Roof Panel & Back Window Glass ([08.1995 - ] (9508- )CP) Diagram Toyota PASEO
- Year
- 1995 - 1999
- Sales region
- General
- Frame
- EL54
- body
- CP
- ENGINE
- 5EFE
- TRANSMISSION
- MTM
- DESTINATION
- EUR
- Model
- PASEO
- From
- 12.1995
- To
- 07.1999
- Vehicle Model
- PASEO
- Driver's Position
- LHD
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
63201G
|
63201G
63201-16100 Glass Sub-Assy, Sliding Roof[08.1995 -] EL54..CP |
63201-16100 |
US $1,285.65 |
||
|
63203H
|
63203H
63203-16090 Housing Sub-Assy, Removable Roof[08.1995 -] EL54..CP |
63203-16090 |
US $374.19 |
||
|
63209
|
63209
63209-16050 Panel Sub-Assy, Roof Wind Deflector[08.1995 -] EL54..CP |
63209-16050 |
US $170.35 |
||
|
63218A
|
63218A
63249-16170 Hose(For Sliding Roof Or Removable Roof Drain)[08.1995 -] EL54..CP FRONT |
63249-16170 |
US $18.78 |
||
| replacement | |||||
|
63218A
|
63218A
63249-21040 Hose, Sliding Roof Drain[08.1995 -] EL54..CP FRONT |
63249-21040 |
US $20.82 |
||
|
63218A
|
63218A
63249-16190 Hose(For Sliding Roof Or Removable Roof Drain)[08.1995 -] EL54..CP REAR |
63249-16190 |
US $19.66 |
||
|
63227
|
63227
63227-17010
Clip, Roof Wind Deflector Panel
[08.1995 -] EL54..CP |
63227-17010 |
— | ||
|
63250
|
63250
63250-16020 Base Assy, Removable Roof Lock[08.1995 -] EL54..CP |
63250-16020 |
US $88.82 |
||
|
63252F
|
63252F
63252-16030 Weatherstrip, Removable Roof, Inner[08.1995 -] EL54..CP |
63252-16030 |
US $84.45 |
||
|
63260
|
63260
63260-16060-B0 Handle Assy, Removable Roof LockREMOVABLE ROOF LOCK [08.1995 -] EL54..CP LT.BLUISH GRAY,TRIM1# |
63260-16060-B0 |
US $151.42 |
||
|
63271
|
63271
63271-16010-B0 Garnish, Removable Roof Lock[08.1995 -] EL54..CP LT.BLUISH GRAY,TRIM1# |
63271-16010-B0 |
US $13.98 |
||
|
63273
|
63273
63273-17040
Case, Removable Roof Hinge, Rh
[08.1995 -] EL54..CP |
63273-17040 |
— | ||
|
63274
|
63274
63274-17040
Case, Removable Roof Hinge, Lh
[08.1995 -] EL54..CP |
63274-17040 |
— | ||
|
63275
|
63275
63275-17010
Holder, Removable Roof Hinge, Rh
[08.1995 -] EL54..CP |
63275-17010 |
— | ||
|
63276
|
63276
63276-17010
Holder, Removable Roof Hinge, Lh
[08.1995 -] EL54..CP |
63276-17010 |
— | ||
|
63277
|
63277
63277-16030 Shim, Sliding Roof Rail[08.1995 -] EL54..CP |
63277-16030 |
US $2.77 |
||
|
63278
|
63278
63278-12010
Seal, Removable Roof Hinge Case
[08.1995 -] EL54..CP |
63278-12010 |
— | ||
|
63280
|
63280
63280-17010 Catch Assy, Removable Roof Auxiliary, Lh[08.1995 -] EL54..CP |
63280-17010 |
US $16.45 |
||
|
63285
|
63285
63285-16030 Hinge, Removable Roof, Rh[08.1995 -] EL54..CP |
63285-16030 |
US $10.19 |
||
|
63286
|
63286
63286-16030 Hinge, Removable Roof, Lh[08.1995 -] EL54..CP |
63286-16030 |
US $10.19 |
||
|
63295B
|
63295B
63295-12020
Pad, Roof Wind Deflector Panel
[08.1995 -] EL54..CP |
63295-12020 |
— | ||
|
63637
|
63637
63637-16010-B0 Garnish, Removable Roof[08.1995 -] EL54..CP LT BLUISH GRAY,TRIM1# |
63637-16010-B0 |
US $33.20 |
||
|
6329716010
|
6329716010
63297-16010 Bolt, Removable Roof Hinge Case |
63297-16010 |
US $12.38 |
||
| replacement | |||||
|
6329716010
|
6329716010
63297-12010
Bolt, Removable Roof Hinge Case
|
63297-12010 |
— | ||
|
9015950074
|
9015950074
90159-50074
New Genuine Part
|
90159-50074 |
— | ||
|
9017906070
|
9017906070
90179-06070
Nut(For Steering Inter Shaft Dust Seal Cover)
|
90179-06070 |
— | ||
| replacement | |||||
|
9017906070
|
9017906070
90179-06159 Nut, Rear Wiper Link Pivot, No.1 |
90179-06159 |
from US $0.57 |
||
|
9046306001
|
9046306001
90463-06001 New Genuine Part |
90463-06001 |
US $13.25 |
||
|
9046714001
|
9046714001
90467-14001 Clip Or Clamp(For Ventilation Hose) |
90467-14001 |
from US $0.67 |
||
| replacement | |||||
|
9046714001
|
9046714001
90466-T0026
Clip Or Clamp(For Ventilation Hose)
|
90466-T0026 |
— | ||
|
9046816009
|
9046816009
90468-16009 Clip(For Ventilation Hose No.2) |
90468-16009 |
US $1.31 |
||
|
9048026020
|
9048026020
90480-26020 Grommet, Sliding Roof Drain |
90480-26020 |
US $1.75 |
||
|
9095001060
|
9095001060
90950-01060
Plug, Hole, No.1(For Dash Panel)
|
90950-01060 |
— | ||
| replacement | |||||
|
9095001060
|
9095001060
90950-01866 Plug, Hole(For Front Door Panel) |
90950-01866 |
from US $1.51 |
||
|
9165140616
|
9165140616
91651-40616 BOLT |
91651-40616 |
from US $0.68 |
||
| replacement | |||||
|
9165140616
|
9165140616
91621-60614 Bolt(For Transaxle & Engine Setting) |
91621-60614 |
from US $1.39 |
||
|
9331925014
|
9331925014
93319-25014 SCREW, W WASHER |
93319-25014 |
US $0.52 |
||
|
9353024010
|
9353024010
93530-24010 New Genuine Part |
93530-24010 |
US $2.18 |
||
|
9353054010
|
9353054010
93530-54010 SCREW |
93530-54010 |
from US $0.65 |
||
|
9616000400
|
9616000400
96160-00400 Ring, E(For Release Arm) |
96160-00400 |
US $0.96 |
||
|
9616000600
|
9616000600
96160-00600 Ring, E(For Clutch Pedal Pawl) |
96160-00600 |
from US $0.82 |
||
