Front Spring & Shock Absorber ([10.1996 - ] (9610- )) Diagram Toyota MEGA CRUISER
- Year
- 1996 - 2001
- Sales region
- General
- Frame
- BXD20
- Roof
- SRF
- ENGINE
- 15BFT
- From
- 10.1996
- To
- 10.2001
- Vehicle Model
- Mega Cruiser
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
48107
|
48107
48107-65010 Arm Sub-Assy, Anchor, Rh[10.1996 -] BXD20 |
48107-65010 |
US $60.63 |
||
|
48108
|
48108
48108-65010 Arm Sub-Assy, Anchor, Lh[10.1996 -] BXD20 |
48108-65010 |
US $60.63 |
||
|
48161
|
48161
48161-65050
Spring, Torsion Bar, Rh
[10.1996 -] BXD20 |
48161-65050 |
— | ||
|
48162
|
48162
48162-65050
Spring, Torsion Bar, Lh
[10.1996 -] BXD20 |
48162-65050 |
— | ||
|
48173
|
48173
48173-36010 Seat, Anchor Arm Adjuster[10.1996 -] BXD20 |
48173-36010 |
US $8.44 |
||
|
48174
|
48174
48174-65010 Cover, Torsion Bar Dust[10.1996 -] BXD20 |
48174-65010 |
US $12.90 |
||
|
48510
|
48510
48510-65020
Absorber Assy, Shock, Front
[10.1996 -] BXD20 |
48510-65020 |
— | ||
|
48520
|
48520
48510-65020
Absorber Assy, Shock, Front
[10.1996 -] BXD20 |
48510-65020 |
— | ||
|
48532A
|
48532A
48532-65010 Pin, Rear Shock Absorber Pivot[10.1996 - 06.1999] BXD20 |
48532-65010 |
US $14.71 |
||
|
48532A
|
48532A
48532-65011 Pin, Rear Shock Absorber Pivot[06.1999 -] BXD20 |
48532-65011 |
US $12.19 |
||
|
48533B
|
48533B
48533-65010 Pin, Rear Shock Absorber Lower Pivot, Rh[10.1996 -] BXD20 |
48533-65010 |
US $8.67 |
||
|
48635
|
48635
48635-65010 Bush, Upper Arm, Rear[10.1996 - 06.1999] BXD20 |
48635-65010 |
US $9.03 |
||
|
48635
|
48635
48635-65011 Bush, Upper Arm, Rear[06.1999 -] BXD20 |
48635-65011 |
US $7.35 |
||
|
48810
|
48810
48810-65010
Link Assy, Front Stabilizer, Lh
[10.1996 -] BXD20 |
48810-65010 |
— | ||
|
48811
|
48811
48811-65020 Bar, Stabilizer, Front[10.1996 -] BXD20 |
48811-65020 |
US $426.61 |
||
|
48815
|
48815
48815-65020 Bush, Front Stabilizer Bar, No.1[10.1996 -] BXD20 |
48815-65020 |
US $16.95 |
||
|
48820B
|
48820B
48820-65010 Link Assy, Front Stabilizer, Rh[10.1996 -] BXD20 |
48820-65010 |
US $60.13 |
||
|
48823B
|
48823B
48823-65020 Cover, Front Stabilizer Bracket[10.1996 -] BXD20 |
48823-65020 |
US $18.64 |
||
|
48824
|
48824
48824-65020 Bracket, Stabilizer, Front[10.1996 -] BXD20 |
48824-65020 |
US $14.71 |
||
|
9010118006
|
9010118006
90101-18006 New Genuine Part |
90101-18006 |
US $11.53 |
||
|
9017016022
|
9017016022
90170-16022 New Genuine Part |
90170-16022 |
US $2.87 |
||
|
9017018009
|
9017018009
90170-18009 New Genuine Part |
90170-18009 |
US $2.91 |
||
|
9017912047
|
9017912047
90179-12047 Nut(For Front Stabilizer Link) |
90179-12047 |
from US $1.16 |
||
|
9034506014
|
9034506014
90345-06014 Plug (For Ball Joint) |
90345-06014 |
US $1.97 |
||
|
9645100600
|
9645100600
96451-00600 Fitting, Grease Small(For Tail Gate Lock Link) |
96451-00600 |
from US $1.39 |
