Brake Master Cylinder ([10.1979 - ] (7910- )LHD) Diagram Toyota LITEACE
- Year
- 1981 - 1982
- Sales region
- Europe
- Frame
- KM20
- grade
- DLX
- body
- WG
- Roof
- SRF
- ENGINE
- 4K
- TRANSMISSION
- MTM
- DESTINATION
- EUR
- Model
- LITEACE
- From
- 08.1981
- To
- 10.1982
- Gear Shift Type
- 4F
- Seating Capacity
- 08S
- Vehicle Model
- LITEACE
- Driver's Position
- LHD
- Building Condition
- CBU
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
47202
|
47202
47220-27012
Reservoir Sub-Assy, Brake Master Cylinder
[01.1981 - 10.1982] KM20..RHD..09S; KM20..VSP..02S;KM20..(03S,05S,07S,08S)..(ARL,EUR) |
47220-27012 |
— | ||
|
47230
|
47230
47230-25020 Cap, Clutch Master Cylinder Reservoir Filler[01.1981 - 10.1982] KM20..VSP..02S;KM20..03S,05S,06S,07S,08S,09S |
47230-25020 |
US $12.52 |
||
|
47233
|
47233
47233-95600 Bracket, Clutch ReservoirRESERVOIR [10.1979 - 10.1982] KM20..VSP..02S;KM20..03S,05S,06S,07S,08S,09S |
47233-95600 |
US $8.44 |
||
|
47236
|
47236
47234-27050
Tube, Reservoir Brake
[10.1979 - 08.1981] KM20..LHD..VSP..EUR;KM20..LHD..(03S,05S,06S,07S,09S) TANDEM MASTER CYLINDER |
47234-27050 |
— | ||
|
47236
|
47236
47234-27070
Tube, Reservoir Brake
[08.1981 - 10.1982] KM20..08S TANDEM MASTER CYLINDER |
47234-27070 |
— | ||
|
47236
|
47236
47234-27110
Tube, Reservoir Brake
[10.1982 - 08.1985] KM20..08S TANDEM MASTER CYLINDER |
47234-27110 |
— | ||
|
47236A
|
47236A
90467-16141
Clip(For Clutch Reservoir Tube)
[10.1979 - 08.1985] CM20,KM20,YM2# |
90467-16141 |
— | ||
|
47237
|
47237
47235-27040
Tube, Reservoir, No.2
[10.1979 - 08.1981] KM20..LHD..VSP..EUR;KM20..LHD..(03S,05S,06S,07S,09S) |
47235-27040 |
— | ||
|
47237
|
47237
47235-27060
Tube, Reservoir, No.2
[08.1981 - 08.1985] KM20..08S |
47235-27060 |
— | ||
|
47299
|
47299
47299-25010 Strainer, Master Cylinder Reservoir[01.1981 - 10.1982] KM20..VSP..02S;KM20..03S,05S,06S,07S,08S,09S |
47299-25010 |
US $5.42 |
||
|
9165640620
|
9165640620
91656-40620
Bolt(For Oil Receiver Pipe)
|
91656-40620 |
— | ||
| replacement | |||||
|
9165640620
|
9165640620
91651-60618 Bolt(For Oil Receiver Pipe) |
91651-60618 |
from US $1.19 |
||
