Switch & Relay & Computer ([08.2003 - ] ENGINE & TRANSMISSION (0308- )) Diagram Toyota PRIUS
- Year
- 2003 - 2009
- Sales region
- U.S.A.
- Frame
- NHW20
- ENGINE
- 1NZFXE
- DESTINATION
- USA
- Model
- PRIUS
- From
- 08.2003
- To
- 03.2009
- Vehicle Model
- PRIUS
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
83530
|
83530
83530-28020 Switch Assy, Oil Pressure (For Engine)[08.2003 - 11.2005] NHW20 DENSO |
83530-28020 |
from US $26.60 |
||
| replacements | |||||
|
83530
|
83530
83530-60020 Switch Assy, Oil Pressure (For Engine)ＹＡＺＡＫＩ→ＤＥＮＳＯ [08.2003 - 11.2005] NHW20 DENSO |
83530-60020 |
from US $25.55 |
||
|
83530
|
83530
83530-0E010 Switch Assy, Oil Pressure (For Engine)[08.2003 - 11.2005] NHW20 DENSO |
83530-0E010 |
from US $51.25 |
||
|
83530
|
83530
83530-60020 Switch Assy, Oil Pressure (For Engine)ＹＡＺＡＫＩ→ＤＥＮＳＯ [08.2003 - 11.2005] NHW20 YAZAKI |
83530-60020 |
from US $25.55 |
||
|
89465
|
89465
89465-47070 Sensor, Oxygen[08.2003 - 11.2005] NHW20 |
89465-47070 |
from US $164.16 |
||
|
89467B
|
89467B
89467-47010 Sensor, Air Fuel Ratio[08.2003 - 11.2005] NHW20 |
89467-47010 |
from US $224.64 |
||
|
89615
|
89615
89615-20090 Sensor, Knock Control[08.2003 - 11.2005] NHW20 |
89615-20090 |
from US $36.02 |
||
|
8271134310
|
8271134310
82711-34310 Clamp(For Hood Lock Control Cable) |
82711-34310 |
US $2.80 |
||
|
8271542710
|
8271542710
82715-42710 Bracket,wiring Harness Clamp |
82715-42710 |
US $2.80 |
||
|
9017908153
|
9017908153
90179-08153 NUT |
90179-08153 |
from US $0.84 |
||
