Heating & Air Conditioning - Cooler Piping ([10.1993 - ] (9310- )CM6#,YM6#) Diagram Toyota LITE/ TOWNACE
- Year
- 1986 - 1999
- Sales region
- Japan
- Frame
- YM60
- grade
- SPX
- body
- T1
- ENGINE
- 2Y
- TRANSMISSION
- MTM
- Model
- LITE/TOWNACE TRUCK
- From
- 10.1986
- To
- 06.1999
- Gear Shift Type
- 5F
- Vehicle Model
- LITE/TOWNACE TRUCK
- Deck(Type)
- 1SO
- Building Condition
- CBU
- Deck(Material)
- TS
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
88453
|
88453
88453-28010
Fan, No.2
[10.1986 - 06.1999] CM52,6#,YM6# |
88453-28010 |
— | ||
|
88460
|
88460
88460-27040 Condenser Assy, Cooler[10.1993 - 11.1996] CM65..TS;CM52,60,61,YM6# |
88460-27040 |
US $531.44 |
||
|
88460
|
88460
88460-95722 Condenser Assy, Cooler[10.1986 - 10.1993] CM52,6#,YM6# |
88460-95722 |
US $770.22 |
||
|
88463
|
88463
88463-95700
Bracket, Cooler Condenser, No.1
[10.1986 - 10.1993] CM52,6#,YM6# |
88463-95700 |
— | ||
|
88470
|
88470
88471-20050
Receiver & Dryer Assy, Cooler
[10.1993 - 11.1996] CM65..TS;CM5#,60,61,KM51,YM55,6# |
88471-20050 |
— | ||
| replacement | |||||
|
88470
|
88470
88471-34010 Receiver & Dryer Assy, Cooler[10.1993 - 11.1996] CM65..TS;CM5#,60,61,KM51,YM55,6# |
88471-34010 |
from US $47.25 |
||
|
88470
|
88470
88471-95700 Receiver & Dryer Assy, Cooler[10.1986 - 10.1989] CM6#,YM60 |
88471-95700 |
US $94.64 |
||
| replacement | |||||
|
88470
|
88470
88471-95401
Receiver & Dryer Assy, Cooler
[10.1986 - 10.1989] CM6#,YM60 |
88471-95401 |
— | ||
|
88472
|
88472
88472-27050
Bracket, Receiver Tank, No.1
[10.1993 - 11.1996] CM65..TS;CM52,60,61,YM6# |
88472-27050 |
— | ||
|
88472
|
88472
88472-95709
Bracket, Receiver Tank, No.1
[10.1986 - 10.1993] CM60,65,YM6# |
88472-95709 |
— | ||
|
88479
|
88479
90986-02001
Freon Gas, Air Conditioner (Drum, Cooler Refrigerant)
[11.1987 - 10.1989] CM6#,YM60 ４００Ｇ |
90986-02001 |
— | ||
| replacements | |||||
|
88479
|
88479
90986-02004
Freon Gas, Air Conditioner (Drum, Cooler Refrigerant)
[11.1987 - 10.1989] CM6#,YM60 ４００Ｇ |
90986-02004 |
— | ||
|
88479
|
88479
90986-02005
New Genuine Part
[11.1987 - 10.1989] CM6#,YM60 ４００Ｇ |
90986-02005 |
— | ||
|
88479
|
88479
90986-02004
Freon Gas, Air Conditioner (Drum, Cooler Refrigerant)
[01.1990 - 08.1990] YM60;CM6#,KM51..3FC,3HC,5H ２５０Ｇ |
90986-02004 |
— | ||
|
88479
|
88479
90986-02007 Freon Gas, Air Conditioner (Drum, Cooler Refrigerant)[10.1993 - 11.1996] CM65..TS;CM5#,60,61,KM51,YM55,6# ２５０Ｇ |
90986-02007 |
US $31.42 |
||
|
88479
|
88479
90986-02008 Freon Gas, Air Conditioner (Drum, Cooler Refrigerant)[10.1993 - 11.1996] CM65..TS;CM5#,60,61,KM51,YM55,6# ２００Ｇ |
90986-02008 |
US $25.20 |
||
|
88550
|
88550
88550-87002 Motor Assy, Blower (For Condenser)[10.1986 - 06.1999] CM52,6#,YM6# |
88550-87002 |
US $145.60 |
||
|
88891A
|
88891A
53735-95701 Shutter Sub-Assy, Hot Air, Upper[10.1986 - 10.1993] CM52,6#,YM6# |
53735-95701 |
US $33.49 |
||
|
88891B
|
88891B
88578-95713
Packing B (For Cooler)
[10.1986 - 10.1993] CM52,6#,YM6# |
88578-95713 |
— | ||
|
88891C
|
88891C
88578-95714
Packing C (For Cooler)
[10.1986 - 10.1993] CM52,6#,YM6# |
88578-95714 |
— | ||
|
88891D
|
88891D
53733-95700 Shutter Sub-Assy, Hot Air Side, A Rh[10.1986 - 10.1993] CM52,6#,YM6# |
53733-95700 |
US $14.27 |
||
|
88891E
|
88891E
53737-95702 Shutter Sub-Assy, Hot Air, Lower[10.1986 - 10.1993] CM52,6#,YM6# |
53737-95702 |
US $18.78 |
||
|
88891F
|
88891F
53734-95700 Shutter Sub-Assy, Hot Air Side, A Lh[10.1986 - 08.1990] YM60 |
53734-95700 |
US $11.07 |
||
|
8871814450
|
8871814450
88718-14450
Clamp(For Cooler Refrigerant Pipe), No.1
|
88718-14450 |
— | ||
|
9009120612
|
9009120612
90091-20612
New Genuine Part
|
90091-20612 |
— | ||
| replacement | |||||
|
9009120612
|
9009120612
90091-20642 BOLT WWASHER |
90091-20642 |
US $1.08 |
||
|
9017906032
|
9017906032
90179-06032
Direct
|
90179-06032 |
— | ||
| replacement | |||||
|
9017906032
|
9017906032
90179-06274 Nut |
90179-06274 |
from US $0.70 |
||
|
9017908123
|
9017908123
90179-08123 Nut (For Front Wiper Arm Setting) |
90179-08123 |
from US $0.80 |
||
|
9165160820
|
9165160820
91651-60820
Bolt, Radiator Side Support Plate
|
91651-60820 |
— | ||
| replacement | |||||
|
9165160820
|
9165160820
91651-B0820 Bolt, Radiator Side Support Plate |
91651-B0820 |
from US $0.99 |
||
|
9338516012
|
9338516012
93385-16012 New Genuine Part |
93385-16012 |
US $0.96 |
||
|
9338516020
|
9338516020
93385-16020
New Genuine Part
|
93385-16020 |
— | ||
| replacement | |||||
|
9338516020
|
9338516020
93385-26020 New Genuine Part |
93385-26020 |
US $1.61 |
||
