Front Spring & Shock Absorber ([12.2004 - 02.2010] (0412-1002)QNC10..RACY) Diagram Toyota PASSO
- Year
- 2004 - 2010
- Sales region
- Japan
- Frame
- QNC10
- grade
- RACY
- ENGINE
- K3VE
- TRANSMISSION
- ATM
- Model
- PASSO
- From
- 12.2004
- To
- 02.2010
- Gear Shift Type
- 4HC
- Vehicle Model
- PASSO
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
48811
|
48811
48811-B1010 Bar, Stabilizer, Front[12.2004 - 12.2006] QNC10..RACY |
48811-B1010 |
US $139.78 |
||
|
48815
|
48815
48815-B1010 Bush, Front Stabilizer Bar, No.1[12.2004 - 12.2006] QNC10..RACY |
48815-B1010 |
from US $10.62 |
||
|
48819A
|
48819A
48821-B1010
Bolt, Front Stabilizer
[12.2004 - 12.2006] QNC10..RACY 右側 |
48821-B1010 |
— | ||
| replacement | |||||
|
48819A
|
48819A
48821-B1031 Link Assy, Front Stabilizer, Rh[12.2004 - 12.2006] QNC10..RACY 右側 |
48821-B1031 |
US $57.96 |
||
|
48819A
|
48819A
48821-B1030 Bolt, Front Stabilizer[04.2009 - 02.2010] QNC10..RACY 右側 |
48821-B1030 |
US $28.39 |
||
| replacement | |||||
|
48819A
|
48819A
48821-B1031 Link Assy, Front Stabilizer, Rh[04.2009 - 02.2010] QNC10..RACY 右側 |
48821-B1031 |
US $57.96 |
||
|
48819A
|
48819A
48831-B1010
Link Assy, Front Stabilizer, Lh
[12.2004 - 12.2006] QNC10..RACY 左側 |
48831-B1010 |
— | ||
| replacement | |||||
|
48819A
|
48819A
48831-B1021 Link Assy, Front Stabilizer, Lh[12.2004 - 12.2006] QNC10..RACY 左側 |
48831-B1021 |
US $57.96 |
||
|
48819A
|
48819A
48831-B1020 Link Assy, Front Stabilizer, Lh[04.2009 - 02.2010] QNC10..RACY 左側 |
48831-B1020 |
US $28.39 |
||
| replacement | |||||
|
48819A
|
48819A
48831-B1021 Link Assy, Front Stabilizer, Lh[04.2009 - 02.2010] QNC10..RACY 左側 |
48831-B1021 |
US $57.96 |
||
|
48824A
|
48824A
48824-B1010 Bracket, Front Stabilizer, No.1 Rh[12.2004 - 12.2006] QNC10..RACY |
48824-B1010 |
US $7.53 |
||
|
48827
|
48827
48827-B1010 Bracket, Front Stabilizer, No.2 Rh[12.2004 - 12.2006] QNC10..RACY |
48827-B1010 |
US $7.53 |
||
|
48828
|
48828
48827-B1010 Bracket, Front Stabilizer, No.2 Rh[12.2004 - 12.2006] QNC10..RACY |
48827-B1010 |
US $7.53 |
||
|
48829A
|
48829A
48824-B1010 Bracket, Front Stabilizer, No.1 Rh[12.2004 - 12.2006] QNC10..RACY |
48824-B1010 |
US $7.53 |
||
|
9004120085
|
9004120085
90041-20085 Bolt(For Front Stabilizer) |
90041-20085 |
US $1.43 |
||
|
9004170341
|
9004170341
90041-70341 New Genuine Part |
90041-70341 |
US $3.23 |
||
