,4 0 |
74230-53390-E0 |
— | ||
|
74230A
|
74230A
74230-53390-E1
Panel Assy, Front Door Armrest Base, Rh
[08.2010 - 07.2015] GSE20 POWER WINDOW-W(WOOD BASE) & PASSENGER=AUTO DOWN ONLY,DK.BROWN,TRIM06,12,22,35,38,4 2 |
74230-53390-E1 |
— | ||
|
74230A
|
74230A
74231-53411
Panel Assy, Front Door Armrest Base, Rh
[08.2010 - 07.2015] GSE20; GSE22..GCC POWER WINDOW-PASSENGER=AUTO UP/DOWN |
74231-53411 |
— | ||
|
74240A
|
74240A
74232-53421
Panel Assy, Front Door Armrest Base, Lh
[08.2010 - 07.2015] GSE20; GSE22..GCC POWER WINDOW-PASSENGER=AUTO UP/DOWN; GSE20 POWER WINDOW-W(WOOD BASE) & PASSENGER=AUTO DOWN ONLY |
74232-53421 |
— | ||
|
74240A
|
74240A
74240-53400-B0
Panel Assy, Front Door Armrest Base, Lh
[08.2010 - 07.2015] GSE20 POWER WINDOW-W(WOOD BASE) & PASSENGER=AUTO DOWN ONLY,GRAY,TRIM01,11,21,34,37,41 |
74240-53400-B0 |
— | ||
|
74240A
|
74240A
74240-53400-E0
Panel Assy, Front Door Armrest Base, Lh
[08.2010 - 07.2015] GSE20 POWER WINDOW-W(WOOD BASE) & PASSENGER=AUTO DOWN ONLY,LT.BROWN,TRIM00,10,20,33,36,4 0 |
74240-53400-E0 |
— | ||
|
74240A
|
74240A
74240-53400-E1
Panel Assy, Front Door Armrest Base, Lh
[08.2010 - 07.2015] GSE20 POWER WINDOW-W(WOOD BASE) & PASSENGER=AUTO DOWN ONLY,DK.BROWN,TRIM06,12,22,35,38,4 2 |
74240-53400-E1 |
— | ||
|
74635A
|
74635A
90467-10203 Direct[04.2009 -] GSE20;GSE22..GEN; GSE22..GCC POWER WINDOW-PASSENGER=AUTO UP/DOWN |
90467-10203 |
from US $0.64 |
||
|
74635A
|
74635A
90467-12080 Clip(For Panel, Instrument Cluster Finish)[08.2010 -] GSE20 POWER WINDOW-W(WOOD BASE) & PASSENGER=AUTO DOWN ONLY |
90467-12080 |
from US $0.74 |
