Switch & Relay & Computer ([08.1999 - 10.2006] ﾄﾞｱ,ﾙ-ﾌ & ﾌﾛｱ (9908-0610)BU28#,RZU280,XZU28#) Diagram Toyota QUICK DELIVERY/ URBAN SUPPORTER
- Year
- 1999 - 2004
- Sales region
- Japan
- Frame
- BU280
- grade
- D
- ENGINE
- 4B
- TRANSMISSION
- MTM
- Model
- QUICK DELIVERY 200
- From
- 08.1999
- To
- 06.2004
- Vehicle Model
- QUICK DELIVERY 200
- Fuel Induction
- DSL
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
83320
|
83320
83320-80312 Gage Assy, Fuel Sender[09.2001 - 10.2006] BU28#,XZU28#..DCR,DSL |
83320-80312 |
US $58.24 |
||
| replacement | |||||
|
83320
|
83320
83320-80316 Gage Assy, Fuel Sender[09.2001 - 10.2006] BU28#,XZU28#..DCR,DSL |
83320-80316 |
US $65.66 |
||
|
83320
|
83320
83320-80316 Gage Assy, Fuel Sender[08.1999 - 09.2001] BU28#..DSL |
83320-80316 |
US $65.66 |
||
|
83361
|
83361
83361-20030 Gasket, Fuel Tank Vent[08.1999 - 10.2006] BU28#,XZU28#..DCR,DSL |
83361-20030 |
from US $2.55 |
||
|
84160
|
84160
84170-90D00 Switch Assy, Room Lamp[08.1999 - 10.2006] BU28#,LY228,270,RZU280,XZU28# |
84170-90D00 |
US $54.57 |
||
|
84261B
|
84261B
84261-37010 Junction, Slide Door Control,male[08.1999 - 06.2004] RZU280..D;BU28#..DSL 右側 |
84261-37010 |
US $54.75 |
||
|
84261B
|
84261B
84261-37020 Junction, Slide Door Control,male[08.1999 - 06.2004] RZU280..D;BU28#..DSL 左側 |
84261-37020 |
US $54.75 |
||
|
84262B
|
84262B
84262-37011 Junction, Slide Door Control, Female[08.1999 - 06.2004] RZU280..D;BU28#..DSL |
84262-37011 |
US $53.96 |
||
|
84265
|
84265
84265-37010 Junction, Back Door Male[08.1999 - 03.2003] BU28#,LY228,270 右側 |
84265-37010 |
US $113.57 |
||
| replacement | |||||
|
84265
|
84265
84265-37030 Junction, Back Door Male[08.1999 - 03.2003] BU28#,LY228,270 右側 |
84265-37030 |
US $113.52 |
||
|
84265
|
84265
84265-37020 Junction, Back Door Male[08.1999 - 06.2004] RZU280..D;BU28#..DSL 左側 |
84265-37020 |
US $84.45 |
||
| replacement | |||||
|
84265
|
84265
84265-37030 Junction, Back Door Male[08.1999 - 06.2004] RZU280..D;BU28#..DSL 左側 |
84265-37030 |
US $113.52 |
||
|
84265
|
84265
84265-37030 Junction, Back Door Male[03.2003 - 06.2004] RZU280..D;BU28#..DSL 右側 |
84265-37030 |
US $113.52 |
||
|
84266
|
84266
84266-37010 Junction, Back Door Female[08.1999 - 06.2004] RZU280..D;BU28#..DSL 右側 |
84266-37010 |
US $100.32 |
||
|
84266
|
84266
84266-37020 Junction, Back Door Female[08.1999 - 06.2004] RZU280..D;BU28#..DSL 左側 |
84266-37020 |
US $74.26 |
||
|
84266
|
84266
84266-37030 Junction, Back Door Female[08.1999 - 06.2004] BU280..D..DSL ｱﾘ(ﾘﾔﾜｲﾊﾟ),左側 |
84266-37030 |
US $125.22 |
||
|
84550
|
84550
84550-16060 Switch Assy, Parking Brake[08.1999 - 10.2006] BU28#,LY228,270,RZU280,XZU28# |
84550-16060 |
from US $17.48 |
||
|
84763
|
84763
84763-37010 Plate, Switch[08.1999 - 06.2004] RZU280..D;BU28#..DSL |
84763-37010 |
US $1.60 |
||
|
85940B
|
85940B
85940-37030 Relay Assy, Rear Wiper[08.1999 - 06.2004] BU280..D..DSL |
85940-37030 |
US $149.97 |
||
|
86650B
|
86650B
86650-37050 Buzzer Assy, Reverse Warning[08.1999 - 10.2006] BU28#,XZU28#..DCR,DSL |
86650-37050 |
US $96.20 |
||
|
91611B0816
|
91611B0816
91611-B0816 Bolt |
91611-B0816 |
from US $1.09 |
||
|
91631B0610
|
91631B0610
91631-B0610 BOLTWWASHER |
91631-B0610 |
from US $0.90 |
||
|
91651B0825
|
91651B0825
91651-B0825 Bolt, Hexagon(For Steering Column Bracket) |
91651-B0825 |
from US $0.88 |
||
|
93319A4010
|
93319A4010
93319-A4010 SCREW WWASHER |
93319-A4010 |
from US $0.72 |
||
|
8282137140
|
8282137140
82821-37140 Retainer, Headlamp Harness |
82821-37140 |
US $1.46 |
||
|
9011906548
|
9011906548
90119-06548 BOLT WWASHER |
90119-06548 |
from US $0.74 |
||
|
9015260008
|
9015260008
90152-60008 New Genuine Part |
90152-60008 |
US $1.92 |
||
|
9017906158
|
9017906158
90179-06158 Nut, Rear Wiper Link Pivot, No.2 |
90179-06158 |
from US $0.99 |
||
|
9111140612
|
9111140612
91111-40612
New Genuine Part
|
91111-40612 |
— | ||
|
9165140820
|
9165140820
91651-40820 Bolt |
91651-40820 |
from US $1.06 |
||
|
9331314012
|
9331314012
93313-14012 SCREW |
93313-14012 |
US $0.96 |
||
|
9415080800
|
9415080800
94150-80800 NUT, FLANGE |
94150-80800 |
from US $0.84 |
||
