Roof Panel & Back Panel ([08.1988 - ] (8808- )YR2#..MRF..GL) Diagram Toyota MODEL-F
- Year
- 1988 - 1990
- Sales region
- General
- Frame
- YR22
- grade
- GL
- Roof
- MRF
- ENGINE
- 4YEC
- TRANSMISSION
- MTM
- DESTINATION
- ARL
- From
- 08.1988
- To
- 01.1990
- Gear Shift Type
- 5F
- Driver's Position
- RHD
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
61243C
|
61243C
61243-87001 Retainer, Roof Side Rail, Outer Rh[08.1988 - 01.1990] YR2#..MRF..GL |
61243-87001 |
US $9.90 |
||
|
61244C
|
61244C
61244-87001 Retainer, Roof Side Rail, Outer Lh[08.1988 - 01.1990] YR2#..MRF..GL |
61244-87001 |
US $9.90 |
||
|
61739C
|
61739C
61739-87001 Seal, Roof Side Inner Plate[08.1988 - 01.1990] YR2#..MRF..GL |
61739-87001 |
US $3.93 |
||
|
63105A
|
63105A
63105-28020 Frame Sub-Assy, Back Door OpeningBACK DOOR OPENING [08.1988 - 01.1990] YR2#..MRF..GL W(TWIN SUN ROOF) |
63105-28020 |
US $310.13 |
||
|
63105A
|
63105A
63105-95D01 Frame Sub-Assy, Back Door OpeningBACK DOOR OPENING [08.1988 - 01.1990] YR2#,31..MRF..GL |
63105-95D01 |
US $170.35 |
||
|
63111
|
63111
63111-87005 Panel, Roof[08.1988 - 01.1990] YR2#,31..MRF |
63111-87005 |
US $1,141.50 |
||
|
63111
|
63111
63111-87007 Panel, Roof[08.1988 - 01.1990] YR2#..MRF..GL W(TWIN SUN ROOF) |
63111-87007 |
US $1,134.22 |
||
|
63123C
|
63123C
63123-95700 Reinforcement, Roof Panel, Rear No.1[08.1988 - 01.1990] YR2#..MRF..GL |
63123-95700 |
US $107.74 |
||
|
63132
|
63132
63102-87005 Panel, Windshield Header, InnerWINDSHIELD HEADER, INNER [08.1988 - 01.1990] YR2#,31..MRF..GL |
63102-87005 |
US $54.75 |
||
|
63132
|
63132
63132-87004 Panel, Windshield Header, Inner[08.1988 - 01.1990] YR2#..DLX;YR22..HRF; YR2#..MRF..GL W(TWIN SUN ROOF) |
63132-87004 |
US $52.85 |
||
|
63159B
|
63159B
63159-95700 Bracket, Sliding Roof, Rear[08.1988 - 01.1990] YR2#..MRF..GL |
63159-95700 |
US $10.63 |
||
|
63201C
|
63201C
63201-87016 Glass Sub-Assy, Tilt RoofTILT ROOF [08.1988 - 01.1990] YR2#..MRF..GL |
63201-87016 |
US $643.55 |
||
|
63201G
|
63201G
63201-87018 Glass Sub-Assy, Sliding RoofSLIDING ROOF [08.1988 - 01.1990] YR2#..MRF..GL *TEM,T=4.0 |
63201-87018 |
US $2,184 |
||
|
63203C
|
63203C
63203-87016 Housing Sub-Assy, Tilt RoofTILT ROOF [08.1988 - 01.1990] YR2#..MRF..GL |
63203-87016 |
US $637.73 |
||
|
63203F
|
63203F
63203-87004
Housing Sub-Assy, Sliding Roof Or Removable Roof
[08.1988 - 01.1990] YR2#..MRF..GL |
63203-87004 |
— | ||
|
63205A
|
63205A
63205-87007 Cable Sub-Assy, Sliding Roof Drive[08.1988 - 01.1990] YR2#..MRF..GL |
63205-87007 |
US $965.33 |
||
|
63207C
|
63207C
63207-87005 Rail Sub-Assy, Tilt Roof Guide[08.1988 - 01.1990] YR2#..MRF..GL |
63207-87005 |
US $481.94 |
||
|
63217E
|
63217E
63217-95702-01 Garnish, Sliding Roof, Front Rh[08.1988 - 01.1990] YR2#..MRF..GL BLACK,TRIM1#,4# |
63217-95702-01 |
US $11.36 |
||
|
63218E
|
63218E
63218-95703-01 Garnish, Sliding Roof, Front Lh[08.1988 - 01.1990] YR2#..MRF..GL BLACK,TRIM1#,4# |
63218-95703-01 |
US $11.65 |
||
|
63228
|
63228
63228-87006 Spacer, Slide Roof Lock, No.1[08.1988 - 01.1990] YR2#..MRF..GL |
63228-87006 |
US $4.66 |
||
|
63230B
|
63230B
63230-95700 Panel Sub-Assy, Roof Wind Deflector[08.1988 - 01.1990] YR2#..MRF..GL |
63230-95700 |
US $54.89 |
||
| replacement | |||||
|
63230B
|
63230B
63230-26010 Panel Assy, Roof Wind Deflector[08.1988 - 01.1990] YR2#..MRF..GL |
63230-26010 |
US $41.06 |
||
|
63234
|
63234
63234-95701 Protector, Slide Roof Housing[08.1988 - 01.1990] YR2#..MRF..GL |
63234-95701 |
US $8.59 |
||
|
63239
|
63239
63239-87002 Stopper, Sliding Roof PanelSLIDING ROOF PANEL [08.1988 - 01.1990] YR2#..MRF..GL..ARL |
63239-87002 |
US $2.77 |
||
|
63251B
|
63251B
63251-87008 Weatherstrip, Tilt Roof, Outer[08.1988 - 01.1990] YR2#..MRF..GL |
63251-87008 |
US $107.74 |
||
|
63254C
|
63254C
63254-95700 Weatherstrip, Slide Roof, Rear[08.1988 - 01.1990] YR2#..MRF..GL |
63254-95700 |
US $7.28 |
||
|
63256C
|
63256C
63256-87002 Seal, Tilt Roof Glass[08.1988 - 01.1990] YR2#..MRF..GL |
63256-87002 |
US $2.18 |
||
|
63260A
|
63260A
63260-87003 Gear Sub-Assy, Sliding Roof Drive[08.1988 - 01.1990] YR2#..MRF..GL |
63260-87003 |
US $607.15 |
||
| replacement | |||||
|
63260A
|
63260A
63260-28060 Gear Sub-Assy, Sliding Roof Drive[08.1988 - 01.1990] YR2#..MRF..GL |
63260-28060 |
US $681.41 |
||
|
63260C
|
63260C
63260-87004 Handle Assy, Tilt Roof Lock[08.1988 - 01.1990] YR2#..MRF..GL |
63260-87004 |
US $42.81 |
||
| replacement | |||||
|
63260C
|
63260C
63260-87007 Handle Assy, Tilt Roof Lock[08.1988 - 01.1990] YR2#..MRF..GL |
63260-87007 |
US $42.08 |
||
|
63261C
|
63261C
63261-95702 Shoe, Sliding Roof, Front[08.1988 - 01.1990] YR2#..MRF..GL |
63261-95702 |
US $19.66 |
||
|
63262
|
63262
63262-95702 Shoe, Sliding Roof, Front[08.1988 - 01.1990] YR2#..MRF..GL |
63262-95702 |
US $19.66 |
||
|
63277C
|
63277C
63277-95701 Shim, Sliding Roof Rail[08.1988 - 01.1990] YR2#..MRF..GL T=1.0 |
63277-95701 |
US $4.08 |
||
|
63285A
|
63285A
63285-87010 Dam, Sliding Roof Housing[08.1988 - 01.1990] YR2#..MRF..GL |
63285-87010 |
US $15.43 |
||
|
63285B
|
63285B
63285-87008 Cover, Sliding Roof Housing Drain[08.1988 - 01.1990] YR2#..MRF..GL |
63285-87008 |
US $8.59 |
||
|
63293B
|
63293B
63293-87001 Protector, Slide Roof Housing[08.1988 - 01.1990] YR2#..MRF..GL |
63293-87001 |
US $8.59 |
||
|
63387A
|
63387A
63387-87001 Bracket, Roof Headlining Holder[08.1988 - 01.1990] YR2#..MRF..GL; YR22..HRF |
63387-87001 |
US $13.54 |
||
|
63605
|
63605
63605-87004 Hinge Sub-Assy, Tilt Roof, Rh[08.1988 - 01.1990] YR2#..MRF..GL |
63605-87004 |
US $19.95 |
||
|
63606
|
63606
63606-87004 Hinge Sub-Assy, Tilt Roof, Lh[08.1988 - 01.1990] YR2#..MRF..GL |
63606-87004 |
US $19.95 |
||
|
63617
|
63617
63617-95700-01 Garnish, Sliding Roof, Rear Rh[08.1988 - 01.1990] YR2#..MRF..GL BLACK,TRIM1#,4# |
63617-95700-01 |
US $11.65 |
||
|
63618
|
63618
63618-95700-01 Garnish, Sliding Roof, Rear Lh[08.1988 - 01.1990] YR2#..MRF..GL BLACK,TRIM1#,4# |
63618-95700-01 |
US $11.65 |
||
|
63619
|
63619
63619-87003 Cover, Tilt Roof Panel[08.1988 - 01.1990] YR2#..MRF..GL |
63619-87003 |
US $13.54 |
||
|
67816
|
67816
67816-87001 Pad, Roof Panel, No.4[08.1988 - 01.1990] YR2#..MRF..GL |
67816-87001 |
US $2.77 |
||
|
6273387201
|
6273387201
62733-87201 Retainer, Quarter Or Side Window Hinge |
62733-87201 |
US $5.60 |
||
|
9004430071
|
9004430071
90044-30071 New Genuine Part |
90044-30071 |
US $1.92 |
||
|
9011906250
|
9011906250
90119-06250 New Genuine Part |
90119-06250 |
US $1.60 |
||
| replacement | |||||
|
9011906250
|
9011906250
91631-40612 New Genuine Part |
91631-40612 |
US $1.75 |
||
|
9016440052
|
9016440052
90164-40052 New Genuine Part |
90164-40052 |
US $1.60 |
||
|
9016845003
|
9016845003
90168-45003 New Genuine Part |
90168-45003 |
US $1.46 |
||
|
9017905095
|
9017905095
90179-05095
NUT
|
90179-05095 |
— | ||
| replacement | |||||
|
9017905095
|
9017905095
90179-05004 NUT |
90179-05004 |
from US $2.08 |
||
|
9017906070
|
9017906070
90179-06070
Nut(For Steering Inter Shaft Dust Seal Cover)
|
90179-06070 |
— | ||
| replacement | |||||
|
9017906070
|
9017906070
90179-06159 Nut, Rear Wiper Link Pivot, No.1 |
90179-06159 |
from US $0.59 |
||
|
9018904070
|
9018904070
90189-04070 New Genuine Part |
90189-04070 |
US $2.08 |
||
|
9018904078
|
9018904078
90189-04078 New Genuine Part |
90189-04078 |
US $1.05 |
||
|
9020205019
|
9020205019
90202-05019 New Genuine Part |
90202-05019 |
US $1.60 |
||
|
9024105010
|
9024105010
90241-05010
New Genuine Part
|
90241-05010 |
— | ||
|
9095001029
|
9095001029
90950-01029
Plug, Hole, No.1(For Dash Panel)
|
90950-01029 |
— | ||
| replacement | |||||
|
9095001029
|
9095001029
90950-01882 Cover, Hole |
90950-01882 |
from US $2.24 |
||
|
9165140814
|
9165140814
91651-40814 BOLT |
91651-40814 |
from US $2.88 |
||
| replacement | |||||
|
9165140814
|
9165140814
90080-11228 New Genuine Part |
90080-11228 |
US $3.20 |
||
|
9324955020
|
9324955020
93249-55020 New Genuine Part |
93249-55020 |
US $0.87 |
||
|
9338515014
|
9338515014
93385-15014 Screw(For Steering Tilt Lever) |
93385-15014 |
US $1.76 |
||
|
9338615012
|
9338615012
93386-15012 New Genuine Part |
93386-15012 |
US $0.87 |
||
|
9354624514
|
9354624514
93546-24514 New Genuine Part |
93546-24514 |
US $0.87 |
||
