Switch & Relay & Computer ([01.1998 - 08.2002] COWL (9801-0208)) Diagram Toyota LEXUS LX
- Year
- 1998 - 2002
- Sales region
- U.S.A.
- Frame
- UZJ100
- ENGINE
- 2UZFE
- TRANSMISSION
- ATM
- Model
- LX470
- From
- 01.1998
- To
- 08.2002
- Gear Shift Type
- 4FC
- Vehicle Model
- LX470
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
81240F
|
81240F
90987-02012 Relay, Ignition, No.1[01.1998 - 08.2002] UZJ100 |
90987-02012 |
from US $27.85 |
||
|
81980
|
81980
81980-60030 Flasher Assy, Turn Signal[01.1998 - 08.2002] UZJ100 |
81980-60030 |
from US $79.29 |
||
|
82600F
|
82600F
90982-09008 Fusible Link[01.1998 - 08.2002] UZJ100 7.5A,MINI FUSE |
90982-09008 |
from US $0.90 |
||
|
82600F
|
82600F
90982-09009 Fusible Link[01.1998 - 08.2002] UZJ100 10A,MINI FUSE |
90982-09009 |
from US $1.12 |
||
|
82600F
|
82600F
90982-09010 Fusible Link[01.1998 - 08.2002] UZJ100 15A,MINI FUSE |
90982-09010 |
from US $1.12 |
||
|
82600F
|
82600F
90982-09011 Fusible Link[01.1998 - 08.2002] UZJ100 20A,MINI FUSE |
90982-09011 |
from US $0.94 |
||
|
82600F
|
82600F
90982-09012 Fusible Link[08.2000 - 08.2002] UZJ100 25A,MINI FUSE |
90982-09012 |
from US $0.92 |
||
|
82600F
|
82600F
90982-09013 Fusible Link[01.1998 - 08.2002] UZJ100 30A,MINI FUSE |
90982-09013 |
from US $0.94 |
||
|
82666
|
82666
82666-35040 Holder, Connector No.4[01.1998 - 08.2002] UZJ100 NO.1 |
82666-35040 |
US $2.33 |
||
|
82666
|
82666
82666-60080 Holder, Connector[01.1998 - 08.2002] UZJ100 NO.2 |
82666-60080 |
US $9.17 |
||
|
82672B
|
82672B
82672-60020 Cover, Junction BlockJUNCTION BLOCK [01.1998 - 08.2000] UZJ100 |
82672-60020 |
US $13.40 |
||
|
82672B
|
82672B
82672-60021 Cover, Junction BlockJUNCTION BLOCK [08.2000 - 08.2002] UZJ100 |
82672-60021 |
US $13.40 |
||
|
82731A
|
82731A
82731-60030 Block, Cowl Side Junction, Rh[01.1998 - 08.2002] UZJ100 |
82731-60030 |
US $168.90 |
||
|
82733A
|
82733A
82733-60040
Block, Cowl Side Junction, Lh
[01.1998 - 08.2000] UZJ100 |
82733-60040 |
— | ||
|
82733A
|
82733A
82733-60041 Block, Cowl Side Junction, LhCOWL SIDE JUNCTION, LH [08.2000 - 08.2002] UZJ100 |
82733-60041 |
US $522.70 |
||
|
82791A
|
82791A
82791-60030 Controller & Junction, Instrument PanelINSTRUMENT PANEL [01.1998 - 07.1999] UZJ100 |
82791-60030 |
US $436.80 |
||
|
82791A
|
82791A
82791-60031 Controller & Junction, Instrument PanelINSTRUMENT PANEL [07.1999 - 08.2002] UZJ100 |
82791-60031 |
US $436.80 |
||
|
82810
|
82810
82810-60080 Relay Assy, Running LightRUNNING LIGHT [01.1998 - 08.2002] UZJ100 |
82810-60080 |
US $214.03 |
||
|
84340
|
84340
84340-32110 Switch Assy, Stop Lamp[01.1998 - 05.2000] UZJ100 |
84340-32110 |
US $59.55 |
||
| replacement | |||||
|
84340
|
84340
84340-42020 Switch Assy, Stop Lamp[01.1998 - 05.2000] UZJ100 |
84340-42020 |
from US $21.28 |
||
|
84340
|
84340
84340-42020 Switch Assy, Stop Lamp[05.2000 - 08.2002] UZJ100 |
84340-42020 |
from US $21.28 |
||
|
84562
|
84562
84562-60010 Switch, Fuel Control[01.1998 - 08.2002] UZJ100 |
84562-60010 |
US $62.46 |
||
|
84930F
|
84930F
90987-04004 Relay, Starter Cut[01.1998 - 08.2002] UZJ100 |
90987-04004 |
US $42.71 |
||
|
84930G
|
84930G
90987-04004 Relay, Starter Cut[01.1998 - 08.2002] UZJ100 |
90987-04004 |
US $42.71 |
||
|
85910C
|
85910C
90987-04002 Relay, Ignition, No.1[01.1998 - 08.2002] UZJ100 |
90987-04002 |
from US $25.17 |
||
|
85910Y
|
85910Y
90987-02012 Relay, Ignition, No.1[01.1998 - 08.2002] UZJ100 |
90987-02012 |
from US $27.85 |
||
|
85912
|
85912
90987-02012 Relay, Ignition, No.1[01.1998 - 08.2002] UZJ100 |
90987-02012 |
from US $27.85 |
||
|
85916D
|
85916D
90987-02012 Relay, Ignition, No.1[01.1998 - 08.2002] UZJ100 |
90987-02012 |
from US $27.85 |
||
|
85916N
|
85916N
90987-02012 Relay, Ignition, No.1[01.1998 - 08.2002] UZJ100 |
90987-02012 |
from US $27.85 |
||
|
85939
|
85939
90987-02009 Relay Assy[01.1998 - 08.2002] UZJ100 |
90987-02009 |
from US $33.87 |
||
|
89111
|
89111
89111-60010
Computer, Network Gateway
[08.2000 - 08.2002] UZJ100 |
89111-60010 |
— | ||
|
89227
|
89227
89227-60020 Computer, Multiplex Tilt & TelescopicMULTIPLEX TILT & TELESCOPIC [01.1998 - 07.1999] UZJ100 |
89227-60020 |
US $429.52 |
||
| replacement | |||||
|
89227
|
89227
89227-60022 Computer, Multiplex Tilt & TelescopicMULTIPLEX TILT & TELESCOPIC [01.1998 - 07.1999] UZJ100 |
89227-60022 |
from US $250.20 |
||
|
89227
|
89227
89227-60021 Computer, Multiplex Tilt & TelescopicMULTIPLEX TILT & TELESCOPIC [07.1999 - 08.2000] UZJ100 |
89227-60021 |
from US $473.20 |
||
| replacement | |||||
|
89227
|
89227
89227-60022 Computer, Multiplex Tilt & TelescopicMULTIPLEX TILT & TELESCOPIC [07.1999 - 08.2000] UZJ100 |
89227-60022 |
from US $250.20 |
||
|
89227
|
89227
89227-60022 Computer, Multiplex Tilt & TelescopicMULTIPLEX TILT & TELESCOPIC [08.2000 - 08.2002] UZJ100 |
89227-60022 |
from US $250.20 |
||
|
89531A
|
89531A
89531-60050 Relay, Transmission ControlTRANSMISSION CONTROL [01.1998 - 08.2002] UZJ100 |
89531-60050 |
US $210.29 |
||
|
89533
|
89533
89533-60090
Computer, 4 Wheel Drive Control
[01.1998 - 07.1999] UZJ100 |
89533-60090 |
— | ||
|
89730
|
89730
89730-60010
Computer Assy, Security Warning
[01.1998 - 09.2000] UZJ100 |
89730-60010 |
— | ||
| replacement | |||||
|
89730
|
89730
89730-60011 Computer Assy, Security WarningSECURITY WARNING [01.1998 - 09.2000] UZJ100 |
89730-60011 |
US $566.38 |
||
|
89730
|
89730
89730-60011 Computer Assy, Security WarningSECURITY WARNING [09.2000 - 08.2002] UZJ100 |
89730-60011 |
US $566.38 |
||
|
9015950098
|
9015950098
90159-50098 SCREW |
90159-50098 |
US $3.52 |
||
|
9015960303
|
9015960303
90159-60303 SCREW |
90159-60303 |
from US $1.12 |
||
|
9015960566
|
9015960566
90159-60566 New Genuine Part |
90159-60566 |
US $1.46 |
||
|
9017906158
|
9017906158
90179-06158 Nut, Rear Wiper Link Pivot, No.2 |
90179-06158 |
from US $0.99 |
||
|
9017906159
|
9017906159
90179-06159 Nut, Rear Wiper Link Pivot, No.1 |
90179-06159 |
from US $0.59 |
||
| replacement | |||||
|
9017906159
|
9017906159
90080-17210
Nut, Rear Wiper Link Pivot, No.1
|
90080-17210 |
— | ||
|
9033905012
|
9033905012
90339-05012 New Genuine Part |
90339-05012 |
US $6.08 |
||
|
9163560616
|
9163560616
91635-60616
BOLT WWASHER
|
91635-60616 |
— | ||
| replacement | |||||
|
9163560616
|
9163560616
91631-J0612 BRACKET |
91631-J0612 |
from US $0.78 |
||
|
9415080600
|
9415080600
94150-80600 NUT FLANGE |
94150-80600 |
from US $0.72 |
||
