Switch & Relay & Computer ([01.2009 - ] SEAT (0901- )) Diagram Toyota LEXUS RX
- Year
- 2012 - 2015
- Sales region
- U.S.A.
- Frame
- GGL15
- grade
- STD
- ENGINE
- 2GRFE
- TRANSMISSION
- ATM
- PRODUCT
- NAP
- Model
- RX350
- From
- 07.2012
- To
- 10.2015
- Gear Shift Type
- 8FC
- Vehicle Model
- RX350
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
84070
|
84070
84070-0E020
Computer & Switch Assy, Position Control
[04.2012 - 10.2015] GGL1#,GYL1#..NAP |
84070-0E020 |
— | ||
|
84920C
|
84920C
84920-0E020-A1
Switch Assy, Power Seat Front, Rh
[04.2012 - 10.2015] GGL1#,GYL1#..NAP IVORY,TRIM0# |
84920-0E020-A1 |
— | ||
|
84920C
|
84920C
84920-0E020-C0
Switch Assy, Power Seat
[04.2012 - 10.2015] GGL1#..NAP BLACK,TRIM1#,2#,3#,4# |
84920-0E020-C0 |
— | ||
|
84920D
|
84920D
84920-0E010-A1
Switch Assy, Power Seat Front, Lh
[04.2012 - 10.2015] GGL1#,GYL1#..NAP IVORY,TRIM0# |
84920-0E010-A1 |
— | ||
|
84920D
|
84920D
84920-0E010-C0
Switch Assy, Power Seat
[04.2012 - 10.2015] GGL1#..NAP BLACK,TRIM1#,2#,3#,4# |
84920-0E010-C0 |
— | ||
|
84921A
|
84921A
84921-0E070-A0
Knob, Power Seat Switch (For Reclining)
[04.2012 - 10.2015] GGL1#,GYL1#..NAP IVORY,TRIM0#,RH |
84921-0E070-A0 |
— | ||
|
84921A
|
84921A
84921-0E070-C0
Knob, Power Seat Switch (For Reclining)
[04.2012 - 10.2015] GGL1#..NAP BLACK,TRIM1#,2#,3#,4#,RH |
84921-0E070-C0 |
— | ||
|
84921A
|
84921A
84921-0E080-A0
Knob, Power Seat Switch (For Reclining)
[04.2012 - 10.2015] GGL1#,GYL1#..NAP IVORY,TRIM0#,LH |
84921-0E080-A0 |
— | ||
|
84921A
|
84921A
84921-0E080-C0
Knob, Power Seat Switch (For Reclining)
[04.2012 - 10.2015] GGL1#..NAP BLACK,TRIM1#,2#,3#,4#,LH |
84921-0E080-C0 |
— | ||
|
84921B
|
84921B
84921-0E050-A0
Knob, Power Seat Switch (For Slide & Vertical)
[04.2012 - 10.2015] GGL1#,GYL1#..NAP IVORY,TRIM0#,RH |
84921-0E050-A0 |
— | ||
|
84921B
|
84921B
84921-0E050-C0
Knob, Power Seat Switch (For Slide & Vertical)
[04.2012 - 10.2015] GGL1#..NAP BLACK,TRIM1#,2#,3#,4#,RH |
84921-0E050-C0 |
— | ||
|
84921B
|
84921B
84921-0E060-A0
Knob, Power Seat Switch (For Slide & Vertical)
[04.2012 - 10.2015] GGL1#,GYL1#..NAP IVORY,TRIM0#,LH |
84921-0E060-A0 |
— | ||
|
84921B
|
84921B
84921-0E060-C0
Knob, Power Seat Switch (For Slide & Vertical)
[04.2012 - 10.2015] GGL1#..NAP BLACK,TRIM1#,2#,3#,4#,LH |
84921-0E060-C0 |
— | ||
|
84922B
|
84922B
84922-AA060
Switch, Front Power Seat
[04.2012 - 10.2015] GGL1#,GYL1#..NAP |
84922-AA060 |
— | ||
|
9008016099
|
9008016099
90080-16099 SCREW PAN TAPPING |
90080-16099 |
US $0.73 |
||
|
9008416012
|
9008416012
90084-16012 SCREW |
90084-16012 |
US $1.77 |
