Back Door Lock & Handle ([05.2004 - ] (0405- )) Diagram Toyota SCION TC
- Year
- 2004 - 2010
- Sales region
- U.S.A.
- Frame
- ANT10
- grade
- G
- body
- LB
- ENGINE
- 2AZFE
- DESTINATION
- USA
- From
- 05.2004
- To
- 07.2010
- Gear Shift Type
- 4FC
- Vehicle Model
- TC
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
68810C
|
68810C
68810-21060 Hinge Assy, Back Door, RhBACK DOOR, RH [05.2004 - 07.2010] ANT10 |
68810-21060 |
US $20.68 |
||
| replacement | |||||
|
68810C
|
68810C
68810-21061 Hinge Assy, Back Door, Rh[05.2004 - 07.2010] ANT10 |
68810-21061 |
US $20.68 |
||
|
68820B
|
68820B
68810-21060 Hinge Assy, Back Door, RhBACK DOOR, RH [05.2004 - 07.2010] ANT10 |
68810-21060 |
US $20.68 |
||
| replacement | |||||
|
68820B
|
68820B
68810-21061 Hinge Assy, Back Door, Rh[05.2004 - 07.2010] ANT10 |
68810-21061 |
US $20.68 |
||
|
68945
|
68945
68945-21040 Bracket, Back Door Damper Stay, Upper RhBACK DOOR DAMPER STAY, UPPER RH [05.2004 -] ANT10 |
68945-21040 |
US $5.53 |
||
|
68946
|
68946
68946-21040 Bracket, Back Door Damper Stay, Upper LhBACK DOOR DAMPER STAY, UPPER LH [05.2004 -] ANT10 |
68946-21040 |
US $5.53 |
||
|
68950C
|
68950C
68950-0W260
Stay Assy, Back Door, Rh
[05.2004 - 11.2004] ANT10 |
68950-0W260 |
— | ||
| replacement | |||||
|
68950C
|
68950C
68950-0W262
Stay Assy, Back Door, Rh
[05.2004 - 11.2004] ANT10 |
68950-0W262 |
— | ||
|
68950C
|
68950C
68950-0W261
Stay Assy, Back Door, Rh
[11.2004 - 10.2006] ANT10 |
68950-0W261 |
— | ||
| replacement | |||||
|
68950C
|
68950C
68950-0W262
Stay Assy, Back Door, Rh
[11.2004 - 10.2006] ANT10 |
68950-0W262 |
— | ||
|
68950C
|
68950C
68950-0W262
Stay Assy, Back Door, Rh
[10.2006 -] ANT10 |
68950-0W262 |
— | ||
|
68960
|
68960
68960-0W250
Stay Assy, Back Door, Lh
[05.2004 - 11.2004] ANT10 |
68960-0W250 |
— | ||
| replacement | |||||
|
68960
|
68960
68960-0W252
Stay Assy, Back Door, Lh
[05.2004 - 11.2004] ANT10 |
68960-0W252 |
— | ||
|
68960
|
68960
68960-0W251
Stay Assy, Back Door, Lh
[11.2004 - 10.2006] ANT10 |
68960-0W251 |
— | ||
| replacement | |||||
|
68960
|
68960
68960-0W252
Stay Assy, Back Door, Lh
[11.2004 - 10.2006] ANT10 |
68960-0W252 |
— | ||
|
68960
|
68960
68960-0W252
Stay Assy, Back Door, Lh
[10.2006 -] ANT10 |
68960-0W252 |
— | ||
|
68961
|
68961
68961-20051 Bolt, Hood Support, No.1[05.2004 -] ANT10 |
68961-20051 |
from US $5.69 |
||
|
69350
|
69350
69350-21110
Lock Assy, Back Door
[05.2004 -] ANT10 |
69350-21110 |
— | ||
|
69430C
|
69430C
69430-20160 Striker Assy, Back Door Lower Lock[05.2004 -] ANT10 |
69430-20160 |
US $19.61 |
||
|
9010506184
|
9010506184
90105-06184 BOLT WASHER BASED |
90105-06184 |
US $1.12 |
||
|
9010506204
|
9010506204
90105-06204 New Genuine Part |
90105-06204 |
US $1.92 |
||
|
9011908061
|
9011908061
90119-08061 BOLT |
90119-08061 |
US $1.12 |
||
|
9014880038
|
9014880038
90148-80038 New Genuine Part |
90148-80038 |
US $1.46 |
||
|
9015980027
|
9015980027
90159-80027 New Genuine Part |
90159-80027 |
US $2.56 |
||
|
9017908096
|
9017908096
90179-08096 NUT |
90179-08096 |
from US $1.46 |
||
| replacement | |||||
|
9017908096
|
9017908096
90080-18061 New Genuine Part |
90080-18061 |
US $4.47 |
||
