Brake Tube & Clamp ([10.1996 - ] (9610- )) Diagram Toyota MEGA CRUISER
- Year
- 1996 - 2001
- Sales region
- General
- Frame
- BXD20
- Roof
- SRF
- ENGINE
- 15BFT
- From
- 10.1996
- To
- 10.2001
- Vehicle Model
- Mega Cruiser
Difficulties in parts search?
Parts list
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
47900
|
47900
47900-65010 Valve Assy, Load Sensing W/spring[10.1996 -] BXD20 |
47900-65010 |
US $106.92 |
||
|
47931
|
47931
47931-65020
Bracket, Load Sensing Valve
[10.1996 -] BXD20 |
47931-65020 |
— | ||
|
47933
|
47933
47933-65010 Bracket, Load Sensing Shackle, No.1[10.1996 -] BXD20 |
47933-65010 |
US $11.50 |
||
|
9017908146
|
9017908146
90179-08146
Nut
|
90179-08146 |
— | ||
| replacement | |||||
|
9017908146
|
9017908146
90179-08204 Nut |
90179-08204 |
from US $1.05 |
||
|
9161260850
|
9161260850
91612-60850 Bolt(For Rocker Support Set) |
91612-60850 |
US $1.75 |
||
| replacement | |||||
|
9161260850
|
9161260850
91611-60850 Bolt(For Rocker Support Set) |
91611-60850 |
US $2.15 |
||
|
9165260814
|
9165260814
91652-60814 New Genuine Part |
91652-60814 |
US $1.75 |
||
| replacement | |||||
|
9165260814
|
9165260814
91651-B0814 Bolt with washer |
91651-B0814 |
from US $0.84 |
||
