Roof Side Ventilator ([10.1988 - ] (8810- )) Diagram Toyota MARK 2
- Year
- 1988 - 1997
- Sales region
- Japan
- Frame
- GX70
- grade
- LG
- body
- WG
- ENGINE
- 1GFE
- TRANSMISSION
- ATM
- Model
- MARK 2 V,WG
- From
- 10.1988
- To
- 04.1997
- Gear Shift Type
- 4FC
- Vehicle Model
- MARK 2 V,WG
- Fuel Induction
- HTWC
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
62903
|
62903
62903-23010 Duct Sub-Assy, Quarter Ventilator, Rh[10.1988 - 04.1997] GX70,LX76,YX7# |
62903-23010 |
US $26.50 |
||
|
62904
|
62904
62904-23010 Duct Sub-Assy, Quarter Ventilator, Lh[10.1988 - 04.1997] GX70,LX76,YX7# |
62904-23010 |
US $26.50 |
||
|
62905
|
62905
62905-91609 Louver, Quarter Ventilation[10.1988 - 04.1997] GX70 右側 |
62905-91609 |
from US $96.97 |
||
|
62905
|
62905
62906-91609 Louver, Quarter Ventilation[10.1988 - 04.1997] GX70 左側 |
62906-91609 |
from US $97.93 |
||
|
75498A
|
75498A
75498-30010 Clip, Quarter Garnish, No.1[10.1988 - 04.1997] GX70,LX76,YX7# |
75498-30010 |
US $3.93 |
||
|
9017905095
|
9017905095
90179-05095
NUT
|
90179-05095 |
— | ||
| replacement | |||||
|
9017905095
|
9017905095
90179-05004 NUT |
90179-05004 |
from US $2.33 |
||
|
9033906011
|
9033906011
90339-06011
Cap, Front Door Trim Retainer
|
90339-06011 |
— | ||
| replacement | |||||
|
9033906011
|
9033906011
67772-20021 Cap, Front Door Trim Retainer |
67772-20021 |
from US $0.96 |
||
|
9038606008
|
9038606008
90386-06008 BUSH |
90386-06008 |
from US $1.07 |
||
|
9046805011
|
9046805011
90468-05011 Clip(For Front Body Pillar Garnish) |
90468-05011 |
US $2.15 |
||
|
9056204137
|
9056204137
90562-04137 New Genuine Part |
90562-04137 |
US $0.96 |
||
