Back Up Lamp ([04.1969 - 09.1978] (6904-7809)V) Diagram Toyota PUBLICA
- Year
- 1975 - 1978
- Sales region
- Japan
- Frame
- KP37
- grade
- DLX
- body
- V
- ENGINE
- 3KHJ
- TRANSMISSION
- MTM
- Model
- PUBLICA
- From
- 11.1975
- To
- 09.1978
- Gear Shift Type
- 4F
- Vehicle Model
- PUBLICA
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
81670
|
81670
81670-19045
Lamp Assy, Back-Up, Rh
[01.1972 - 09.1978] KP36,37..V |
81670-19045 |
— | ||
|
81670B
|
81670B
99132-11120 Bulb(For Map Lamp)[06.1973 - 09.1978] KP36,37..V 12V 12W |
99132-11120 |
US $2.77 |
||
|
81671
|
81671
81671-11011 Lens, Back-Up Lamp, RhBACK-UP LAMP, RH [01.1972 - 09.1978] KP36,37..V |
81671-11011 |
US $23.59 |
||
|
81674
|
81674
81672-11011
Gasket, Back-Up Lamp Body, Rh
[01.1972 - 09.1978] KP36,37..V |
81672-11011 |
— | ||
|
81678
|
81678
81678-11011
Shade, Back Up Lamp
[01.1972 - 09.1978] KP36,37..V |
81678-11011 |
— | ||
|
81680
|
81680
81680-19045
Lamp Assy, Back Up, Lh
[01.1972 - 09.1978] KP36,37..V |
81680-19045 |
— | ||
|
81681
|
81681
81681-11011
Lens, Back-Up Lamp, Lh
[01.1972 - 09.1978] KP36,37..V |
81681-11011 |
— | ||
|
81684
|
81684
81682-11011
Gasket, Back Up Lamp Body, Lh
[01.1972 - 09.1978] KP36,37..V |
81682-11011 |
— | ||
|
9018304015
|
9018304015
90183-04015 New Genuine Part |
90183-04015 |
US $2.77 |
||
|
9046707093
|
9046707093
90467-07093
New Genuine Part
|
90467-07093 |
— | ||
|
9321994008
|
9321994008
93219-94008 New Genuine Part |
93219-94008 |
US $1.60 |
||
|
9321994012
|
9321994012
93219-94012 New Genuine Part |
93219-94012 |
US $2.18 |
||
| replacement | |||||
|
9321994012
|
9321994012
93219-64012 New Genuine Part |
93219-64012 |
US $1.60 |
||
|
9321994020
|
9321994020
93219-94020 Moulding, Rear Combination Lamp, Rh |
93219-94020 |
US $2.18 |
||
| replacement | |||||
|
9321994020
|
9321994020
81559-10050 Screw |
81559-10050 |
US $5.73 |
||
|
9351014012
|
9351014012
93510-14012 New Genuine Part |
93510-14012 |
US $1.49 |
||
| replacement | |||||
|
9351014012
|
9351014012
93540-A4014 SCREW TAPPING |
93540-A4014 |
US $0.96 |
||
|
9353014010
|
9353014010
93530-14010 New Genuine Part |
93530-14010 |
US $2.33 |
||
