Heating & Air Conditioning - Cooler Unit ([08.1991 - 08.1993] (9108-9308)RHD) Diagram Toyota PREVIA/ TARAGO
- Year
- 1990 - 1993
- Sales region
- General
- Frame
- TCR21
- grade
- GL
- ENGINE
- 2TZFE
- TRANSMISSION
- ATM
- DESTINATION
- ARL
- From
- 05.1990
- To
- 08.1993
- Seating Capacity
- 07S
- Driver's Position
- RHD
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
88361
|
88361
87105-87004
Fan, Cooler Blower, No.1
[05.1990 - 08.1994] TCR21..ATM;TCR1#..GEN,W |
87105-87004 |
— | ||
|
88501E
|
88501E
88501-95D04
Evapolator Sub-Assy, Cooler (Cool Box)
[05.1990 - 08.1991] TCR1#..W;TCR21..ATM |
88501-95D04 |
— | ||
|
88502
|
88502
88502-28110-03
Case Sub-Assy, Cooling Unit
[05.1990 - 08.1991] TCR21..ATM;TCR11..RHD..W LIGHT GRAY,TRIM1# |
88502-28110-03 |
— | ||
|
88502
|
88502
88502-28110-05
Case Sub-Assy, Cooling Unit
[05.1990 - 08.1991] TCR21..ATM;TCR11..RHD..W LIGHT GRAIGE,TRIM4# |
88502-28110-05 |
— | ||
|
88502
|
88502
88502-28250-B0
Case Sub-Assy, Cooling Unit
[08.1991 - 08.1993] TCR21..ARL;TCR11..RHD..W LIGHT GRAY,TRIM1# |
88502-28250-B0 |
— | ||
|
88502
|
88502
88502-28250-E0
Case Sub-Assy, Cooling Unit
[08.1991 - 08.1993] TCR21..ARL;TCR11..RHD..W LIGHT GREIGE,TRIM4# |
88502-28250-E0 |
— | ||
|
88515C
|
88515C
88515-95700 Valve, Cooler Expansion[08.1991 - 08.1993] TCR21..ARL;TCR11..RHD..W |
88515-95700 |
US $94.64 |
||
|
88520
|
88520
88520-28110-B0
Box Assy, Cooling
[08.1991 - 08.1993] TCR21..ARL;TCR11..RHD..W LIGHT GRAY,TRIM1# |
88520-28110-B0 |
— | ||
|
88520
|
88520
88520-28110-E0
Box Assy, Cooling
[08.1991 - 08.1993] TCR21..ARL;TCR11..RHD..W LIGHT GRAIGE,TRIM4# |
88520-28110-E0 |
— | ||
|
88520
|
88520
88520-95D01-03
Box Assy, Cooling
[05.1990 - 08.1991] TCR21..ATM;TCR11..RHD..W LIGHT GRAY,TRIM1# |
88520-95D01-03 |
— | ||
|
88520
|
88520
88520-95D01-05
Box Assy, Cooling
[05.1990 - 08.1991] TCR21..ATM;TCR11..RHD..W LIGHT GRAIGE,TRIM4# |
88520-95D01-05 |
— | ||
|
88539E
|
88539E
88539-95708
Hose, Cooler Unit Drain, No.1
[05.1990 - 08.1994] TCR21..ATM;TCR1#..GEN,W |
88539-95708 |
— | ||
|
88550B
|
88550B
88550-28010 Motor Assy, Blower[08.1990 - 08.1991] TCR1#..W;TCR21..ATM |
88550-28010 |
US $257.71 |
||
|
88550B
|
88550B
88550-87003 Motor Sub-Assy, Cooler Blower, No.1[05.1990 - 08.1990] TCR1#..W;TCR21..ATM |
88550-87003 |
US $262.08 |
||
|
88610
|
88610
88610-95713
Switch Assy, Cooler Control
[05.1990 - 08.1993] TCR1#..W;TCR21..ATM NO.2 |
88610-95713 |
— | ||
|
88610
|
88610
88610-95D00
Switch Assy, Cooler Control
[05.1990 - 08.1991] TCR1#..W;TCR21..ATM NO.1 |
88610-95D00 |
— | ||
|
88625A
|
88625A
88625-95700
Thermistor, Cooler, No.1
[05.1990 - 08.1991] TCR1#..W;TCR21..ATM |
88625-95700 |
— | ||
|
88649
|
88649
88605-28240
Wiring, Cooler, No.2
[08.1990 - 08.1991] TCR1#..W;TCR21..ATM |
88605-28240 |
— | ||
|
88649
|
88649
88605-95D23
Wiring, Cooler, No.2
[05.1990 - 08.1990] TCR1#..W;TCR21..ATM |
88605-95D23 |
— | ||
| replacement | |||||
|
88649
|
88649
88605-28240
Wiring, Cooler, No.2
[05.1990 - 08.1990] TCR1#..W;TCR21..ATM |
88605-28240 |
— | ||
|
88650C
|
88650C
88650-28120
Amplifier Sub-Assy, Airconditioner
[11.1990 - 08.1994] TCR21..ATM;TCR1#..GEN,W |
88650-28120 |
— | ||
|
88650C
|
88650C
88650-95705
Amplifier Assy, Cooler Stabilizer
[05.1990 - 11.1990] TCR1#..W;TCR21..ATM |
88650-95705 |
— | ||
|
88710H
|
88710H
88710-28150 Tube & Accessory Assy, Air Conditioner[08.1990 - 08.1991] TCR1#..W;TCR21..ATM |
88710-28150 |
US $122.30 |
||
|
88710H
|
88710H
88710-95D07 Tube & Accessory Assy, Air Conditioner[05.1990 - 08.1990] TCR1#..W;TCR21..ATM |
88710-95D07 |
US $122.30 |
||
| replacement | |||||
|
88710H
|
88710H
88710-28150 Tube & Accessory Assy, Air Conditioner[05.1990 - 08.1990] TCR1#..W;TCR21..ATM |
88710-28150 |
US $122.30 |
||
|
88899N
|
88899N
88899-95D00-03
Plate, Cover
[05.1990 - 08.1991] TCR1#..W;TCR21..ATM LIGHT GRAY,TRIM1# |
88899-95D00-03 |
— | ||
| replacement | |||||
|
88899N
|
88899N
88899-95D00-B0
Plate, Cover
[05.1990 - 08.1991] TCR1#..W;TCR21..ATM LIGHT GRAY,TRIM1# |
88899-95D00-B0 |
— | ||
|
88899N
|
88899N
88899-95D00-05
Plate, Cover
[05.1990 - 08.1991] TCR11..W;TCR21..ATM LIGHT GRAIGE,TRIM4# |
88899-95D00-05 |
— | ||
| replacement | |||||
|
88899N
|
88899N
88899-95D00-E2
Plate, Cover
[05.1990 - 08.1991] TCR11..W;TCR21..ATM LIGHT GRAIGE,TRIM4# |
88899-95D00-E2 |
— | ||
|
88899P
|
88899P
88899-95D03-03
Plate, Cover
[05.1990 - 08.1993] TCR21..ATM;TCR11..RHD..W LIGHT GRAY,TRIM1# |
88899-95D03-03 |
— | ||
| replacement | |||||
|
88899P
|
88899P
88899-95D03-B0
Plate, Cover
[05.1990 - 08.1993] TCR21..ATM;TCR11..RHD..W LIGHT GRAY,TRIM1# |
88899-95D03-B0 |
— | ||
|
88899P
|
88899P
88899-95D03-05
Plate, Cover
[05.1990 - 08.1993] TCR21..ATM;TCR11..RHD..W LIGHT GRAIGE,TRIM4# |
88899-95D03-05 |
— | ||
| replacement | |||||
|
88899P
|
88899P
88899-95D03-E2
Plate, Cover
[05.1990 - 08.1993] TCR21..ATM;TCR11..RHD..W LIGHT GRAIGE,TRIM4# |
88899-95D03-E2 |
— | ||
|
8868828410
|
8868828410
88688-28410
Bracket, Cooler Diaphragm
|
88688-28410 |
— | ||
|
8868828420
|
8868828420
88688-28420
Bracket, Cooler Diaphragm
|
88688-28420 |
— | ||
|
8868828450
|
8868828450
88688-28450
Bracket, Cooler Diaphragm
|
88688-28450 |
— | ||
|
8868828460
|
8868828460
88688-28460
Bracket, Cooler Diaphragm
|
88688-28460 |
— | ||
|
8889728060
|
8889728060
88897-28060
Valve, Cooler Magnet
|
88897-28060 |
— | ||
|
9017906130
|
9017906130
90179-06130 Nut |
90179-06130 |
US $2.15 |
||
|
9165140616
|
9165140616
91651-40616 BOLT |
91651-40616 |
from US $0.74 |
||
| replacement | |||||
|
9165140616
|
9165140616
91621-60614 Bolt(For Transaxle & Engine Setting) |
91621-60614 |
from US $1.46 |
||
|
9165540820
|
9165540820
91655-40820
New Genuine Part
|
91655-40820 |
— | ||
| replacement | |||||
|
9165540820
|
9165540820
91653-40820 BOLT, W/WASHER |
91653-40820 |
US $1.97 |
||
|
9354055016
|
9354055016
93540-55016 SCREW |
93540-55016 |
US $1.25 |
||
|
904670500401
|
904670500401
90467-05004-01 Clip, Roof Side Rail Garnish |
90467-05004-01 |
US $1.31 |
||
| replacement | |||||
|
904670500401
|
904670500401
90467-05004-11
Clip(For Luggage Compartment Trim Rear Cover)
|
90467-05004-11 |
— | ||
