Rear Steering Gear (4Ws) ([01.1996 - ] (9601- )) Diagram Toyota MEGA CRUISER
- Year
- 1996 - 1999
- Sales region
- Japan
- Frame
- BXD20
- ENGINE
- 15BFT
- TRANSMISSION
- ATM
- From
- 01.1996
- To
- 06.1999
- Vehicle Model
- Mega Cruiser
- Fuel Induction
- TD
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
43321A
|
43321A
43321-65010 Plate, Upper Ball Joint Dust Cover (For Rear Steering Link)[01.1996 -] BXD20 |
43321-65010 |
US $1.16 |
||
|
45046J
|
45046J
45046-65010 End Sub-Assy, Tie Rod, Rh[01.1996 -] BXD20 |
45046-65010 |
US $63.17 |
||
|
45047A
|
45047A
45047-65010 End Sub-Assy, Tie Rod, Lh[01.1996 -] BXD20 |
45047-65010 |
US $47.04 |
||
|
45060
|
45060
45060-65010 Bracket Assy, Idler Arm W/arm[01.1996 -] BXD20 |
45060-65010 |
US $279.55 |
||
|
45060B
|
45060B
90501-32033 Spring, Compression(For Bracket, Idler Arm)[01.1996 -] BXD20 |
90501-32033 |
US $4.51 |
||
|
45060C
|
45060C
90311-25009 Seal, Type T Oil(For Bracket, Idler Arm)[01.1996 -] BXD20 |
90311-25009 |
from US $2.27 |
||
|
45461B
|
45461B
45461-65030 Rod, Steering Tie[01.1996 -] BXD20 |
45461-65030 |
US $18.05 |
||
|
45466B
|
45466B
45466-36020 Clamp, Steering Relay Rod End[01.1996 -] BXD20 |
45466-36020 |
from US $6.82 |
||
|
45479A
|
45479A
45479-36030 Seal, Dust(For Tie Rod)[01.1996 -] BXD20 |
45479-36030 |
from US $6.19 |
||
|
45481
|
45481
45481-65010
Seal, Steering Idler Arm Bushing Dust(For Front Steering)
[01.1996 -] BXD20 |
45481-65010 |
— | ||
|
45490E
|
45490E
45490-65010 Arm Assy,steering Idler(For Rear Steering)[01.1996 -] BXD20 |
45490-65010 |
US $120.56 |
||
|
45490F
|
45490F
90522-30034 Ring, Set(For Power Steering Rack End Dust Seal)[01.1996 -] BXD20 |
90522-30034 |
US $3.40 |
||
|
45497B
|
45497B
45497-36020 Cap, Idler Arm Bracket[01.1996 -] BXD20 |
45497-36020 |
US $14.27 |
||
|
45902
|
45902
45460-65030 End Sub-Assy, Rear Steering Tie Rod[01.1996 - 02.1997] BXD20 右側 |
45460-65030 |
US $76.02 |
||
|
45902
|
45902
45470-65010 End Sub-Assy, Rear Steering Tie Rod[01.1996 - 02.1997] BXD20 左側 |
45470-65010 |
US $80.08 |
||
| replacement | |||||
|
45902
|
45902
45460-65030 End Sub-Assy, Rear Steering Tie Rod[01.1996 - 02.1997] BXD20 左側 |
45460-65030 |
US $76.02 |
||
|
45904
|
45904
45904-65010
Rod Sub-Assy, Rear Steering Relay
[01.1996 -] BXD20 |
45904-65010 |
— | ||
|
45904A
|
45904A
90522-34002 Ring, Set(For Tie Rod End Dust Seal)[01.1996 -] BXD20 |
90522-34002 |
US $1.79 |
||
|
45922
|
45922
45922-65010 Screw, Rear Steering Gear Pinion Bearing Adjust[01.1996 -] BXD20 |
45922-65010 |
US $1.89 |
||
|
45952
|
45952
45952-65010 Shaft, Rear Steering Angle Ratio Converter[01.1996 -] BXD20 |
45952-65010 |
US $19.92 |
||
|
45987A
|
45987A
45987-65010
Boot, Rear Steering Connecting Shaft
[01.1996 -] BXD20 |
45987-65010 |
— | ||
|
51260
|
51260
51260-65010
Crossmember Assy, Frame, No.6
[01.1996 -] BXD20 |
51260-65010 |
— | ||
|
4547936030
|
4547936030
45479-36030 Seal, Dust(For Tie Rod) |
45479-36030 |
from US $6.19 |
||
|
4547965010
|
4547965010
45479-65010 Seal, Steering Link Joint Dust |
45479-65010 |
US $16.31 |
||
|
9010512208
|
9010512208
90105-12208 Bolt, Hexagon(For Front Disc Brake Caliper) |
90105-12208 |
US $2.87 |
||
|
9010512260
|
9010512260
90105-12260 New Genuine Part |
90105-12260 |
US $4.08 |
||
|
9017114006
|
9017114006
90171-14006 Nut, Castle(For Idler Arm) |
90171-14006 |
US $0.76 |
||
|
9017116050
|
9017116050
90171-16050 Nut, Castle (For Front Lower Ball Joint Setting) |
90171-16050 |
from US $2.79 |
||
|
9017118003
|
9017118003
90171-18003 Nut, Castle(For Relay Rod) |
90171-18003 |
from US $1.10 |
||
|
9017912072
|
9017912072
90179-12072 NUT |
90179-12072 |
US $1.97 |
||
|
9020416001
|
9020416001
90204-16001 Washer(For Center Arm Shaft) |
90204-16001 |
US $3.05 |
||
|
9025204003
|
9025204003
90252-04003 PIN |
90252-04003 |
from US $0.18 |
||
|
9034506014
|
9034506014
90345-06014 Plug (For Ball Joint) |
90345-06014 |
US $1.97 |
||
|
9052234002
|
9052234002
90522-34002 Ring, Set(For Tie Rod End Dust Seal) |
90522-34002 |
US $1.79 |
||
|
9052240001
|
9052240001
90522-40001 Ring, Set (For Dust Cover) |
90522-40001 |
US $1.75 |
||
| replacement | |||||
|
9052240001
|
9052240001
90580-10001 Ring, Set (For Dust Cover) |
90580-10001 |
US $1.79 |
||
|
9116261250
|
9116261250
91162-61250 Bolt, Mounting |
91162-61250 |
US $2.87 |
||
|
9413061200
|
9413061200
94130-61200 Nut |
94130-61200 |
from US $0.95 |
||
|
9413061600
|
9413061600
94130-61600 Nut, Hexagon(for Sector Shaft To Pitman Arm Setting) |
94130-61600 |
US $2.15 |
||
|
9453101200
|
9453101200
94531-01200 WASHER |
94531-01200 |
from US $0.72 |
||
|
9462211600
|
9462211600
94622-11600 WASHER |
94622-11600 |
from US $1.56 |
||
|
9538103225
|
9538103225
95381-03225 PIN COTTER |
95381-03225 |
from US $0.68 |
||
|
9538104028
|
9538104028
95381-04028 PIN |
95381-04028 |
US $2.15 |
||
