Clutch & Release Fork ([07.2001 - ] (0107- )MTM) Diagram Toyota LEXUS IS
- Year
- 2001 - 2005
- Sales region
- U.S.A.
- Frame
- JCE10
- body
- SED
- ENGINE
- 2JZGE
- TRANSMISSION
- MTM
- Model
- IS300
- From
- 07.2001
- To
- 07.2005
- Vehicle Model
- IS300
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
31126
|
31126
31126-22050 Boot, Clutch Release Fork[07.2001 - 07.2005] JCE10..MTM |
31126-22050 |
US $15.81 |
||
|
31204
|
31204
31204-22050 Fork Sub-Assy, Clutch Release[07.2001 - 07.2005] JCE10..MTM |
31204-22050 |
from US $46.21 |
||
|
31210
|
31210
31210-30261 Cover Assy, Clutch[07.2001 - 07.2004] JCE10..MTM |
31210-30261 |
US $214.03 |
||
| replacement | |||||
|
31210
|
31210
31210-53020 Cover Assy, Clutch[07.2001 - 07.2004] JCE10..MTM |
31210-53020 |
US $246.06 |
||
|
31210
|
31210
31210-30262 Cover Assy, Clutch[07.2004 -] JCE10..MTM |
31210-30262 |
US $214.03 |
||
| replacement | |||||
|
31210
|
31210
31210-53020 Cover Assy, Clutch[07.2004 -] JCE10..MTM |
31210-53020 |
US $246.06 |
||
|
31230
|
31230
31230-22100 Bearing Assy, Clutch Release[07.2001 - 07.2005] JCE10..MTM |
31230-22100 |
US $29.56 |
||
| replacement | |||||
|
31230
|
31230
31230-22101 Bearing Assy, Clutch Release[07.2001 - 07.2005] JCE10..MTM |
31230-22101 |
from US $35.57 |
||
|
31232A
|
31232A
31232-22020 Clip, Release Bearing Hub[07.2001 - 07.2005] JCE10..MTM TYPE A:REFER TO ILLUSTRATION |
31232-22020 |
US $3.32 |
||
|
31236B
|
31236B
31236-14010 Support, Release Fork[07.2001 - 07.2005] JCE10..MTM |
31236-14010 |
US $11.36 |
||
|
31250
|
31250
31250-53020 Disc Assy, Clutch[07.2001 - 11.2003] JCE10..MTM |
31250-53020 |
US $176.18 |
||
| replacement | |||||
|
31250
|
31250
31250-53021 Disc Assy, Clutch[07.2001 - 11.2003] JCE10..MTM |
31250-53021 |
from US $136.71 |
||
|
31250
|
31250
31250-53021 Disc Assy, Clutch[11.2003 -] JCE10..MTM |
31250-53021 |
from US $136.71 |
||
|
33311W
|
33311W
90363-12002
Bearing (For Input Shaft)
[07.2001 -] JCE10..MTM |
90363-12002 |
— | ||
| replacement | |||||
|
33311W
|
33311W
90363-12024 Bearing, Radial Ball[07.2001 -] JCE10..MTM |
90363-12024 |
from US $5.91 |
||
|
9011908026
|
9011908026
90119-08026
Bolt(For Transmission Input Damper Cover & Flywheel)
|
90119-08026 |
— | ||
| replacement | |||||
|
9011908026
|
9011908026
90119-08079 Bolt(For Transmission Input Damper Cover & Flywheel) |
90119-08079 |
from US $0.66 |
||
