Parking Brake & Cable ([03.2012 - ] (1203- )) Diagram Toyota QUICK DELIVERY/ URBAN SUPPORTER
- Year
- 2012 - 2012
- Sales region
- Japan
- Frame
- XZU282
- grade
- DLX
- ENGINE
- N04C
- TRANSMISSION
- MTM
- Model
- QUICK DELIVERY 200
- From
- 03.2012
- To
- 12.2012
- Gear Shift Type
- 5H
- Seating Capacity
- 02S
- Vehicle Model
- QUICK DELIVERY 200
- Fuel Induction
- DCR
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
46501
|
46501
46501-37060 Drum Sub-Assy, Parking Brake[03.2012 - 12.2012] XZU282 |
46501-37060 |
from US $172.67 |
||
|
46501A
|
46501A
90031-01170 Bolt, Serration(For Parking Brake Drum)[03.2012 -] XZU282 |
90031-01170 |
from US $1.29 |
||
|
46503C
|
46503C
46503-37681 Plate Sub-Assy, Parking Brake[03.2012 - 12.2012] XZU282 |
46503-37681 |
US $211.20 |
||
|
46506A
|
46506A
46506-36010 Screw Set, Shoe Adjusting, Rh[03.2012 -] XZU282 |
46506-36010 |
US $23.52 |
||
|
46540
|
46540
46530-37030 Shoe Assy, Parking Brake, Rh Or Center No.1[03.2012 -] XZU282 |
46530-37030 |
US $24.53 |
||
|
46550
|
46550
46530-37030 Shoe Assy, Parking Brake, Rh Or Center No.1[03.2012 -] XZU282 |
46530-37030 |
US $24.53 |
||
|
46550A
|
46550A
90506-18001 Spring, Tension[03.2012 -] XZU282 |
90506-18001 |
US $3.05 |
||
|
46550C
|
46550C
90213-06003 Washer, Type C(For Parking Brake Shoe)[03.2012 -] XZU282 |
90213-06003 |
from US $0.87 |
||
|
46550E
|
46550E
90506-14012 Spring, Tension, No.2(For Parking Brake Shoe Return)[03.2012 -] XZU282 |
90506-14012 |
US $3.94 |
||
|
46555
|
46555
90501-16025 Spring, Brake Shoe Hold Down[03.2012 -] XZU282 |
90501-16025 |
from US $2.74 |
||
|
46556
|
46556
47447-22010 Pin, Shoe Hold Down Spring[03.2012 -] XZU282 |
47447-22010 |
from US $1.31 |
||
|
46557
|
46557
47449-20011 Cup, Brake Shoe Hold Down[03.2012 -] XZU282 |
47449-20011 |
from US $2 |
||
|
46577
|
46577
46577-36010 Cover, Adjusting Cam Hole[03.2012 -] XZU282 |
46577-36010 |
US $7.17 |
||
|
46601
|
46601
46601-37680 Lever Sub-Assy, Parking Brake Shoe[03.2012 -] XZU282 |
46601-37680 |
US $10.39 |
||
|
46612
|
46612
46612-36010 Strut, Parking Brake Shoe Lever[03.2012 -] XZU282 |
46612-36010 |
US $16.13 |
||
|
46612B
|
46612B
90504-10001 Spring, Compression(For Parking Brake Shoe Strut)[03.2012 -] XZU282 |
90504-10001 |
from US $2.51 |
||
|
9011912211
|
9011912211
90119-12211 BOLT WWASHER |
90119-12211 |
from US $1.25 |
||
|
9461311200
|
9461311200
94613-11200 WASHER |
94613-11200 |
US $1.25 |
