Rear Axle Shaft & Hub ([09.2003 - ] RH (0309- )GSU35,MCU38..NAP) Diagram Toyota LEXUS RX
- Year
- 2003 - 2006
- Sales region
- U.S.A.
- Frame
- MCU38
- grade
- STD
- body
- WG
- ENGINE
- 3MZFE
- TRANSMISSION
- ATM
- PRODUCT
- NAP
- Model
- RX330
- From
- 09.2003
- To
- 02.2006
- Gear Shift Type
- 5FC
- Vehicle Model
- RX330
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
04438N
|
04438N
04437-08011
Boot Kit, Rear Drive Shaft
[09.2003 - 02.2006] MCU38..NAP |
04437-08011 |
— | ||
|
04438P
|
04438P
04437-08010
Boot Kit, Rear Drive Shaft Inboard Joint
[09.2003 - 02.2006] MCU38..NAP |
04437-08010 |
— | ||
|
41336J
|
41336J
41336-0E010
Cover, Dust(For Rear Drive Shaft)
[09.2003 - 02.2006] MCU38..NAP |
41336-0E010 |
— | ||
|
42330
|
42330
42340-0E010
Shaft Assy, Rear Drive, Rh
[09.2003 - 02.2006] MCU38..NAP |
42340-0E010 |
— | ||
|
42341A
|
42341A
43425-08010
Ring, Snap (For Rear Drive Shaft)
[09.2003 - 02.2006] MCU38..NAP ID=22.2 |
43425-08010 |
— | ||
|
42341A
|
42341A
43425-08020
Ring, Snap (For Rear Drive Shaft)
[09.2003 - 02.2006] MCU38..NAP ID=70.7 |
43425-08020 |
— | ||
|
42341B
|
42341B
43425-0E010 Ring, Snap (For Rear Drive Shaft Rh)SHAFT SNAP (FOR REAR DRIVE SHAFT INBOARD JOINT RH) [09.2003 - 02.2006] MCU38..NAP |
43425-0E010 |
US $0.58 |
||
|
42346A
|
42346A
42345-08030
Clamp (For Rear Drive Shaft Outboard Joint Boot)
[09.2003 - 02.2006] MCU38..NAP ID=30.1 |
42345-08030 |
— | ||
|
42346B
|
42346B
42345-08040
Clamp, No. 2 (For Rr Drive Shaft Outboard Joint Boot)
[09.2003 - 02.2006] MCU38..NAP |
42345-08040 |
— | ||
|
42347A
|
42347A
42345-08010
Clamp (For Rear Drive Shaft Inboard Joint Boot)
[09.2003 - 02.2006] MCU38..NAP ID=31.9 |
42345-08010 |
— | ||
|
42347B
|
42347B
42345-08020
Clamp, No.2 (For Rear Drive Shaft Inboard Joint Boot)
[09.2003 - 02.2006] MCU38..NAP |
42345-08020 |
— | ||
|
42360C
|
42360C
42360-0E010
Joint Assy, Rear Drive Shaft Inboard, Rh
[09.2003 - 02.2006] MCU38..NAP |
42360-0E010 |
— | ||
|
42370A
|
42370A
42370-09008
Shaft Assy, Rear Drive Outboard Joint, Rh
[09.2003 - 02.2006] MCU38..NAP |
42370-09008 |
— |
