Disc Wheel & Wheel Cap ([10.1994 - ] (9410- )) Diagram Toyota LEXUS LS
- Year
- 1997 - 2000
- Sales region
- Europe
- Frame
- UCF20
- ENGINE
- 1UZFE
- DESTINATION
- V
- Model
- LS400
- From
- 07.1997
- To
- 08.2000
- Gear Shift Type
- 5FC
- Vehicle Model
- LS400
- Driver's Position
- LHD
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
42601
|
42601
42611-50170 Wheel, Disc[07.1997 -] UCF20 16X7JJ,TYPE C:REFER TO ILLUSTRATION |
42611-50170 |
US $620.26 |
||
|
42601A
|
42601A
42611-50170 Wheel, Disc[07.1997 -] UCF20 16X7JJ,TYPE C:REFER TO ILLUSTRATION |
42611-50170 |
US $620.26 |
||
|
42601C
|
42601C
90942-01062 Nut, Hub (For Axle)[10.1994 -] UCF20 |
90942-01062 |
from US $6.16 |
||
|
42603
|
42603
42603-50100
Ornament Sub-Assy, Wheel Hub
[07.1997 -] UCF20 TYPE A:REFER TO ILLUSTRATION |
42603-50100 |
— | ||
|
42611G
|
42611G
90942-05009 Valve (For Tubeless Tire)[10.1994 -] UCF20 |
90942-05009 |
US $6.24 |
||
| replacement | |||||
|
42611G
|
42611G
90080-94031 Valve (For Tubeless Tire)[10.1994 -] UCF20 |
90080-94031 |
US $1.62 |
||
|
42611J
|
42611J
90942-05009 Valve (For Tubeless Tire)[10.1994 -] UCF20 |
90942-05009 |
US $6.24 |
||
| replacement | |||||
|
42611J
|
42611J
90080-94031 Valve (For Tubeless Tire)[10.1994 -] UCF20 |
90080-94031 |
US $1.62 |
||
|
42652
|
42652
42652-50180
Tire
[10.1994 -] UCF20..V..4FC;UCF20..LHD..5FC 225/60R16 97V |
42652-50180 |
— | ||
|
42652
|
42652
42652-50260
Tire
[10.1994 -] UCF20..LHD..5FC;UCF20..LHD..EUR..4FC 225/60R16 97W |
42652-50260 |
— | ||
| replacement | |||||
|
42652
|
42652
42652-50261
Tire
[10.1994 -] UCF20..LHD..5FC;UCF20..LHD..EUR..4FC 225/60R16 97W |
42652-50261 |
— | ||
|
42652A
|
42652A
42652-50180
Tire
[10.1994 -] UCF20..V..4FC;UCF20..LHD..5FC 225/60R16 97V |
42652-50180 |
— | ||
|
42652A
|
42652A
42652-50260
Tire
[10.1994 -] UCF20..LHD..5FC;UCF20..LHD..EUR..4FC 225/60R16 97W |
42652-50260 |
— | ||
| replacement | |||||
|
42652A
|
42652A
42652-50261
Tire
[10.1994 -] UCF20..LHD..5FC;UCF20..LHD..EUR..4FC 225/60R16 97W |
42652-50261 |
— | ||
