Switch & Relay & Computer ([03.2017 - ] ｴﾝｼﾞﾝ & ﾄﾗﾝｽﾐｯｼｮﾝ (1703- )URZ100) Diagram Toyota LEXUS LC
- Year
- 2017 - 2018
- Sales region
- Japan
- Frame
- URZ100
- ENGINE
- 2URGSE
- TRANSMISSION
- ATM
- Model
- LC500
- From
- 03.2017
- Gear Shift Type
- 10FC
- Vehicle Model
- LC500
- Fuel Induction
- D4
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
83530
|
83530
83530-28020 Switch Assy, Oil Pressure (For Engine)[01.2017 -] GWZ100,URZ100 ＤＥＮＳＯ |
83530-28020 |
from US $23.56 |
||
| replacement | |||||
|
83530
|
83530
83530-60020 Switch Assy, Oil Pressure (For Engine)ＹＡＺＡＫＩ→ＤＥＮＳＯ [01.2017 -] GWZ100,URZ100 ＤＥＮＳＯ |
83530-60020 |
from US $23.22 |
||
|
83530
|
83530
83530-60020 Switch Assy, Oil Pressure (For Engine)ＹＡＺＡＫＩ→ＤＥＮＳＯ [01.2017 -] GWZ100,URZ100 ＹＡＺＡＫＩ |
83530-60020 |
from US $23.22 |
||
|
89429
|
89429
89429-53010 Sensor, Oil Temperature[03.2017 -] URZ100 |
89429-53010 |
from US $57.12 |
||
|
89465
|
89465
89465-11010 Sensor, Oxygen[03.2017 -] URZ100 リヤ 左側 |
89465-11010 |
US $85.90 |
||
|
89465
|
89465
89465-11020 Sensor, Oxygen[03.2017 -] URZ100 リヤ 右側 |
89465-11020 |
US $85.90 |
||
|
89467B
|
89467B
89467-11050 Sensor, Air Fuel Ratio[03.2017 -] URZ100 ＦＲ ＲＨ |
89467-11050 |
from US $132.50 |
||
|
89467B
|
89467B
89467-24010 Sensor, Air Fuel Ratio[03.2017 -] URZ100 ＦＲ ＬＨ |
89467-24010 |
US $149.91 |
||
|
89491
|
89491
89491-24020 Sensor, Engine Oil Level[03.2017 -] URZ100 |
89491-24020 |
US $96.10 |
||
|
89615
|
89615
89615-20090 Sensor, Knock Control[03.2017 -] URZ100 |
89615-20090 |
from US $39.82 |
||
|
91511B0830
|
91511B0830
91511-B0830 Bolt Or Ring, Exhaust Pipe Front (For Front) |
91511-B0830 |
from US $0.80 |
||
|
91621B0616
|
91621B0616
91621-B0616 Bolt |
91621-B0616 |
from US $0.76 |
||
|
8271530L60
|
8271530L60
82715-30L60
Bracket,wiring Harness Clamp
|
82715-30L60 |
— | ||
|
8271511490
|
8271511490
82715-11490 Bracket,wiring Harness Clamp |
82715-11490 |
US $5.10 |
||
|
8271524380
|
8271524380
82715-24380 Bracket,wiring Harness Clamp |
82715-24380 |
US $3.20 |
||
|
9043014011
|
9043014011
90430-14011 Gasket, Straight Screw Plug No.1(For Cylinder Block) |
90430-14011 |
US $0.90 |
||
|
9167180816
|
9167180816
91671-80816 Bolt (For Transmission Control Cable Bracket) |
91671-80816 |
from US $0.76 |
||
|
9167380614
|
9167380614
91673-80614 BOLT, FLANGE W/WASER |
91673-80614 |
US $1.08 |
||
