Disc Wheel & Wheel Cap ([08.2002 - ] (0208- )) Diagram Toyota LEXUS LX
- Year
- 2002 - 2007
- Sales region
- Europe
- Frame
- UZJ100
- ENGINE
- 2UZFE
- TRANSMISSION
- ATM
- Model
- LX470
- From
- 08.2002
- To
- 08.2007
- Gear Shift Type
- 5FC
- Vehicle Model
- LX470
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
42601A
|
42601A
42611-60470 Wheel, Disc (For Spare)DISC (FOR SPARE) [08.2002 - 05.2005] UZJ100 17X8JJ,TYPE A:REFER ILLUST. |
42611-60470 |
US $665.39 |
||
| replacement | |||||
|
42601A
|
42601A
42611-60480 Wheel, Disc (For Spare)DISC (FOR SPARE) [08.2002 - 05.2005] UZJ100 17X8JJ,TYPE A:REFER ILLUST. |
42611-60480 |
US $665.39 |
||
|
42601A
|
42601A
42611-60480 Wheel, Disc (For Spare)DISC (FOR SPARE) [08.2002 - 05.2005] UZJ100 17X8JJ,TYPE B:REFER ILLUST. |
42611-60480 |
US $665.39 |
||
|
42601A
|
42601A
42611-60590
Wheel, Disc (For Spare)
[05.2006 -] UZJ100 17X8JJ,TYPE A:REFER ILLUST. |
42611-60590 |
— | ||
| replacement | |||||
|
42601A
|
42601A
42611-60600
Wheel, Disc (For Spare)
[05.2006 -] UZJ100 17X8JJ,TYPE A:REFER ILLUST. |
42611-60600 |
— | ||
|
42601A
|
42601A
42611-60600
Wheel, Disc (For Spare)
[05.2006 -] UZJ100 17X8JJ,TYPE B:REFER ILLUST. |
42611-60600 |
— | ||
|
42601C
|
42601C
90942-01103 Nut, Hub (For Axle)[08.2002 - 05.2005] UZJ100 |
90942-01103 |
from US $8.23 |
||
|
42601F
|
42601F
42611-60470 Wheel, Disc (For Spare)DISC (FOR SPARE) [08.2002 - 05.2005] UZJ100 17X8JJ,TYPE A:REFER TO ILLUSTRATION |
42611-60470 |
US $665.39 |
||
| replacement | |||||
|
42601F
|
42601F
42611-60480 Wheel, Disc (For Spare)DISC (FOR SPARE) [08.2002 - 05.2005] UZJ100 17X8JJ,TYPE A:REFER TO ILLUSTRATION |
42611-60480 |
US $665.39 |
||
|
42601F
|
42601F
42611-60480 Wheel, Disc (For Spare)DISC (FOR SPARE) [08.2002 - 05.2005] UZJ100 17X8JJ,TYPE B:REFER ILLUST. |
42611-60480 |
US $665.39 |
||
|
42601F
|
42601F
42611-60590
Wheel, Disc (For Spare)
[05.2006 -] UZJ100 17X8JJ,TYPE A:REFER ILLUST. |
42611-60590 |
— | ||
| replacement | |||||
|
42601F
|
42601F
42611-60600
Wheel, Disc (For Spare)
[05.2006 -] UZJ100 17X8JJ,TYPE A:REFER ILLUST. |
42611-60600 |
— | ||
|
42601F
|
42601F
42611-60600
Wheel, Disc (For Spare)
[05.2006 -] UZJ100 17X8JJ,TYPE B:REFER ILLUST. |
42611-60600 |
— | ||
|
42601R
|
42601R
42611-60470 Wheel, Disc (For Spare)DISC (FOR SPARE) [08.2002 - 05.2005] UZJ100 17X8JJ,TYPE A:REFER TO ILLUSTRATION |
42611-60470 |
US $665.39 |
||
| replacement | |||||
|
42601R
|
42601R
42611-60480 Wheel, Disc (For Spare)DISC (FOR SPARE) [08.2002 - 05.2005] UZJ100 17X8JJ,TYPE A:REFER TO ILLUSTRATION |
42611-60480 |
US $665.39 |
||
|
42601R
|
42601R
42611-60480 Wheel, Disc (For Spare)DISC (FOR SPARE) [08.2002 - 05.2005] UZJ100 17X8JJ,TYPE B:REFER ILLUST. |
42611-60480 |
US $665.39 |
||
|
42601R
|
42601R
42611-60590
Wheel, Disc (For Spare)
[05.2006 -] UZJ100 17X8JJ,TYPE A:REFER ILLUST. |
42611-60590 |
— | ||
| replacement | |||||
|
42601R
|
42601R
42611-60600
Wheel, Disc (For Spare)
[05.2006 -] UZJ100 17X8JJ,TYPE A:REFER ILLUST. |
42611-60600 |
— | ||
|
42601R
|
42601R
42611-60600
Wheel, Disc (For Spare)
[05.2006 -] UZJ100 17X8JJ,TYPE B:REFER ILLUST. |
42611-60600 |
— | ||
|
42611G
|
42611G
90942-05009 Valve (For Tubeless Tire)[08.2002 - 05.2005] UZJ100 |
90942-05009 |
from US $6.99 |
||
| replacement | |||||
|
42611G
|
42611G
90080-94031 Valve (For Tubeless Tire)[08.2002 - 05.2005] UZJ100 |
90080-94031 |
US $1.46 |
||
|
42611J
|
42611J
90942-05009 Valve (For Tubeless Tire)[08.2002 - 05.2005] UZJ100 |
90942-05009 |
from US $6.99 |
||
| replacement | |||||
|
42611J
|
42611J
90080-94031 Valve (For Tubeless Tire)[08.2002 - 05.2005] UZJ100 |
90080-94031 |
US $1.46 |
||
|
42652
|
42652
42652-60750
Tire
[08.2002 - 11.2002] UZJ100 275/65R17 115T,*D/L |
42652-60750 |
— | ||
|
42652
|
42652
42652-60760
Tire
[08.2002 - 11.2002] UZJ100 275/65R17,*B/S |
42652-60760 |
— | ||
|
42652
|
42652
42652-60840
Tire
[11.2002 - 12.2003] UZJ100 275/65R17 115H,*D/L |
42652-60840 |
— | ||
| replacement | |||||
|
42652
|
42652
42652-60841
Tire
[11.2002 - 12.2003] UZJ100 275/65R17 115H,*D/L |
42652-60841 |
— | ||
|
42652
|
42652
42652-60841
Tire
[05.2005 -] UZJ100 275/65R17,*D/L |
42652-60841 |
— | ||
|
42652
|
42652
42652-60850
Tire
[11.2002 - 12.2003] UZJ100 275/65R17,MICHELIN |
42652-60850 |
— | ||
| replacement | |||||
|
42652
|
42652
42652-60851
Tire
[11.2002 - 12.2003] UZJ100 275/65R17,MICHELIN |
42652-60851 |
— | ||
|
42652
|
42652
42652-60851
Tire
[05.2005 -] UZJ100 275/65R17,MICHELIN |
42652-60851 |
— | ||
|
42652A
|
42652A
42652-60750
Tire
[08.2002 - 11.2002] UZJ100 275/65R17 115T,*D/L |
42652-60750 |
— | ||
|
42652A
|
42652A
42652-60760
Tire
[08.2002 - 11.2002] UZJ100 275/65R17,*B/S |
42652-60760 |
— | ||
|
42652A
|
42652A
42652-60840
Tire
[11.2002 - 12.2003] UZJ100 275/65R17 115H,*D/L |
42652-60840 |
— | ||
| replacement | |||||
|
42652A
|
42652A
42652-60841
Tire
[11.2002 - 12.2003] UZJ100 275/65R17 115H,*D/L |
42652-60841 |
— | ||
|
42652A
|
42652A
42652-60841
Tire
[05.2005 - 04.2006] UZJ100 275/65R17,*D/L |
42652-60841 |
— | ||
|
42652A
|
42652A
42652-60850
Tire
[11.2002 - 12.2003] UZJ100 275/65R17,MICHELIN |
42652-60850 |
— | ||
| replacement | |||||
|
42652A
|
42652A
42652-60851
Tire
[11.2002 - 12.2003] UZJ100 275/65R17,MICHELIN |
42652-60851 |
— | ||
|
42652A
|
42652A
42652-60851
Tire
[05.2005 - 04.2006] UZJ100 275/65R17,MICHELIN |
42652-60851 |
— | ||
