Front Clearance Lamp ([01.1998 - ] (9801- )) Diagram Toyota LEXUS LX
- Year
- 2002 - 2007
- Sales region
- U.S.A.
- Frame
- UZJ100
- ENGINE
- 2UZFE
- TRANSMISSION
- ATM
- Model
- LX470
- From
- 08.2002
- To
- 08.2007
- Gear Shift Type
- 5FC
- Vehicle Model
- LX470
Difficulties in parts search?
Parts list
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
81610L
|
81610L
81610-60240
Lamp Assy, Clearance, Rh
[08.2002 - 05.2005] UZJ100 |
81610-60240 |
— | ||
|
81610M
|
81610M
99132-12050 Bulb (12V 5W)[08.2002 - 05.2005] UZJ100 |
99132-12050 |
from US $1.97 |
||
| replacement | |||||
|
81610M
|
81610M
90080-81053 Bulb(For Clearance Lamp)[08.2002 - 05.2005] UZJ100 |
90080-81053 |
US $0.99 |
||
|
81611B
|
81611B
81611-60240 Lens & Body, Clearance Lamp, RhCLEARANCE LAMP, RH [08.2002 - 05.2005] UZJ100 |
81611-60240 |
US $116.66 |
||
|
81615A
|
81615A
90075-60004 Cover, Headlamp Socket[08.2002 - 05.2005] UZJ100 |
90075-60004 |
from US $6.23 |
||
|
81620A
|
81620A
81620-60220
Lamp Assy, Clearance, Lh
[08.2002 - 05.2005] UZJ100 |
81620-60220 |
— | ||
|
81621B
|
81621B
81621-60220 Lens & Body, Clearance Lamp, LhCLEARANCE LAMP, LH [08.2002 - 05.2005] UZJ100 |
81621-60220 |
US $121.11 |
||
|
9016740027
|
9016740027
90167-40027 SCREW |
90167-40027 |
from US $0.82 |
||
| replacement | |||||
|
9016740027
|
9016740027
90167-40021 SCREW |
90167-40021 |
from US $0.76 |
||
