Switch & Relay & Computer ([03.2012 - ] ｴﾝｼﾞﾝ (1203- )) Diagram Toyota QUICK DELIVERY/ URBAN SUPPORTER
- Year
- 2012 - 2012
- Sales region
- Japan
- Frame
- XZU282
- grade
- DLX
- ENGINE
- N04C
- TRANSMISSION
- MTM
- Model
- QUICK DELIVERY 200
- From
- 03.2012
- To
- 12.2012
- Gear Shift Type
- 5H
- Seating Capacity
- 02S
- Vehicle Model
- QUICK DELIVERY 200
- Fuel Induction
- DCR
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
55173A
|
55173A
55173-37460 Bracket[03.2012 -] XZU282 |
55173-37460 |
US $29.56 |
||
|
83420
|
83420
S8342-01250 Gage Assy, Water Temperature Sender[03.2012 -] XZU282 |
S8342-01250 |
from US $27.87 |
||
|
83530
|
83530
83530-E0220
Switch Assy, Oil Pressure (For Engine)
[03.2012 - 12.2012] XZU282 |
83530-E0220 |
— | ||
| replacement | |||||
|
83530
|
83530
83530-E0250 SWITCH ASSY OIL[03.2012 - 12.2012] XZU282 |
83530-E0250 |
from US $29.20 |
||
|
89420M
|
89420M
89421-E0050 Sensor Assy, Air Pressure[03.2012 -] XZU282 |
89421-E0050 |
US $83.16 |
||
|
89424G
|
89424G
89424-37020 Switch, Inlet Air Temperature[03.2012 -] XZU282 |
89424-37020 |
US $90.20 |
||
|
89425
|
89425
89425-37310
Sensor, Exhaust Gas Temperature
[03.2012 -] XZU282 |
89425-37310 |
— | ||
|
89425A
|
89425A
89425-37160 Sensor, Exhaust Gas Temperature, No.2[03.2012 -] XZU282 |
89425-37160 |
US $126.28 |
||
|
89425B
|
89425B
89425-37200 Sensor, Exhaust Gas Temperature, No.3[03.2012 -] XZU282 |
89425-37200 |
US $98.40 |
||
|
89425C
|
89425C
89425-37230 Sensor, Exhaust Gas Temperature, No.4[03.2012 -] XZU282 |
89425-37230 |
US $98.40 |
||
|
89458D
|
89458D
89458-E0030 Sensor, Fuel Pressure[03.2012 -] XZU282 |
89458-E0030 |
from US $172.80 |
||
|
89463A
|
89463A
89463-37021 Sensor, Nitrogen Oxides[03.2012 -] XZU282 |
89463-37021 |
US $712.74 |
||
| replacement | |||||
|
89463A
|
89463A
89463-37022 Sensor, Nitrogen Oxides[03.2012 -] XZU282 |
89463-37022 |
US $756.60 |
||
|
89480A
|
89480A
89480-37040 Sensor Assy, Differential Pressure[03.2012 - 12.2012] XZU282 |
89480-37040 |
US $286.40 |
||
|
827153VM31
|
827153VM31
82715-3VM31 Bracket,wiring Harness Clamp |
82715-3VM31 |
US $3.35 |
||
|
827153VM50
|
827153VM50
82715-3VM50 Bracket,wiring Harness Clamp |
82715-3VM50 |
US $4.80 |
||
|
8271148060
|
8271148060
82711-48060 Wire, Fuse To Fuse(for Combustion Heater) |
82711-48060 |
US $2.51 |
||
|
8918837010
|
8918837010
89188-37010 Guide, Steering Control Sensor |
89188-37010 |
US $5.39 |
||
|
9011910883
|
9011910883
90119-10883 New Genuine Part |
90119-10883 |
US $1.43 |
||
|
9155180825
|
9155180825
91551-80825 Bolt(For Cylinder Head Set Sub) |
91551-80825 |
from US $0.78 |
||
|
9415180600
|
9415180600
94151-80600 Nut, Cap(For Cylinder Head Cover) |
94151-80600 |
from US $0.65 |
||
|
9415180800
|
9415180800
94151-80800 Nut (For Transmission Control Cable) |
94151-80800 |
from US $0.78 |
||
|
SH51110614
|
SH51110614
SH511-10614
New Genuine Part
|
SH511-10614 |
— | ||
|
SH55210816
|
SH55210816
SH552-10816 Bolt(For Cylinder Head Cover) |
SH552-10816 |
US $6.27 |
||
|
SZ43010005
|
SZ43010005
SZ430-10005 NR WASHERSOFT 300 500S |
SZ430-10005 |
US $3.76 |
||
|
SZ43014002
|
SZ43014002
SZ430-14002 New Genuine Part |
SZ430-14002 |
US $4.84 |
||
