Switch & Relay & Computer ([05.2005 - ] ENGINE & TRANSMISSION (0505- )) Diagram Toyota LEXUS LX
- Year
- 2002 - 2007
- Sales region
- U.S.A.
- Frame
- UZJ100
- ENGINE
- 2UZFE
- TRANSMISSION
- ATM
- Model
- LX470
- From
- 08.2002
- To
- 08.2007
- Gear Shift Type
- 5FC
- Vehicle Model
- LX470
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
83520
|
83520
83520-35020
Gage Assy,oil Pressure Sender
[08.2002 - 09.2004] UZJ100 |
83520-35020 |
— | ||
| replacement | |||||
|
83520
|
83520
83520-60051 Gage Assy,oil Pressure Sender[08.2002 - 09.2004] UZJ100 |
83520-60051 |
from US $41.50 |
||
|
83520
|
83520
83520-60050
Gage Assy,oil Pressure Sender
[09.2004 - 05.2005] UZJ100 |
83520-60050 |
— | ||
| replacement | |||||
|
83520
|
83520
83520-60051 Gage Assy,oil Pressure Sender[09.2004 - 05.2005] UZJ100 |
83520-60051 |
from US $41.50 |
||
|
84222
|
84222
84222-12010 Switch, Transfer Indicator, No.1[08.2002 - 05.2005] UZJ100 |
84222-12010 |
from US $54.43 |
||
|
84222B
|
84222B
84222-60081 Switch, Transfer Indicator, No.1[08.2002 - 05.2005] UZJ100 |
84222-60081 |
from US $42.56 |
||
|
84222C
|
84222C
84222-12010 Switch, Transfer Indicator, No.1[08.2002 - 05.2005] UZJ100 |
84222-12010 |
from US $54.43 |
||
|
84540
|
84540
84540-51010 Switch Assy, Neutral Start[08.2002 - 05.2005] UZJ100 |
84540-51010 |
from US $135.91 |
||
|
84540
|
84540
84540-71010 Switch Assy, Neutral Start[05.2005 - 08.2007] UZJ100 |
84540-71010 |
from US $108.03 |
||
|
89465
|
89465
89465-60150 Sensor, Oxygen[08.2002 - 05.2005] UZJ100 FRONT |
89465-60150 |
from US $187.20 |
||
|
89465
|
89465
89465-60290 Sensor, OxygenOXYGEN [05.2005 - 08.2007] UZJ100 LH |
89465-60290 |
US $280.88 |
||
|
89465
|
89465
89465-60300
Sensor, Oxygen
[05.2005 - 08.2007] UZJ100 RH |
89465-60300 |
— | ||
|
89465
|
89465
89465-69175 Sensor, Oxygen[08.2002 - 05.2005] UZJ100 REAR |
89465-69175 |
from US $180.80 |
||
|
89467B
|
89467B
89467-60020 Sensor, Air Fuel RatioAIR FUEL RATIO [05.2005 -] UZJ100 RH |
89467-60020 |
US $311.39 |
||
|
89467B
|
89467B
89467-71020 Sensor, Air Fuel Ratio[05.2005 -] UZJ100 LH |
89467-71020 |
from US $214.66 |
||
|
89615
|
89615
89615-20090 Sensor, Knock Control[05.2005 -] UZJ100 |
89615-20090 |
from US $39.82 |
||
|
89615
|
89615
89615-52010 Sensor, Knock Control[08.2002 - 05.2005] UZJ100 |
89615-52010 |
from US $116.79 |
||
|
91621J0814
|
91621J0814
91621-J0814 Bolt (For Transmission Control Cable Bracket) |
91621-J0814 |
from US $0.78 |
||
|
8271560A00
|
8271560A00
82715-60A00 Bracket,wiring Harness Clamp |
82715-60A00 |
US $12.08 |
||
|
8271560A10
|
8271560A10
82715-60A10 Bracket,wiring Harness Clamp |
82715-60A10 |
US $6.41 |
||
|
8271560A20
|
8271560A20
82715-60A20 Bracket,wiring Harness Clamp |
82715-60A20 |
US $7.57 |
||
|
9012608039
|
9012608039
90126-08039 Bolt, Stud(For Oil Pan) |
90126-08039 |
US $4.30 |
||
|
9017908153
|
9017908153
90179-08153 NUT |
90179-08153 |
from US $0.76 |
||
|
9043018008
|
9043018008
90430-18008 Gasket |
90430-18008 |
from US $0.87 |
||
| replacement | |||||
|
9043018008
|
9043018008
90430-T0021 Gasket(For Manual Transmission Filler Plug) |
90430-T0021 |
US $0.99 |
||
|
9165140830
|
9165140830
91651-40830 Bolt, Radiator Side Support Plate |
91651-40830 |
US $1.31 |
||
|
9165160816
|
9165160816
91651-60816 BOLT |
91651-60816 |
from US $0.99 |
||
| replacement | |||||
|
9165160816
|
9165160816
90080-11396 BOLT |
90080-11396 |
US $3.32 |
||
