Rear Spring & Shock Absorber ([05.1991 - ] (9105- )UZZ32) Diagram Toyota SOARER
- Year
- 1991 - 1996
- Sales region
- Japan
- Frame
- UZZ32
- grade
- GTL
- ENGINE
- 1UZFE
- TRANSMISSION
- ATM
- From
- 05.1991
- To
- 08.1996
- Vehicle Model
- SOARER
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
42304
|
42304
42313-24030 Carrier Sub-Assy, Rear Axle, Rh[05.1991 - 08.1996] UZZ32 |
42313-24030 |
US $164.53 |
||
|
42305
|
42305
42314-24030 Carrier Sub-Assy, Rear Axle, Lh[05.1991 - 08.1996] UZZ32 |
42314-24030 |
US $164.53 |
||
|
43330N
|
43330N
43330-29255 Joint Assy, Lower Ball, Rear Rh[05.1991 - 01.1994] UZZ32 |
43330-29255 |
US $106.29 |
||
|
43330Q
|
43330Q
90171-16004 Nut, Castle (For Front Lower Ball Joint Setting)[05.1991 - 08.1996] UZZ32 |
90171-16004 |
US $3.20 |
||
|
43330R
|
43330R
90105-12227 Bolt (For Rear Lower Ball Joint Rh)[05.1991 - 08.1996] UZZ32 |
90105-12227 |
US $4.22 |
||
|
43340D
|
43340D
43340-29125 Joint Assy, Lower Ball, Rear Lh[05.1991 - 01.1994] UZZ32 |
43340-29125 |
US $106.29 |
||
|
43340E
|
43340E
90171-16004 Nut, Castle (For Front Lower Ball Joint Setting)[05.1991 - 08.1996] UZZ32 |
90171-16004 |
US $3.20 |
||
|
43340F
|
43340F
90105-12227 Bolt (For Rear Lower Ball Joint Rh)[05.1991 - 08.1996] UZZ32 |
90105-12227 |
US $4.22 |
||
|
48075E
|
48075E
48075-24020 Bracket Sub-Assy, Lower Control Arm, No.1[05.1991 - 08.1996] UZZ32 |
48075-24020 |
US $43.10 |
||
|
48076A
|
48076A
48076-24020 Bracket Sub-Assy, Lower Control Arm, No.2[05.1991 - 08.1996] UZZ32 |
48076-24020 |
US $43.10 |
||
|
48194A
|
48194A
48190-24040 Cam, Rear Suspension Camber Adjust, No.1[05.1991 - 08.1996] UZZ32 |
48190-24040 |
US $14.41 |
||
|
48194B
|
48194B
48194-24020 Cam, Rear Suspension Camber Adjust, No.3[05.1991 - 08.1996] UZZ32 |
48194-24020 |
US $10.92 |
||
|
48198R
|
48198R
48198-24020 Cam, Rear Suspension Camber Adjust, No.2[05.1991 - 08.1996] UZZ32 |
48198-24020 |
US $5.82 |
||
|
48516C
|
48516C
48516-24010 Bracket, Rear Shock Absorber, No.1 Rh[07.1991 - 08.1996] UZZ32 |
48516-24010 |
US $2.33 |
||
|
48517A
|
48517A
48516-24010 Bracket, Rear Shock Absorber, No.1 Rh[07.1991 - 08.1996] UZZ32 |
48516-24010 |
US $2.33 |
||
|
48710M
|
48710M
90948-02060 Retainer, Cushion, No.1(For Rear Shock Absorber)[05.1991 - 08.1996] UZZ32 ＮＯ．１ |
90948-02060 |
US $3.68 |
||
|
48710M
|
48710M
90948-02149 Retainer, Cushion, No.1(For Rear Lower Control Arm)[05.1991 - 08.1996] UZZ32 ＮＯ．２ |
90948-02149 |
US $6.41 |
||
|
48710M
|
48710M
90948-02150 Retainer, Cushion, No.1(For Rear Lower Control Arm)[05.1991 - 08.1996] UZZ32 ＮＯ．３ |
90948-02150 |
US $5.82 |
||
|
48710N
|
48710N
94115-71600
Nut(For Front Suspension Lower Arm)
[05.1991 - 08.1996] UZZ32 |
94115-71600 |
— | ||
| replacement | |||||
|
48710N
|
48710N
94130-01602 Nut(For Dust Cover To Steering Knuckle Arm Setting)[05.1991 - 08.1996] UZZ32 |
94130-01602 |
from US $1.07 |
||
|
48710Q
|
48710Q
90105-16043 Bolt(For Rear Lower Control Arm)[05.1991 - 08.1996] UZZ32 |
90105-16043 |
US $6.99 |
||
|
48720B
|
48720B
48720-24040 Arm Assy, Rear Lower Control, Rh No.1[05.1991 - 08.1996] UZZ32 |
48720-24040 |
US $337.79 |
||
|
48730J
|
48730J
48730-24040 Arm Assy, Rear Lower Control, Lh No.1[05.1991 - 08.1996] UZZ32 |
48730-24040 |
US $337.79 |
||
|
48757
|
48757
48757-24020 Attachment, Rear Suspension Arm[05.1991 - 08.1996] UZZ32 |
48757-24020 |
US $4.66 |
||
|
48770A
|
48770A
48770-19025 Arm Assy, Upper Control, Rear Rh[01.1994 - 01.1995] UZZ3#; JZZ30 G ﾊﾟﾂｹ-ｼﾞ OR L ﾊﾟﾂｹ-ｼﾞ |
48770-19025 |
US $446.60 |
||
|
48770A
|
48770A
48770-24020
Arm Assy, Upper Control, Rear Rh
[05.1991 - 01.1994] JZZ30,UZZ3#..GT,GTL,GTTL |
48770-24020 |
— | ||
| replacement | |||||
|
48770A
|
48770A
48770-24050
Arm Assy, Upper Control, Rear Rh
[05.1991 - 01.1994] JZZ30,UZZ3#..GT,GTL,GTTL |
48770-24050 |
— | ||
|
48770C
|
48770C
90119-14040 Bolt(For Rear Upper Control Arm)[05.1991 -] JZZ3#,UZZ3# |
90119-14040 |
US $8.32 |
||
|
48770D
|
48770D
90179-14054 Nut(For Rear Upper Control Arm)[05.1991 -] JZZ3#,UZZ3# |
90179-14054 |
US $4.16 |
||
|
48770E
|
48770E
90179-14015 Nut, Castle (For Front Lower Ball Joint Setting)[05.1991 - 08.1996] JZZ3#,UZZ3# |
90179-14015 |
from US $1.93 |
||
|
48770F
|
48770F
90523-16001 Ring, E(For Rear Upper Control Arm)[05.1991 -] JZZ3#,UZZ3# |
90523-16001 |
US $2.08 |
||
|
48790
|
48790
48790-19025 Arm Assy, Upper Control, Rear Lh[01.1994 - 01.1995] UZZ3#; JZZ30 G ﾊﾟﾂｹ-ｼﾞ OR L ﾊﾟﾂｹ-ｼﾞ |
48790-19025 |
US $446.60 |
||
|
48790
|
48790
48790-24020
Arm Assy, Upper Control, Rear Lh
[05.1991 - 01.1994] JZZ30,UZZ3#..GT,GTL,GTTL |
48790-24020 |
— | ||
| replacement | |||||
|
48790
|
48790
48790-24050 Arm Assy, Upper Control, Rear Lh[05.1991 - 01.1994] JZZ30,UZZ3#..GT,GTL,GTTL |
48790-24050 |
US $536.97 |
||
|
48790A
|
48790A
90179-14015 Nut, Castle (For Front Lower Ball Joint Setting)[05.1991 -] JZZ3#,UZZ3# |
90179-14015 |
from US $1.93 |
||
|
9017914035
|
9017914035
90179-14035
New Genuine Part
|
90179-14035 |
— | ||
|
9020114031
|
9020114031
90201-14031 New Genuine Part |
90201-14031 |
US $3.20 |
||
|
9020116017
|
9020116017
90201-16017 WASHER |
90201-16017 |
from US $1.07 |
||
|
9046816016
|
9046816016
90468-16016 CLIP |
90468-16016 |
from US $1.12 |
||
