Fuel Injection System ([05.1991 - 05.1995] (9105-9505)1UZFE) Diagram Toyota SOARER
- Year
- 1991 - 1996
- Sales region
- Japan
- Frame
- UZZ32
- grade
- GTL
- ENGINE
- 1UZFE
- TRANSMISSION
- ATM
- From
- 05.1991
- To
- 08.1996
- Vehicle Model
- SOARER
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
22202
|
22202
22202-50011
Dash Pot Sub-Assy
[05.1991 - 01.1994] 1UZFE..UZZ3# TYPE A:ｲﾗｽﾄｻﾝｼﾖｳ |
22202-50011 |
— | ||
|
22202
|
22202
22202-50040 Dash Pot Sub-Assy[05.1995 - 09.1997] 1UZFE..UZZ3# |
22202-50040 |
US $75.71 |
||
|
22202
|
22202
22202-50070
Dash Pot Sub-Assy
[01.1994 - 05.1995] 1UZFE..UZZ3# |
22202-50070 |
— | ||
|
22207
|
22207
22207-50030 Cover Sub-Assy, Throttle Body[05.1991 - 05.1995] 1UZFE..UZZ3# ｱﾘ(ﾄﾗｸｼﾖﾝ ｺﾝﾄﾛ-ﾙ) |
22207-50030 |
US $34.94 |
||
|
22210
|
22210
22030-50060 Body Assy, Throttle[05.1991 - 10.1992] 1UZFE..UZZ3# ｱﾘ(ﾄﾗｸｼﾖﾝ ｺﾝﾄﾛ-ﾙ) |
22030-50060 |
US $1,878.24 |
||
| replacement | |||||
|
22210
|
22210
22030-50061 Body Assy, Throttle[05.1991 - 10.1992] 1UZFE..UZZ3# ｱﾘ(ﾄﾗｸｼﾖﾝ ｺﾝﾄﾛ-ﾙ) |
22030-50061 |
US $1,878.24 |
||
|
22210
|
22210
22030-50061 Body Assy, Throttle[10.1992 - 09.1994] 1UZFE..UZZ3# ｱﾘ(ﾄﾗｸｼﾖﾝ ｺﾝﾄﾛ-ﾙ) |
22030-50061 |
US $1,878.24 |
||
|
22210
|
22210
22030-50062 Body Assy, Throttle[09.1994 - 05.1995] 1UZFE..UZZ3# |
22030-50062 |
US $1,878.24 |
||
|
22210
|
22210
22030-50090 Body Assy, Throttle[05.1995 - 09.1997] 1UZFE..UZZ3# |
22030-50090 |
US $1,892.80 |
||
|
22271
|
22271
22271-50010 Gasket, Throttle Body[05.1991 - 09.1997] 1UZFE..UZZ3# |
22271-50010 |
from US $5.13 |
||
|
9007910005
|
9007910005
90079-10005 New Genuine Part |
90079-10005 |
US $1.31 |
||
|
9007910006
|
9007910006
90079-10006 New Genuine Part |
90079-10006 |
US $1.60 |
||
|
9007911022
|
9007911022
90079-11022 New Genuine Part |
90079-11022 |
US $0.96 |
||
|
9007913009
|
9007913009
90079-13009 Screw, Dash Pot Adjusting |
90079-13009 |
US $1.46 |
||
|
9007922006
|
9007922006
90079-22006 New Genuine Part |
90079-22006 |
US $1.46 |
||
|
9007930006
|
9007930006
90079-30006 New Genuine Part |
90079-30006 |
US $1.05 |
||
|
9007930007
|
9007930007
90079-30007 New Genuine Part |
90079-30007 |
US $1.60 |
||
| replacement | |||||
|
9007930007
|
9007930007
90079-30006 New Genuine Part |
90079-30006 |
US $1.05 |
||
|
9007941003
|
9007941003
90079-41003 New Genuine Part |
90079-41003 |
US $1.31 |
||
|
9010508181
|
9010508181
90105-08181
Bolt(For Alternator)
|
90105-08181 |
— | ||
| replacement | |||||
|
9010508181
|
9010508181
91511-J0840 Bolt(For Alternator) |
91511-J0840 |
from US $2.88 |
||
|
9017606019
|
9017606019
90176-06019 Nut (For Rear Wiper Arm Setting) |
90176-06019 |
US $1.76 |
||
|
9017908153
|
9017908153
90179-08153 NUT |
90179-08153 |
from US $0.92 |
||
