Clutch Pedal & Flexible Hose ([04.1969 - 12.1971] (6904-7112)UP3#) Diagram Toyota PUBLICA
- Year
- 1969 - 1971
- Sales region
- Japan
- Frame
- UP36
- grade
- DLX
- body
- V
- ENGINE
- 2UC
- TRANSMISSION
- MTM
- Model
- PUBLICA
- From
- 04.1969
- To
- 12.1971
- Gear Shift Type
- 4F
- Vehicle Model
- PUBLICA
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
31301
|
31301
31301-10030
Pedal Sub-Assy, Clutch
[04.1969 - 12.1971] KP3#,UP3#..4F |
31301-10030 |
— | ||
|
31301A
|
31301A
90506-12217
Spring(For Clutch Pedal)
[04.1969 - 11.1971] KP3#,UP3#..4F |
90506-12217 |
— | ||
| replacement | |||||
|
31301A
|
31301A
90506-14393 Spring(For Clutch Pedal)[04.1969 - 11.1971] KP3#,UP3#..4F |
90506-14393 |
US $3.20 |
||
|
31301A
|
31301A
90506-14393 Spring(For Clutch Pedal)[11.1971 - 12.1971] KP3#,UP3#..4F |
90506-14393 |
US $3.20 |
||
|
31301B
|
31301B
90541-06008 Cushion, No.1(For Clutch Pedal)[04.1969 - 12.1971] KP3#,UP3#..4F |
90541-06008 |
from US $1.50 |
||
|
31301C
|
31301C
90386-13007 Bush(For Clutch Pedal)[04.1969 - 12.1971] UP3# |
90386-13007 |
from US $2.45 |
||
|
31301F
|
31301F
90101-06319
Bolt(For Clutch Pedal Stopper)
[04.1969 - 12.1971] KP3#,UP3#..4F |
90101-06319 |
— | ||
|
31321
|
31321
31321-10020
Pad, Clutch Pedal
[04.1969 - 12.1971] UP3# |
31321-10020 |
— | ||
|
31324
|
31324
31302-10010
Shaft, Clutch Pedal
[04.1969 - 12.1971] KP3#,UP3#..4F |
31302-10010 |
— | ||
|
31331
|
31331
31331-10020
Wire, Clutch Release
[04.1969 - 12.1971] UP3# |
31331-10020 |
— | ||
|
31331A
|
31331A
90501-14469
Spring, Compression(For Clutch Release Wire Return)
[04.1969 - 12.1971] UP3# |
90501-14469 |
— | ||
|
31340
|
31340
31340-19075 Cable Assy, Clutch Release[04.1969 - 12.1971] UP3# |
31340-19075 |
US $37.13 |
||
| replacement | |||||
|
31340
|
31340
31340-10080
Cable Assy, Clutch Release
[04.1969 - 12.1971] UP3# |
31340-10080 |
— | ||
|
31340A
|
31340A
96160-01200 Ring, E(For Clutch Release Cable)[04.1969 - 12.1971] UP3# |
96160-01200 |
from US $1.50 |
||
|
31341
|
31341
31341-10020
Bracket, Clutch Cable
[04.1969 - 12.1971] UP3# |
31341-10020 |
— | ||
|
31368
|
31368
31368-10010
Bellcrank, Clutch Release
[04.1969 - 12.1971] UP3# |
31368-10010 |
— | ||
|
31368A
|
31368A
90101-08229
Bolt, Hexagon(For Clutch Release Bellcrank Shaft)
[04.1969 - 12.1971] UP3# |
90101-08229 |
— | ||
|
31368B
|
31368B
90387-08055
Collar(For Clutch Release Bellcrank Shaft)
[04.1969 - 12.1971] UP3# |
90387-08055 |
— | ||
|
31368C
|
31368C
90386-13007 Bush(For Clutch Pedal)[04.1969 - 12.1971] UP3# |
90386-13007 |
from US $2.45 |
||
|
31368D
|
31368D
90301-17011 Ring, O(For Clutch Release Bellcrank)[04.1969 - 02.1971] UP3# |
90301-17011 |
US $5.73 |
||
|
31368D
|
31368D
96710-02018
Ring, O(For Clutch Release Bellcrank)
[02.1971 - 12.1971] UP3# |
96710-02018 |
— | ||
| replacement | |||||
|
31368D
|
31368D
96711-19018
Ring, O(For Clutch Release Bellcrank)
[02.1971 - 12.1971] UP3# |
96711-19018 |
— | ||
|
31368E
|
31368E
90201-08322
Washer, Plate Or Retainer(For Clutch Release Bellcrank)
[04.1969 - 12.1971] UP3# |
90201-08322 |
— | ||
|
31369
|
31369
31369-10010
Bracket, Clutch Release Bellcrank
[04.1969 - 12.1971] UP3# |
31369-10010 |
— | ||
|
31369A
|
31369A
90560-08284
Spacer(For Clutch Release Bellcrank Bracket)
[04.1969 - 12.1971] UP3# |
90560-08284 |
— | ||
|
31391
|
31391
31391-10010
Holder, Clutch Return Spring
[04.1969 - 12.1971] UP3# |
31391-10010 |
— | ||
|
9050614218
|
9050614218
90506-14218
New Genuine Part
|
90506-14218 |
— | ||
|
9411040800
|
9411040800
94110-40800
Nut(For Steering Damper)
|
94110-40800 |
— | ||
| replacement | |||||
|
9411040800
|
9411040800
94130-00802 Nut, No.1 (For Center Support Bearing) |
94130-00802 |
from US $0.87 |
||
|
9411551200
|
9411551200
94115-51200 Nut(For Backing Plate To Steering Knuckle Setting) |
94115-51200 |
US $3.05 |
||
|
9412040600
|
9412040600
94120-40600 Nut, Wire Adjusting, No.1 |
94120-40600 |
US $3.05 |
||
|
9453101200
|
9453101200
94531-01200 WASHER |
94531-01200 |
from US $0.72 |
||
|
9454100800
|
9454100800
94541-00800 New Genuine Part |
94541-00800 |
US $1.79 |
||
