Clutch Pedal & Flexible Hose ([03.2012 - ] (1203- )) Diagram Toyota QUICK DELIVERY/ URBAN SUPPORTER
- Year
- 2012 - 2012
- Sales region
- Japan
- Frame
- XZU282
- grade
- DLX
- ENGINE
- N04C
- TRANSMISSION
- MTM
- Model
- QUICK DELIVERY 200
- From
- 03.2012
- To
- 12.2012
- Gear Shift Type
- 5H
- Seating Capacity
- 02S
- Vehicle Model
- QUICK DELIVERY 200
- Fuel Induction
- DCR
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
31301
|
31301
31301-37330 Pedal Sub-Assy, Clutch[03.2012 -] XZU282 |
31301-37330 |
US $27.96 |
||
|
31301A
|
31301A
90508-35004 Spring(For Clutch Pedal)[03.2012 -] XZU282 |
90508-35004 |
US $6.81 |
||
|
31301B
|
31301B
90541-06036 Cushion, No.1(For Clutch Pedal)[03.2012 -] XZU282 |
90541-06036 |
from US $0.91 |
||
| replacement | |||||
|
31301B
|
31301B
90541060361
CUSHION
[03.2012 -] XZU282 |
90541060361 |
— | ||
|
31301C
|
31301C
90386-13007 Bush(For Clutch Pedal)[03.2012 -] XZU282 |
90386-13007 |
from US $2.45 |
||
|
31321
|
31321
31321-52010 Pad, Brake Pedal[03.2012 -] XZU282 |
31321-52010 |
from US $1.94 |
||
|
31324
|
31324
91552-81070 Bolt(For Alternator)[03.2012 -] XZU282 |
91552-81070 |
from US $1.48 |
||
|
31324A
|
31324A
90387-10004 Collar, Clutch Pedal Shaft[03.2012 -] XZU282 |
90387-10004 |
from US $3.76 |
||
|
31453A
|
31453A
90240-08006 Pin, W/hole(For Clutch Master Cylinder Push Rod Clevis)[03.2012 -] XZU282 長さ＝２３．５ |
90240-08006 |
from US $1.63 |
||
|
31453B
|
31453B
90386-08033 Bush(For Clutch Master Cylinder Push Rod Clevis)[03.2012 -] XZU282 |
90386-08033 |
from US $1.27 |
||
|
38979A
|
38979A
38979-37120 Bracket, Power Take-Off Clutch Switch[03.2012 -] XZU282 |
38979-37120 |
US $4.22 |
||
|
55107A
|
55107A
55107-37040 Support Sub-Assy, Clutch Pedal[03.2012 -] XZU282 |
55107-37040 |
US $8.59 |
||
|
91641C0612
|
91641C0612
91641-C0612 New Genuine Part |
91641-C0612 |
US $0.87 |
||
|
8411337071
|
8411337071
84113-37071 Bracket, Light Control Rheostat |
84113-37071 |
US $14.56 |
||
|
9046814021
|
9046814021
90468-14021 New Genuine Part |
90468-14021 |
US $1.79 |
||
|
9155180820
|
9155180820
91551-80820 Bolt, W/washer (For Transmission Oil Pump Cover) |
91551-80820 |
from US $0.76 |
||
|
9415181001
|
9415181001
94151-81001 NUT FLANGE |
94151-81001 |
US $1.97 |
||
