Front Door Lock & Handle ([01.1998 - ] (9801- )) Diagram Toyota LEXUS LX
- Year
- 2002 - 2007
- Sales region
- U.S.A.
- Frame
- UZJ100
- ENGINE
- 2UZFE
- TRANSMISSION
- ATM
- Model
- LX470
- From
- 08.2002
- To
- 08.2007
- Gear Shift Type
- 5FC
- Vehicle Model
- LX470
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
69205
|
69205
69205-51020-A0 Handle Sub-Assy, Front Door Inside, Rh[08.2002 - 05.2005] UZJ100 IVORY,TRIM0# |
69205-51020-A0 |
US $41.06 |
||
|
69205
|
69205
69205-51020-B1 Handle Sub-Assy, Front Door Inside, Rh[08.2002 - 05.2005] UZJ100 STONE,TRIM1# |
69205-51020-B1 |
US $41.06 |
||
|
69205B
|
69205B
90541-04014 Cushion, Console Box[08.2002 - 05.2005] UZJ100 |
90541-04014 |
from US $0.78 |
||
|
69206B
|
69206B
69206-51020-A0 Handle Sub-Assy, Front Door Inside, Lh[08.2002 - 05.2005] UZJ100 IVORY,TRIM0# |
69206-51020-A0 |
US $41.06 |
||
|
69206B
|
69206B
69206-51020-B1 Handle Sub-Assy, Front Door Inside, Lh[08.2002 - 05.2005] UZJ100 STONE,TRIM1# |
69206-51020-B1 |
US $41.06 |
||
|
69210
|
69210
69210-60061 Handle Assy, Front Door, Outside Rh[10.2006 -] UZJ100 *CR,SPECIAL EDITION(USA) |
69210-60061 |
from US $84.46 |
||
|
69210
|
69210
69210-60071-A3 Handle Assy, Front Door, Outside Rh[08.2002 - 05.2005] UZJ100 WHITE PEARL CS.,070 |
69210-60071-A3 |
US $108.24 |
||
|
69210
|
69210
69210-60071-A4 Handle Assy, Front Door, Outside Rh[05.2005 - 08.2007] UZJ100 WHITE PEARL CS.,062 |
69210-60071-A4 |
US $108.24 |
||
|
69210
|
69210
69210-60071-B4 Handle Assy, Front Door, Outside Rh[08.2002 - 05.2005] UZJ100 DK.GRAY M.M.,1E9 |
69210-60071-B4 |
US $108.24 |
||
|
69210
|
69210
69210-60071-B5 Handle Assy, Front Door, Outside Rh[05.2005 - 08.2007] UZJ100 SILVER ME.,1F7 |
69210-60071-B5 |
US $108.24 |
||
|
69210
|
69210
69210-60071-C0 Handle Assy, Front Door, Outside Rh[08.2002 - 05.2005] UZJ100 BLACK,202 |
69210-60071-C0 |
from US $95.21 |
||
|
69210
|
69210
69210-60071-E4 Handle Assy, Front Door, Outside Rh[08.2002 - 05.2005] UZJ100 BEIGE PEARL CS.,4R2 |
69210-60071-E4 |
US $108.24 |
||
|
69210
|
69210
69210-60071-G3 Handle Assy, Front Door, Outside RhFRONT DOOR, OUTSIDE RH [08.2002 - 05.2005] UZJ100 LT. GREEN M.M.,6T2 |
69210-60071-G3 |
US $81.84 |
||
|
69210
|
69210
69210-60071-G5 Handle Assy, Front Door, Outside Rh[05.2005 - 08.2007] UZJ100 OLIVE M.M.,6T7 |
69210-60071-G5 |
US $108.24 |
||
|
69210
|
69210
69210-60071-J1 Handle Assy, Front Door, Outside Rh[08.2002 - 05.2005] UZJ100 GRAYISH BLUE ME.,8P6 |
69210-60071-J1 |
US $81.84 |
||
|
69220
|
69220
69220-60061 Handle Assy, Front Door Outside, Lh[10.2006 -] UZJ100 *CR,SPECIAL EDITION(USA) |
69220-60061 |
from US $81.97 |
||
|
69220
|
69220
69220-60071-A3 Handle Assy, Front Door Outside, Lh[08.2002 - 05.2005] UZJ100 WHITE PEARL CS.,070 |
69220-60071-A3 |
US $90.27 |
||
|
69220
|
69220
69220-60071-A4 Handle Assy, Front Door Outside, Lh[05.2005 - 08.2007] UZJ100 WHITE PEARL CS.,062 |
69220-60071-A4 |
US $90.27 |
||
|
69220
|
69220
69220-60071-B4 Handle Assy, Front Door Outside, Lh[08.2002 - 05.2005] UZJ100 DK.GRAY M.M.,1E9 |
69220-60071-B4 |
US $90.27 |
||
|
69220
|
69220
69220-60071-B5 Handle Assy, Front Door Outside, Lh[05.2005 - 08.2007] UZJ100 SILVER ME.,1F7 |
69220-60071-B5 |
US $90.27 |
||
|
69220
|
69220
69220-60071-C0 Handle Assy, Front Door Outside, Lh[08.2002 - 05.2005] UZJ100 BLACK,202 |
69220-60071-C0 |
from US $95.21 |
||
|
69220
|
69220
69220-60071-E4 Handle Assy, Front Door Outside, Lh[08.2002 - 05.2005] UZJ100 BEIGE PEARL CS.,4R2 |
69220-60071-E4 |
US $90.27 |
||
|
69220
|
69220
69220-60071-G3 Handle Assy, Front Door Outside, LhFRONT DOOR OUTSIDE, LH [08.2002 - 05.2005] UZJ100 LT. GREEN M.M.,6T2 |
69220-60071-G3 |
US $90.27 |
||
|
69220
|
69220
69220-60071-G5 Handle Assy, Front Door Outside, Lh[05.2005 - 08.2007] UZJ100 OLIVE M.M.,6T7 |
69220-60071-G5 |
US $90.27 |
||
|
69220
|
69220
69220-60071-J1
Handle Assy, Front Door Outside, Lh
[08.2002 - 05.2005] UZJ100 GRAYISH BLUE ME.,8P6 |
69220-60071-J1 |
— | ||
|
69241D
|
69241D
69241-60021 Pad, Front Door Outside Handle, Rh[08.2002 - 05.2005] UZJ100 |
69241-60021 |
from US $6.14 |
||
|
69242C
|
69242C
69241-60021 Pad, Front Door Outside Handle, Rh[08.2002 - 05.2005] UZJ100 |
69241-60021 |
from US $6.14 |
||
|
69277B
|
69277B
69277-60040-A0 Bezel, Front Door Inside Handle, Rh[08.2002 - 05.2005] UZJ100 IVORY,TRIM0# |
69277-60040-A0 |
from US $15.87 |
||
|
69277B
|
69277B
69277-60040-B0 Bezel, Front Door Inside Handle, Rh[08.2002 - 05.2005] UZJ100 STONE,TRIM1# |
69277-60040-B0 |
US $17.92 |
||
|
69278B
|
69278B
69278-60030-A0 Bezel, Front Door Inside Handle, Lh[08.2002 - 05.2005] UZJ100 IVORY,TRIM0# |
69278-60030-A0 |
from US $13.10 |
||
|
69278B
|
69278B
69278-60030-B0 Bezel, Front Door Inside Handle, Lh[08.2002 - 05.2005] UZJ100 STONE,TRIM1# |
69278-60030-B0 |
from US $13.40 |
||
|
69297A
|
69297A
69297-60010-A0 Bezel, Door Inside Handle, No.2 Rh[08.2002 - 05.2005] UZJ100 IVORY,TRIM0# |
69297-60010-A0 |
from US $5.53 |
||
|
69297A
|
69297A
69297-60010-B0 Bezel, Door Inside Handle, No.2 Rh[08.2002 - 05.2005] UZJ100 STONE,TRIM1# |
69297-60010-B0 |
US $6.45 |
||
|
69298A
|
69298A
69298-60010-A0 Bezel, Door Inside Handle, No.2 Lh[08.2002 - 05.2005] UZJ100 IVORY,TRIM0# |
69298-60010-A0 |
US $6.45 |
||
|
69298A
|
69298A
69298-60010-B0 Bezel, Door Inside Handle, No.2 Lh[08.2002 - 05.2005] UZJ100 STONE,TRIM1# |
69298-60010-B0 |
US $6.45 |
||
|
69310
|
69310
69030-60181
Lock Assy, Front Door, Rh
[08.2002 - 05.2005] UZJ100 TAIWAN SPEC |
69030-60181 |
— | ||
| replacement | |||||
|
69310
|
69310
69030-60182 Lock Assy, Front Door, RhFRONT DOOR, RH [08.2002 - 05.2005] UZJ100 TAIWAN SPEC |
69030-60182 |
US $260.26 |
||
|
69310
|
69310
69030-60182 Lock Assy, Front Door, RhFRONT DOOR, RH [10.2006 -] UZJ100 TAIWAN SPEC |
69030-60182 |
US $260.26 |
||
|
69310
|
69310
69030-60220 Lock Assy, Front Door, RhFRONT DOOR, RH [08.2002 - 05.2005] UZJ100 |
69030-60220 |
US $215.49 |
||
| replacement | |||||
|
69310
|
69310
69030-60221
Lock Assy, Front Door, Rh
[08.2002 - 05.2005] UZJ100 |
69030-60221 |
— | ||
|
69310
|
69310
69030-60221
Lock Assy, Front Door, Rh
[12.2006 -] UZJ100 |
69030-60221 |
— | ||
|
69320
|
69320
69040-60131
Lock Assy, Front Door, Lh
[08.2002 - 05.2005] UZJ100 TAIWAN SPEC |
69040-60131 |
— | ||
| replacement | |||||
|
69320
|
69320
69040-60132 Lock Assy, Front Door, Lh[08.2002 - 05.2005] UZJ100 TAIWAN SPEC |
69040-60132 |
from US $218.40 |
||
|
69320
|
69320
69040-60132 Lock Assy, Front Door, Lh[10.2006 -] UZJ100 TAIWAN SPEC |
69040-60132 |
from US $218.40 |
||
|
69320
|
69320
69040-60190 Lock Assy, Front Door, LhFRONT DOOR, LH [08.2002 - 05.2005] UZJ100 |
69040-60190 |
US $215.49 |
||
| replacement | |||||
|
69320
|
69320
69040-60191 Lock Assy, Front Door, LhFRONT DOOR, LH [08.2002 - 05.2005] UZJ100 |
69040-60191 |
US $200.93 |
||
|
69320
|
69320
69040-60191 Lock Assy, Front Door, LhFRONT DOOR, LH [12.2006 -] UZJ100 |
69040-60191 |
US $200.93 |
||
|
69410
|
69410
69410-33020 Plate Assy, Front Door Lock Striker[08.2002 - 05.2005] UZJ100 |
69410-33020 |
US $27.72 |
||
|
69415B
|
69415B
69415-33010 Cover, Door Lock Striker, Front[08.2002 - 05.2005] UZJ100 |
69415-33010 |
from US $3.42 |
||
|
69719C
|
69719C
69719-30010 Cushion, Door Lock Control[08.2002 - 05.2005] UZJ100 |
69719-30010 |
US $1.31 |
||
|
69725
|
69725
69725-60030 Protector, Front Door Inside Locking Link, Rh[08.2002 - 05.2005] UZJ100 |
69725-60030 |
US $23.41 |
||
|
69726A
|
69726A
69726-60030
Protecter, Front Door Inside Locking Link, Lh
[08.2002 - 05.2005] UZJ100 |
69726-60030 |
— | ||
|
9014860022
|
9014860022
90148-60022 BOLT |
90148-60022 |
from US $0.48 |
||
|
9014880028
|
9014880028
90148-80028 SCREW, HEX LOBULAR |
90148-80028 |
from US $0.67 |
||
|
9015950098
|
9015950098
90159-50098 SCREW |
90159-50098 |
US $3.94 |
||
|
9016450031
|
9016450031
90164-50031 SCREW BINDING |
90164-50031 |
from US $0.63 |
||
|
9018905003
|
9018905003
90189-05003 CLIP |
90189-05003 |
from US $1.12 |
||
|
9046704014
|
9046704014
90467-04014 Clamp, Rear Door Lock Link |
90467-04014 |
US $1.93 |
||
|
9162140612
|
9162140612
91621-40612 BOLTWWASHER |
91621-40612 |
from US $0.74 |
||
