Disc Wheel & Wheel Cap ([08.2000 - ] (0008- )) Diagram Toyota LEXUS LS
- Year
- 2003 - 2006
- Sales region
- U.S.A.
- Frame
- UCF30
- ENGINE
- 3UZFE
- DESTINATION
- USA
- Model
- LS430
- From
- 07.2003
- To
- 08.2006
- Gear Shift Type
- 6FC
- Vehicle Model
- LS430
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
42601
|
42601
42611-50370 Wheel, Disc[07.2003 -] UCF30 17X7.5JJ,TYPE E:REFER ILLUST. |
42611-50370 |
US $687.23 |
||
| replacement | |||||
|
42601
|
42601
4261A-50100 Wheel, Disc[07.2003 -] UCF30 17X7.5JJ,TYPE E:REFER ILLUST. |
4261A-50100 |
US $687.23 |
||
|
42601
|
42601
42611-50390 Wheel, DiscDISC [07.2003 -] UCF30 17X7.5JJ,W(CHROME PLATED WHEEL),TYPE E:REFER ILLUST. |
42611-50390 |
US $924.56 |
||
|
42601
|
42601
42611-50410 Wheel, Disc[07.2003 -] UCF30 18X7.5JJ,SUPER CHROME METALLIC PAINTED, TYPE F:REFER TO ILLUSTRATION |
42611-50410 |
US $732.37 |
||
| replacement | |||||
|
42601
|
42601
4261A-50110 Wheel, Disc[07.2003 -] UCF30 18X7.5JJ,SUPER CHROME METALLIC PAINTED, TYPE F:REFER TO ILLUSTRATION |
4261A-50110 |
US $692.13 |
||
|
42601
|
42601
42611-50430 Wheel, Disc[07.2003 -] UCF30 18X7.5JJ,W(CHROME PLATED WHEEL),TYPE F:REFER ILLUST. |
42611-50430 |
US $969.70 |
||
|
42601A
|
42601A
42611-50370 Wheel, Disc[07.2003 -] UCF30 17X7.5JJ,TYPE E:REFER ILLUST. |
42611-50370 |
US $687.23 |
||
| replacement | |||||
|
42601A
|
42601A
4261A-50100 Wheel, Disc[07.2003 -] UCF30 17X7.5JJ,TYPE E:REFER ILLUST. |
4261A-50100 |
US $687.23 |
||
|
42601A
|
42601A
42611-50390 Wheel, DiscDISC [07.2003 -] UCF30 17X7.5JJ,W(CHROME PLATED WHEEL),TYPE E:REFER ILLUST. |
42611-50390 |
US $924.56 |
||
|
42601A
|
42601A
42611-50410 Wheel, Disc[07.2003 -] UCF30 18X7.5JJ,TYPE F:REFER ILLUST. |
42611-50410 |
US $732.37 |
||
| replacement | |||||
|
42601A
|
42601A
4261A-50110 Wheel, Disc[07.2003 -] UCF30 18X7.5JJ,TYPE F:REFER ILLUST. |
4261A-50110 |
US $692.13 |
||
|
42601A
|
42601A
42611-50430 Wheel, Disc[07.2003 -] UCF30 18X7.5JJ,W(CHROME PLATED WHEEL),TYPE F:REFER ILLUST. |
42611-50430 |
US $969.70 |
||
|
42601C
|
42601C
90942-01033 Nut, Hub (For Axle)[07.2003 -] UCF30 |
90942-01033 |
from US $2.40 |
||
|
42611G
|
42611G
90942-05009 Valve (For Tubeless Tire)[07.2003 -] UCF30 |
90942-05009 |
from US $6.24 |
||
| replacement | |||||
|
42611G
|
42611G
90080-94031 Valve (For Tubeless Tire)[07.2003 -] UCF30 |
90080-94031 |
US $1.66 |
||
|
42611G
|
42611G
90942-05028 Valve (For Tubeless Tire)[07.2003 -] UCF30 CHROME PLATED WHEEL |
90942-05028 |
from US $6.08 |
||
|
42611J
|
42611J
90942-05009 Valve (For Tubeless Tire)[07.2003 -] UCF30 |
90942-05009 |
from US $6.24 |
||
| replacement | |||||
|
42611J
|
42611J
90080-94031 Valve (For Tubeless Tire)[07.2003 -] UCF30 |
90080-94031 |
US $1.66 |
||
|
42611J
|
42611J
90942-05028 Valve (For Tubeless Tire)[07.2003 -] UCF30 CHROME PLATED WHEEL |
90942-05028 |
from US $6.08 |
||
|
42611U
|
42611U
90942-05029 Cap, Tire Valve[07.2003 -] UCF30 |
90942-05029 |
from US $2.32 |
||
|
42611W
|
42611W
90942-05029 Cap, Tire Valve[07.2003 -] UCF30 |
90942-05029 |
from US $2.32 |
||
|
42652
|
42652
42652-50340
Tire
[07.2003 -] UCF30 P225/55R17 95H |
42652-50340 |
— | ||
|
42652
|
42652
42652-50390
Tire
[07.2003 -] UCF30 P225/55R17 95H M+S |
42652-50390 |
— | ||
|
42652
|
42652
42652-50420
Tire
[07.2003 - 05.2004] UCF30 245/45R18 96W,*B/S |
42652-50420 |
— | ||
|
42652
|
42652
42652-50421
Tire
[06.2004 -] UCF30 245/45R18 96W,*B/S |
42652-50421 |
— | ||
|
42652
|
42652
42652-50440
Tire
[08.2004 -] UCF30 245/45R18 96V,*D/L |
42652-50440 |
— | ||
|
42652
|
42652
42652-50620
Tire
[02.2006 -] UCF30 245/45R18 96V,*B/S |
42652-50620 |
— | ||
|
42652A
|
42652A
42652-50340
Tire
[07.2003 -] UCF30 P225/55R17 95H |
42652-50340 |
— | ||
|
42652A
|
42652A
42652-50390
Tire
[07.2003 -] UCF30 P225/55R17 95H M+S |
42652-50390 |
— | ||
|
42652A
|
42652A
42652-50420
Tire
[07.2003 - 05.2004] UCF30 245/45R18 96W,*B/S |
42652-50420 |
— | ||
|
42652A
|
42652A
42652-50421
Tire
[06.2004 -] UCF30 245/45R18 96W,*B/S |
42652-50421 |
— | ||
|
42652A
|
42652A
42652-50440
Tire
[08.2004 -] UCF30 245/45R18 96V,*D/L |
42652-50440 |
— | ||
|
42652A
|
42652A
42652-50620
Tire
[02.2006 -] UCF30 245/45R18 96V,*B/S |
42652-50620 |
— | ||
