Center Support & Planetary Sun Gear (Atm) ([04.2009 - ] A960E (0904- )6FC) Diagram Toyota LEXUS IS
- Year
- 2009 - 2014
- Sales region
- Europe
- Frame
- GSE20
- grade
- 250C
- ENGINE
- 4GRFSE
- TRANSMISSION
- ATM
- Model
- IS250
- From
- 04.2009
- To
- 11.2014
- Gear Shift Type
- 6FC
- Vehicle Model
- IS250C
- Driver's Position
- RHD
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
35045
|
35045
35045-22010 Spring Sub-Assy, Brake Piston Return,no.2[04.2009 - 08.2010] GSE20..6FC |
35045-22010 |
US $13.98 |
||
| replacement | |||||
|
35045
|
35045
35045-22H00 Spring Sub-Assy, Brake Piston Return,no.2[04.2009 - 08.2010] GSE20..6FC |
35045-22H00 |
US $40.77 |
||
|
35045
|
35045
35045-22020 Spring Sub-Assy, Brake Piston Return,no.2[08.2010 -] GSE20 |
35045-22020 |
US $10.48 |
||
|
35046
|
35046
35046-22010 Spring Sub-Assy, Brake Piston Return, No.3[04.2009 -] GSE20..6FC |
35046-22010 |
US $23.73 |
||
|
35066
|
35066
35066-22030 Disc Set, 2Nd Brake[04.2009 -] GSE20..6FC |
35066-22030 |
US $39.49 |
||
|
35608J
|
35608J
35608-22020 Spring Sub-Assy, Brake Piston Return[04.2009 -] GSE20..6FC |
35608-22020 |
US $12.52 |
||
|
35608K
|
35608K
90520-99098 Ring, Snap (For Brake Piston Return Spring)[04.2009 -] GSE20..6FC |
90520-99098 |
US $2.48 |
||
|
35616E
|
35616E
35616-22010 Washer,clutch Drum Thrust[04.2009 -] GSE20..6FC |
35616-22010 |
US $11.50 |
||
|
35621V
|
35621V
35621-22020 Piston, Brake, No.1[04.2009 -] GSE20..6FC |
35621-22020 |
US $29.85 |
||
|
35622G
|
35622G
35622-22020 Piston, Brake, No.2[04.2009 - 08.2010] GSE20..6FC |
35622-22020 |
US $40.48 |
||
| replacement | |||||
|
35622G
|
35622G
35045-22H00 Spring Sub-Assy, Brake Piston Return,no.2[04.2009 - 08.2010] GSE20..6FC |
35045-22H00 |
US $40.77 |
||
|
35622G
|
35622G
35622-22030 Piston, Brake, No.2[08.2010 -] GSE20 |
35622-22030 |
US $30.58 |
||
|
35622H
|
35622H
90301-99123 Ring, O (For Front Oil Pump Body)[04.2009 -] GSE20..6FC OUTER |
90301-99123 |
from US $2.80 |
||
|
35622H
|
35622H
90301-99155 Ring, O (For Brake Piston No.2)[04.2009 -] GSE20..6FC INNER |
90301-99155 |
US $2.62 |
||
|
35624
|
35624
35624-22030 Piston, 2Nd Brake[04.2009 -] GSE20..6FC |
35624-22030 |
US $32.18 |
||
|
35624A
|
35624A
90301-99113 Ring, O(For 2Nd Coast & Overdrive)[04.2009 -] GSE20..6FC OUTER |
90301-99113 |
US $2.62 |
||
|
35624A
|
35624A
90301-99123 Ring, O (For Front Oil Pump Body)[04.2009 -] GSE20..6FC INNER |
90301-99123 |
from US $2.80 |
||
|
35624D
|
35624D
90301-99085 Ring, O (For Brake Piston No.2)[04.2009 -] GSE20..6FC INNER |
90301-99085 |
US $1.16 |
||
|
35624D
|
35624D
90301-99143 Ring, O (For Brake Piston No.4)[04.2009 -] GSE20..6FC OUTER |
90301-99143 |
US $2.62 |
||
|
35624H
|
35624H
90520-99098 Ring, Snap (For Brake Piston Return Spring)[04.2009 -] GSE20..6FC |
90520-99098 |
US $2.48 |
||
|
35624J
|
35624J
90521-99132 Ring, Hole Snap (For 2Nd Brake Piston)[04.2009 -] GSE20..6FC |
90521-99132 |
US $2.48 |
||
|
35639B
|
35639B
35639-60010 Spring, Brake Plate Stopper[04.2009 -] GSE20..6FC |
35639-60010 |
US $28.10 |
||
|
35664
|
35664
35664-22010 Cylinder, 2Nd Brake[04.2009 -] GSE20..6FC |
35664-22010 |
US $49.36 |
||
|
35676B
|
35676B
35676-22040 Flange, Brake, No.1[04.2009 -] GSE20..6FC T=2.0,MARK 0 |
35676-22040 |
US $23.15 |
||
|
35676B
|
35676B
35676-22050 Flange, Brake, No.1[04.2009 -] GSE20..6FC T=2.2,MARK 1 |
35676-22050 |
US $23.15 |
||
|
35676B
|
35676B
35676-22060 Flange, Brake, No.1[04.2009 -] GSE20..6FC T=2.4,MARK 2 |
35676-22060 |
US $23.15 |
||
|
35676B
|
35676B
35676-22070 Flange, Brake, No.1[04.2009 -] GSE20..6FC T=2.6,MARK 3 |
35676-22070 |
US $23.15 |
||
|
35678B
|
35678B
35678-22010 Flange, Brake, No.2[04.2009 -] GSE20..6FC T=4.6,NO.1 |
35678-22010 |
US $13.25 |
||
|
35678B
|
35678B
35678-22020 Flange, Brake, No.2[04.2009 -] GSE20..6FC T=2.0,NO.2 |
35678-22020 |
US $13.25 |
||
|
35678B
|
35678B
35678-22030 Flange, Brake, No.2[04.2009 -] GSE20..6FC T=2.1,NO.2 |
35678-22030 |
US $13.25 |
||
|
35678B
|
35678B
35678-22040 Flange, Brake, No.2[04.2009 -] GSE20..6FC T=2.2,NO.2 |
35678-22040 |
US $13.25 |
||
|
35678B
|
35678B
35678-22050 Flange, Brake, No.2[04.2009 -] GSE20..6FC T=2.3,NO.2 |
35678-22050 |
US $13.25 |
||
|
35678B
|
35678B
35678-22060 Flange, Brake, No.2[04.2009 -] GSE20..6FC T=2.4,NO.2 |
35678-22060 |
US $13.25 |
||
|
35678B
|
35678B
35678-22070 Flange, Brake, No.2[04.2009 -] GSE20..6FC T=2.5,NO.2 |
35678-22070 |
US $13.25 |
||
|
35678B
|
35678B
35678-22080 Flange, Brake, No.2[04.2009 -] GSE20..6FC T=2.6,NO.2 |
35678-22080 |
US $13.25 |
||
|
35678B
|
35678B
35678-22090 Flange, Brake, No.2[04.2009 -] GSE20..6FC T=2.7,NO.2 |
35678-22090 |
US $13.25 |
||
|
35678C
|
35678C
90520-99097 Ring, Snap (For Brake No.2)[04.2009 -] GSE20..6FC |
90520-99097 |
US $2.48 |
||
|
35679B
|
35679B
35679-22010 Flange, Brake, No.3[04.2009 -] GSE20..6FC |
35679-22010 |
from US $12.81 |
||
|
35679C
|
35679C
90520-99099 Ring, Snap (For Brake No.3)[04.2009 -] GSE20..6FC |
90520-99099 |
US $2.48 |
||
|
35681A
|
35681A
35681-22010 Disc, Brake, No.1[04.2009 -] GSE20..6FC |
35681-22010 |
from US $8.06 |
||
|
35682A
|
35682A
35682-22010 Disc, Brake, No.2[04.2009 -] GSE20..6FC |
35682-22010 |
from US $17.16 |
||
|
35691
|
35691
35691-22020 Plate, Brake, No.1[04.2009 -] GSE20..6FC |
35691-22020 |
US $9.17 |
||
|
35692A
|
35692A
35692-22010 Plate, Brake, No.2[04.2009 -] GSE20..6FC |
35692-22010 |
US $7.72 |
||
|
35698
|
35698
35698-22010 Cylinder, Brake, No.1[04.2009 -] GSE20..6FC |
35698-22010 |
US $18.78 |
||
|
35699
|
35699
35699-22010 Cylinder, Brake, No.2[04.2009 -] GSE20..6FC |
35699-22010 |
US $24.17 |
||
|
35707C
|
35707C
35707-22020 Race Sub-Assy, 1 Way Clutch, Inner[04.2009 -] GSE20..6FC |
35707-22020 |
US $43.24 |
||
|
35780B
|
35780B
35780-22010 Clutch Assy, 1 Way N0.2[04.2009 -] GSE20..6FC |
35780-22010 |
US $243.15 |
||
|
35790
|
35790
35790-22050 Clutch Assy, 1 Way[04.2009 -] GSE20..6FC |
35790-22050 |
US $103.38 |
||
