Front Fender Apron & Dash Panel ([01.2008 - ] (0801- )) Diagram Toyota LITE/ TOWNACE
- Year
- 2008 - 2018
- Sales region
- Japan
- Frame
- S402U
- grade
- DXED
- body
- PIC
- ENGINE
- 3SZVE
- Model
- LITE/TOWNACE
- From
- 01.2008
- Gear Shift Type
- 5F
- Vehicle Model
- LITE/TOWNACE
- Building Condition
- CBU
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
52145D
|
52145D
52145-BZ050 Bracket, Front Bumper Side Mounting, Rh[01.2008 -] S402,412 |
52145-BZ050 |
from US $6.81 |
||
|
52146D
|
52146D
52145-BZ050 Bracket, Front Bumper Side Mounting, Rh[01.2008 -] S402,412 |
52145-BZ050 |
from US $6.81 |
||
|
53028
|
53028
53028-BZ090 Support Sub-Assy, Radiator, Lower[01.2008 - 05.2010] S402 |
53028-BZ090 |
US $151.42 |
||
| replacement | |||||
|
53028
|
53028
53028-BZ091 Support Sub-Assy, Radiator, LowerRADIATOR, LOWER [01.2008 - 05.2010] S402 |
53028-BZ091 |
from US $196.80 |
||
|
53028
|
53028
53028-BZ091 Support Sub-Assy, Radiator, LowerRADIATOR, LOWER [06.2010 -] S402,412 |
53028-BZ091 |
from US $196.80 |
||
|
53201
|
53201
53201-BZ190 Support Sub-Assy, Radiator[01.2008 - 05.2010] S402 |
53201-BZ190 |
US $307.22 |
||
| replacement | |||||
|
53201
|
53201
53201-BZ191 Support Sub-Assy, RadiatorRADIATOR [01.2008 - 05.2010] S402 |
53201-BZ191 |
US $474.24 |
||
|
53201
|
53201
53201-BZ191 Support Sub-Assy, RadiatorRADIATOR [06.2010 -] S402,412 |
53201-BZ191 |
US $474.24 |
||
|
53205
|
53205
53205-BZ130 Support Sub-Assy, Radiator, Upper[01.2008 - 06.2013] S402,412 ＴＹＰＥ Ｂ（３スポット溶接） |
53205-BZ130 |
US $110.88 |
||
|
53205
|
53205
53205-BZ131 Support Sub-Assy, Radiator, Upper[06.2013 -] S402,412 ＴＹＰＥ Ａ（２スポット溶接） |
53205-BZ131 |
US $75.71 |
||
|
53208A
|
53208A
53215-BZ090 Support Sub-Assy, Hood Lock[01.2008 -] S402,412 |
53215-BZ090 |
from US $19.31 |
||
|
53211C
|
53211C
53211-BZ100 Support, Radiator, Rh[01.2008 -] S402,412 |
53211-BZ100 |
US $29.99 |
||
|
53212C
|
53212C
53203-BZ090 Support, Radiator, Lh[01.2008 -] S402,412 |
53203-BZ090 |
US $42.08 |
||
|
53253B
|
53253B
53253-BZ020 Bracket, Radiator Mounting, Upper[01.2008 -] S402,412 右側 |
53253-BZ020 |
US $8.74 |
||
|
53253B
|
53253B
53254-BZ020 Bracket, Radiator Mounting, Upper[01.2008 -] S402,412 左側 |
53254-BZ020 |
US $8.74 |
||
|
53291J
|
53291J
81818-BZ030 Seal, Radiator Support[01.2008 -] S402,412 |
81818-BZ030 |
US $11.29 |
||
|
53705E
|
53705E
53705-BZ020 Member Sub-Assy, Front Apron To Cowl Side, Rh[01.2008 - 12.2014] S402,412 |
53705-BZ020 |
US $165.98 |
||
| replacement | |||||
|
53705E
|
53705E
53705-BZ070 Member Sub-Assy, Front Apron To Cowl Side, Rh[01.2008 - 12.2014] S402,412 |
53705-BZ070 |
US $208 |
||
|
53705E
|
53705E
53705-BZ070 Member Sub-Assy, Front Apron To Cowl Side, Rh[01.2015 -] S402,412 |
53705-BZ070 |
US $208 |
||
|
53706D
|
53706D
53706-BZ040 Member Sub-Assy, Front Apron To Cowl Side, Lh[01.2008 - 12.2014] S402,412 |
53706-BZ040 |
US $64.06 |
||
| replacement | |||||
|
53706D
|
53706D
53706-BZ100 Member Sub-Assy, Front Apron To Cowl Side, Lh[01.2008 - 12.2014] S402,412 |
53706-BZ100 |
US $86.92 |
||
|
53706D
|
53706D
53706-BZ100 Member Sub-Assy, Front Apron To Cowl Side, Lh[01.2015 -] S402,412 |
53706-BZ100 |
US $86.92 |
||
|
53877F
|
53877F
53707-BZ030 Bracket, Front Fender Liner, Rh[01.2015 -] S402,412 |
53707-BZ030 |
US $13.44 |
||
|
53877F
|
53877F
53877-BZ010 Bracket, Front Fender Liner, Rh[01.2008 - 12.2014] S402,412 |
53877-BZ010 |
US $9.03 |
||
| replacement | |||||
|
53877F
|
53877F
53707-BZ030 Bracket, Front Fender Liner, Rh[01.2008 - 12.2014] S402,412 |
53707-BZ030 |
US $13.44 |
||
|
53878N
|
53878N
53708-BZ020 Bracket, Front Fender Liner, Lh[01.2015 -] S402,412 |
53708-BZ020 |
US $13.44 |
||
|
53878N
|
53878N
53878-BZ030 Bracket, Front Fender Liner, Lh[01.2008 - 12.2014] S402,412 |
53878-BZ030 |
US $9.03 |
||
| replacement | |||||
|
53878N
|
53878N
53708-BZ020 Bracket, Front Fender Liner, Lh[01.2008 - 12.2014] S402,412 |
53708-BZ020 |
US $13.44 |
||
|
55101
|
55101
55101-BZ580 Panel Sub-Assy, Dash[01.2008 -] S402..5F |
55101-BZ580 |
US $285.38 |
||
|
55210A
|
55210A
90044-67397 Clip[01.2008 - 08.2016] S402,412 |
90044-67397 |
US $3.05 |
||
|
55210A
|
55210A
9004A-46131-B0
Clip
[09.2016 -] S402,412 DK.GRAY |
9004A-46131-B0 |
— | ||
|
55215B
|
55215B
55215-BZ010 Pad, Dash Panel Insulator, No.3[01.2008 -] S402,412 |
55215-BZ010 |
US $54.02 |
||
|
9004A11251
|
9004A11251
9004A-11251 New Genuine Part |
9004A-11251 |
US $2.48 |
||
| replacement | |||||
|
9004A11251
|
9004A11251
91651-B0825 Bolt, Hexagon(For Steering Column Bracket) |
91651-B0825 |
from US $0.84 |
||
|
9004A11260
|
9004A11260
9004A-11260 New Genuine Part |
9004A-11260 |
US $2.18 |
||
| replacement | |||||
|
9004A11260
|
9004A11260
91621-B0816 BOLT WWASHER |
91621-B0816 |
from US $0.84 |
||
|
9004A11281
|
9004A11281
9004A-11281
New Genuine Part
|
9004A-11281 |
— | ||
|
9004A17221
|
9004A17221
9004A-17221
New Genuine Part
|
9004A-17221 |
— | ||
|
85373BZ060
|
85373BZ060
85373-BZ060 Hose, Windshield Washer (from Joint To Nozzle) |
85373-BZ060 |
US $2.33 |
||
|
9004179142
|
9004179142
90041-79142 New Genuine Part |
90041-79142 |
US $1.65 |
||
|
9017908132
|
9017908132
90179-08132 NUT |
90179-08132 |
US $2.15 |
||
|
9162160618
|
9162160618
91621-60618 New Genuine Part |
91621-60618 |
US $1.46 |
||
| replacement | |||||
|
9162160618
|
9162160618
91651-B0620 New Genuine Part |
91651-B0620 |
US $1.25 |
||
