Manifold ([10.1996 - ] (9610- )) Diagram Toyota MEGA CRUISER
- Year
- 1996 - 2001
- Sales region
- General
- Frame
- BXD20
- Roof
- SRF
- ENGINE
- 15BFT
- From
- 10.1996
- To
- 10.2001
- Vehicle Model
- Mega Cruiser
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
04175
|
04175
04175-58030 Gasket Kit, Turbocharger[10.1996 -] 15BFT..BXD20 |
04175-58030 |
US $131.04 |
||
|
17021A
|
17021A
90116-08158 Bolt, Stud(For Bearing Housing)[10.1996 -] 15BFT..BXD20 |
90116-08158 |
US $5.56 |
||
|
17021B
|
17021B
90116-06048 Bolt, Stud(For Oil Pan)[10.1996 -] 15BFT..BXD20 |
90116-06048 |
from US $0.65 |
||
|
17025A
|
17025A
90126-08017 Bolt, Stud(For Turbine Housing)[10.1996 -] 15BFT..BXD20 |
90126-08017 |
US $2.77 |
||
|
17141G
|
17141G
90116-10175 Bolt, Stud(For Turbine Housing)[10.1996 -] 15BFT..BXD20 |
90116-10175 |
from US $1.20 |
||
|
17201
|
17201
17201-58050 Turbocharger Sub-Assy[10.1996 -] 15BFT..BXD20 |
17201-58050 |
US $2,839.20 |
||
| replacements | |||||
|
17201
|
17201
17201-58051
Turbocharger Sub-Assy
[10.1996 -] 15BFT..BXD20 |
17201-58051 |
— | ||
|
17201
|
17201
17362-58020 Protector, Actuator Hose[10.1996 -] 15BFT..BXD20 |
17362-58020 |
US $5.68 |
||
|
17201
|
17201
90445-12151 Hose, Actuator[10.1996 -] 15BFT..BXD20 |
90445-12151 |
US $2.91 |
||
|
17201
|
17201
96132-51100 Clip (For Hose)[10.1996 -] 15BFT..BXD20 |
96132-51100 |
from US $1.39 |
||
|
17230A
|
17230A
17230-59115 Repair Actuaor Assy, W/bracketW/BRACKET [10.1996 -] 15BFT..BXD20 |
17230-59115 |
US $359.63 |
||
|
17230B
|
17230B
90201-08081 Washer, Plate(For Repair Actuator Set)[10.1996 -] 15BFT..BXD20 T=0.5 |
90201-08081 |
US $2.51 |
||
|
17230B
|
17230B
90201-08082 Washer, Plate(For Repair Actuator Set)[10.1996 -] 15BFT..BXD20 T=1.0 |
90201-08082 |
US $1.79 |
||
|
17230B
|
17230B
90201-08086 Washer, Plate(For Repair Actuator Set)[10.1996 -] 15BFT..BXD20 T=2.0 |
90201-08086 |
US $1.46 |
||
|
17230B
|
17230B
90201-08087 Washer, Plate(For Repair Actuator Set)[10.1996 -] 15BFT..BXD20 T=3.0 |
90201-08087 |
US $1.89 |
||
|
17230C
|
17230C
91621-60822 Bolt, W/washer(For Repair Actuator Set)[10.1996 -] 15BFT..BXD20 |
91621-60822 |
US $1.61 |
||
|
17294
|
17294
90445-12151 Hose, Actuator[10.1996 -] 15BFT..BXD20 |
90445-12151 |
US $2.91 |
||
|
17294A
|
17294A
96132-41100
Clamp Or Clip(For Radiator Reserve Tank Hose)
[10.1996 -] 15BFT..BXD20 |
96132-41100 |
— | ||
| replacement | |||||
|
17294A
|
17294A
96132-51100 Clip (For Hose)[10.1996 -] 15BFT..BXD20 |
96132-51100 |
from US $1.39 |
||
|
17362D
|
17362D
17362-58020 Protector, Actuator Hose[10.1996 -] 15BFT..BXD20 |
17362-58020 |
US $5.68 |
||
|
9052304002
|
9052304002
90523-04002 RING |
90523-04002 |
US $1.43 |
||
|
9162160818
|
9162160818
91621-60818
Bolt(For Automatic Transmission Case Protector)
|
91621-60818 |
— | ||
| replacement | |||||
|
9162160818
|
9162160818
91651-B0820 Bolt, Radiator Side Support Plate |
91651-B0820 |
from US $0.97 |
||
