Switch & Relay & Computer ([01.2008 - ] (0801- )) Diagram Toyota LITE/ TOWNACE
- Year
- 2008 - 2018
- Sales region
- Japan
- Frame
- S402M
- grade
- DX
- body
- VAN
- ENGINE
- 3SZVE
- Model
- LITE/TOWNACE
- From
- 01.2008
- Gear Shift Type
- 4FC
- Vehicle Model
- LITE/TOWNACE
- Building Condition
- CBU
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
83530
|
83530
83530-97401 Switch Assy, Oil Pressure (For Engine)[01.2008 -] S402,412 |
83530-97401 |
from US $18.82 |
||
|
84540
|
84540
84540-97502
Switch Assy, Neutral Start
[01.2008 - 04.2011] S402,412..4FC |
84540-97502 |
— | ||
| replacement | |||||
|
84540
|
84540
84540-B0010 Switch Assy, Neutral Start[01.2008 - 04.2011] S402,412..4FC |
84540-B0010 |
from US $112.91 |
||
|
84540
|
84540
84540-B0010 Switch Assy, Neutral Start[05.2011 -] S402,412..4FC |
84540-B0010 |
from US $112.91 |
||
|
89421B
|
89421B
89421-BZ020 Sensor, Vacuum[01.2008 -] S402,412 |
89421-BZ020 |
US $74.26 |
||
| replacement | |||||
|
89421B
|
89421B
89421-B2040 Sensor, Vacuum[01.2008 -] S402,412 |
89421-B2040 |
US $104.96 |
||
|
89422A
|
89422A
89422-BZ010 Sensor, Water Temperature[01.2008 -] S402,412 |
89422-BZ010 |
from US $40.49 |
||
|
89465
|
89465
89465-BZ200 Sensor, Oxygen[01.2008 - 07.2010] S402 品番ラベル有り |
89465-BZ200 |
US $129.56 |
||
|
89465
|
89465
89465-BZ320 Sensor, Oxygen[07.2010 - 01.2014] S402 品番ラベル有り |
89465-BZ320 |
US $129.56 |
||
|
89465
|
89465
89465-BZ321 Sensor, Oxygen[01.2014 -] S402,412 品番ラベル有り |
89465-BZ321 |
US $111.52 |
||
|
89465A
|
89465A
89465-BZ180 Sensor, Oxygen No.2[01.2008 - 07.2010] S402 品番ラベル有り |
89465-BZ180 |
US $110.07 |
||
|
89465A
|
89465A
89465-BZ310 Sensor, Oxygen No.2[07.2010 -] S402 品番ラベル有り |
89465-BZ310 |
US $119.72 |
||
|
89615
|
89615
89615-BZ030 Sensor, Knock Control[01.2008 - 12.2012] S402,412 |
89615-BZ030 |
US $131.04 |
||
| replacement | |||||
|
89615
|
89615
89615-20090 Sensor, Knock Control[01.2008 - 12.2012] S402,412 |
89615-20090 |
from US $39.82 |
||
|
89615
|
89615
89615-BZ040
Sensor, Knock Control
[12.2012 -] S402,412 |
89615-BZ040 |
— | ||
|
9004A11240
|
9004A11240
9004A-11240
New Genuine Part
|
9004A-11240 |
— | ||
|
9004119865
|
9004119865
90041-19865 New Genuine Part |
90041-19865 |
US $1.16 |
||
|
9012608039
|
9012608039
90126-08039 Bolt, Stud(For Oil Pan) |
90126-08039 |
US $4.30 |
||
|
9017908153
|
9017908153
90179-08153 NUT |
90179-08153 |
from US $0.78 |
||
|
9043012221
|
9043012221
90430-12221 Gasket |
90430-12221 |
from US $1.07 |
||
