Electronic Modulated Suspension ([10.1994 - ] (9410- )) Diagram Toyota LEXUS LS
- Year
- 1997 - 2000
- Sales region
- U.S.A.
- Frame
- UCF20
- ENGINE
- 1UZFE
- DESTINATION
- USA
- Model
- LS400
- From
- 07.1997
- To
- 08.2000
- Gear Shift Type
- 5FC
- Vehicle Model
- LS400
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
89191A
|
89191A
89191-50010 Sensor, Acceleration[10.1994 -] UCF20..USA |
89191-50010 |
US $382.93 |
||
|
89291
|
89291
89291-50050 Actuator, Suspension Control, Front[10.1994 -] UCF20..USA |
89291-50050 |
US $170.35 |
||
|
89293
|
89293
89293-50080 Computer, Suspension Control[07.1997 - 08.1998] UCF20..USA |
89293-50080 |
US $1,994.72 |
||
|
89293
|
89293
89293-50090
Computer, Suspension Control
[08.1998 -] UCF20..USA |
89293-50090 |
— | ||
|
89293A
|
89293A
90987-02006 Relay[10.1994 -] UCF20..USA |
90987-02006 |
from US $27.65 |
||
|
89405
|
89405
89405-50040 Sensor Sub-Assy, Height Control, Front[10.1994 -] UCF20..USA RH |
89405-50040 |
US $545.13 |
||
|
89405
|
89405
89406-50040
Sensor Sub-Assy, Height Control, Front
[10.1994 -] UCF20..USA LH |
89406-50040 |
— | ||
|
89408
|
89408
89407-50050 Sensor Sub-Assy, Height Control, Rear[07.1997 -] UCF20..USA RH |
89407-50050 |
US $560.56 |
||
|
89408
|
89408
89408-50050 Sensor Sub-Assy, Height Control, Rear[07.1997 -] UCF20..USA LH |
89408-50050 |
US $560.56 |
||
|
9011906375
|
9011906375
90119-06375 Bolt (For Transmission Housing & Case Setting) |
90119-06375 |
US $1.12 |
||
|
9017905100
|
9017905100
90179-05100 Nut, Antenna |
90179-05100 |
US $1.60 |
||
| replacement | |||||
|
9017905100
|
9017905100
90179-05102 Nut |
90179-05102 |
from US $0.78 |
||
|
9017906161
|
9017906161
90179-06161 Bolt, Union(For Clutch Accumulator) |
90179-06161 |
from US $0.84 |
||
|
9017906194
|
9017906194
90179-06194
Nut (For Rear Wiper Arm Setting)
|
90179-06194 |
— | ||
| replacement | |||||
|
9017906194
|
9017906194
90179-06178 Nut (For Rear Wiper Arm Setting) |
90179-06178 |
from US $0.80 |
||
|
9033330002
|
9033330002
90333-30002 Cover, Front Floor Hole |
90333-30002 |
US $1.12 |
||
|
9095001785
|
9095001785
90950-01785 New Genuine Part |
90950-01785 |
US $1.49 |
||
|
9151160610
|
9151160610
91511-60610
New Genuine Part
|
91511-60610 |
— | ||
| replacement | |||||
|
9151160610
|
9151160610
91511-B0610 BOLT FLANGE |
91511-B0610 |
US $1.76 |
||
|
9163260612
|
9163260612
91632-60612 BOLT WWASHER |
91632-60612 |
US $1.46 |
||
| replacement | |||||
|
9163260612
|
9163260612
91631-J0612 BRACKET |
91631-J0612 |
from US $1.76 |
||
