Meter ([01.1992 - ] (9201- )LHD) Diagram Toyota LITEACE
- Year
- 1992 - 1995
- Sales region
- Europe
- Frame
- YR29
- grade
- STD
- Roof
- MRF
- ENGINE
- 4YEC
- Model
- LITEACE VAN,WAGON
- From
- 01.1992
- To
- 01.1995
- No.of Doors
- 4D
- Seating Capacity
- 02S
- Vehicle Model
- LITEACE VAN,WAGON
- Driver's Position
- LHD
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
83100B
|
83100B
83109-24030 Bulb, Combination Meter, No.1[08.1994 - 01.1995] CR2#,YR2#..LHD 12V 3.4W W(GREEN CAP) |
83109-24030 |
from US $3.14 |
||
|
83100B
|
83100B
83109-95J00 Bulb, Combination Meter, No.1[01.1992 - 08.1994] CR2#,KR2#,YR2#..LHD 14V 3.78W |
83109-95J00 |
US $8.30 |
||
|
83100B
|
83100B
83119-28040 Bulb, Combination Meter, No.1[01.1992 - 08.1994] CR2#,KR2#,YR2#..LHD 14V 3.8W,W(GREEN CAP) |
83119-28040 |
US $1.89 |
||
|
83100B
|
83100B
90981-11018 Bulb, Position Indicator Lamp[01.1992 - 01.1995] KR2#,YR2#..LHD 12V 1.2W W/O SOCKET |
90981-11018 |
from US $2.07 |
||
|
83100B
|
83100B
99132-12034 Bulb, Position Indicator Lamp[01.1992 - 08.1994] CR2#,KR2#,YR2#..LHD 12V 3.4W |
99132-12034 |
from US $1.60 |
||
| replacement | |||||
|
83100B
|
83100B
00234-00158 Bulb, Position Indicator Lamp[01.1992 - 08.1994] CR2#,KR2#,YR2#..LHD 12V 3.4W |
00234-00158 |
US $1.59 |
||
|
83101
|
83101
83101-14040 Socket, Indicator Lamp[01.1992 - 01.1995] KR2#,YR2#..LHD 12V 1.4W BULB |
83101-14040 |
US $2.98 |
||
|
83101
|
83101
83101-20040 Socket, Bulb(For Map Lamp)[01.1992 - 08.1994] CR2#,KR2#,YR2#..LHD 12V 3.4W BULB,BLACK |
83101-20040 |
from US $1.77 |
||
|
83101
|
83101
83101-20070 Socket Sub-Assy, Combination Meter Bulb[01.1992 - 08.1994] CR2#,KR2#,YR2#..LHD 12V 3.4W BULB,GREEN |
83101-20070 |
US $7.84 |
||
|
83110
|
83110
83110-28260 Speedometer Assy[01.1992 - 08.1994] KR2#,YR2#..LHD |
83110-28260 |
US $353.81 |
||
|
83110
|
83110
83110-28261 Speedometer Assy[08.1994 - 01.1995] YR2# |
83110-28261 |
US $353.81 |
||
|
83131E
|
83131E
83131-28080 Lens, MeterMETER [01.1992 - 01.1995] YR2# |
83131-28080 |
US $8.15 |
||
|
83132
|
83132
83132-28200 Case, Combination MeterCOMBINATION METER [01.1992 - 01.1995] CR2#,KR2#,YR2#..LHD |
83132-28200 |
US $58.82 |
||
|
83134
|
83134
83134-28140 Cover, Combination Meter, No.1COMBINATION METER, NO.1 [01.1992 - 01.1995] CR2#,KR2#,YR2#..LHD |
83134-28140 |
US $46.88 |
||
|
83138G
|
83138G
83138-28040 Glass, Combination MeterCOMBINATION METER [01.1992 - 08.1994] KR2#,YR2#..LHD |
83138-28040 |
US $60.28 |
||
|
83145C
|
83145C
83145-89320
Lens, Meter, No.1
[01.1992 - 08.1994] CR2#,KR2#,YR2# |
83145-89320 |
— | ||
|
83145F
|
83145F
83145-28280 Lens, Meter, No.7METER, NO.7 [01.1992 - 01.1995] CR2#,KR2#,YR2#..LHD |
83145-28280 |
US $2.48 |
||
|
83145T
|
83145T
83145-28300 Lens, Meter, No.8METER, NO.8 [01.1992 - 01.1995] CR2#,KR2#,YR2#..LHD |
83145-28300 |
US $8.30 |
||
|
83145U
|
83145U
83145-28320 Lens, Meter, No.9METER, NO.9 [01.1992 - 01.1995] CR2#,KR2#,YR2#..LHD |
83145-28320 |
US $8.30 |
||
|
83243A
|
83243A
83243-28080 Gauge Sub-Assy, Fuel ReceiverFUEL RECEIVER [01.1992 - 08.1994] CR2#,KR2#,YR2#..LHD |
83243-28080 |
US $53.14 |
||
|
83243A
|
83243A
83243-2J060 Gauge Sub-Assy, Fuel ReceiverFUEL RECEIVER [08.1994 - 01.1995] CR2#,YR2#..LHD |
83243-2J060 |
US $58.53 |
||
|
83244
|
83244
83244-28020 Gauge Sub-Assy, Water Temperature ReceiverWATER TEMPERATURE RECEIVER [01.1992 - 08.1994] CR2#,KR2#,YR2#..LHD |
83244-28020 |
US $47.61 |
||
|
83244
|
83244
83244-2J020 Gauge Sub-Assy, Water Temperature ReceiverWATER TEMPERATURE RECEIVER [08.1994 - 01.1995] CR2#,YR2#..LHD |
83244-2J020 |
US $58.53 |
||
|
83247
|
83247
83149-2J200 Plate, Meter CircuitMETER CIRCUIT [08.1994 - 11.1994] YR2# |
83149-2J200 |
US $57.80 |
||
|
83247
|
83247
83247-28300 Plate, Meter CircuitMETER CIRCUIT [01.1992 - 08.1994] KR2#,YR2#..LHD |
83247-28300 |
US $57.80 |
||
|
83247
|
83247
83247-28840 Plate, Meter CircuitMETER CIRCUIT [11.1994 - 01.1995] YR2# |
83247-28840 |
US $57.80 |
||
|
83247C
|
83247C
83247-95N29
Plate Sub-Assy, Combination Meter Circuit, No.3
[01.1992 - 08.1994] KR27;CR2#,KR21,YR2#..LHD |
83247-95N29 |
— | ||
|
83910
|
83910
83910-20420 Clock Assy[01.1992 - 01.1995] CR2#,KR2#,YR2#..LHD |
83910-20420 |
US $410.59 |
||
|
831611E020
|
831611E020
83161-1E020 Case, Combination Meter Mirror, No.1 |
83161-1E020 |
US $0.86 |
||
|
8316120280
|
8316120280
83161-20280 Case, Combination Meter Mirror, No.1 |
83161-20280 |
US $1.69 |
||
|
8316120440
|
8316120440
83161-20440
Case, Combination Meter Mirror, No.1
|
83161-20440 |
— | ||
|
8316120480
|
8316120480
83161-20480 Case, Combination Meter Mirror, No.1 |
83161-20480 |
US $1.46 |
||
|
8316120880
|
8316120880
83161-20880
Case, Combination Meter Mirror, No.1
|
83161-20880 |
— | ||
|
8316121020
|
8316121020
83161-21020 Case, Combination Meter Mirror, No.1 |
83161-21020 |
US $1.02 |
||
|
9356015020
|
9356015020
93560-15020 SCREW |
93560-15020 |
from US $0.52 |
||
|
9356715014
|
9356715014
93567-15014 Direct |
93567-15014 |
US $1.60 |
||
| replacement | |||||
|
9356715014
|
9356715014
93568-55014 Screw |
93568-55014 |
from US $1.12 |
||
