Front Axle Housing & Differential ([07.2003 - ] E351 (0307- )5F) Diagram Toyota SOLARA
- Year
- 2003 - 2008
- Sales region
- U.S.A.
- Frame
- ACV30
- grade
- SE
- body
- CP
- ENGINE
- 2AZFE
- DESTINATION
- USA
- From
- 07.2003
- To
- 08.2008
- Gear Shift Type
- 5F
- Vehicle Model
- SOLARA
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
31105D
|
31105D
90311-30006
Seal, Oil, No.1(For Front Transaxle Case)
[07.2003 - 09.2005] ACV30..5F |
90311-30006 |
— | ||
| replacement | |||||
|
31105D
|
31105D
90311-30017 Seal, Oil, No.1(For Front Transaxle Case)OIL, NO.1(FOR FRONT TRANSAXLE CASE) [07.2003 - 09.2005] ACV30..5F |
90311-30017 |
from US $5.20 |
||
|
31105D
|
31105D
90311-30017 Seal, Oil, No.1(For Front Transaxle Case)OIL, NO.1(FOR FRONT TRANSAXLE CASE) [09.2005 - 05.2006] ACV30..5F |
90311-30017 |
from US $5.20 |
||
|
31115C
|
31115C
31115-20071 Case, Front Transaxle(Mtm)FRONT TRANSAXLE(MTM) [03.2005 - 05.2006] ACV30..5F |
31115-20071 |
US $486.30 |
||
|
31115C
|
31115C
31115-20072
Case, Front Transaxle(Mtm)
[05.2008 - 08.2008] ACV30..5F REFER TO ILLUST. |
31115-20072 |
— | ||
|
31115C
|
31115C
31115-28021 Case, Front Transaxle(Mtm)FRONT TRANSAXLE(MTM) [07.2003 - 03.2005] ACV30..5F |
31115-28021 |
US $487.76 |
||
| replacement | |||||
|
31115C
|
31115C
31115-20071 Case, Front Transaxle(Mtm)FRONT TRANSAXLE(MTM) [07.2003 - 03.2005] ACV30..5F |
31115-20071 |
US $486.30 |
||
|
31116F
|
31116F
90311-40025 Oil Seal, Front Drive Shaft, Rh[07.2003 - 09.2005] ACV30..5F |
90311-40025 |
US $4.51 |
||
| replacement | |||||
|
31116F
|
31116F
90311-40036 Seal, Oil, No.2(For Transaxle Case)[07.2003 - 09.2005] ACV30..5F |
90311-40036 |
from US $5.56 |
||
|
31116F
|
31116F
90311-40030 Seal, Oil, No.2(For Transaxle Case)OIL(FOR FRONT TRANSAXLE CASE COVER) [09.2005 - 05.2006] ACV30..5F |
90311-40030 |
US $4.51 |
||
| replacement | |||||
|
31116F
|
31116F
90311-40036 Seal, Oil, No.2(For Transaxle Case)[09.2005 - 05.2006] ACV30..5F |
90311-40036 |
from US $5.56 |
||
|
33143C
|
33143C
33143-28010 Baffle, Front Differential Oil[07.2003 - 05.2006] ACV30..5F |
33143-28010 |
US $2.97 |
||
|
33449
|
33449
33449-20010 Magnet, Transmission[07.2003 - 05.2006] ACV30..5F |
33449-20010 |
US $5.97 |
||
|
33481
|
33481
33481-28050
Gear, Speedometer Drive (Mtm)
[07.2003 - 05.2006] ACV30..5F N=32 |
33481-28050 |
— | ||
|
41221
|
41221
41221-20400 Gear, Front Differential RingFRONT DIFFERENTIAL RING [03.2005 - 05.2006] ACV30..5F |
41221-20400 |
US $151.42 |
||
|
41221
|
41221
41221-28130 Gear, Front Differential RingFRONT DIFFERENTIAL RING [07.2003 - 03.2005] ACV30..5F |
41221-28130 |
US $182 |
||
| replacement | |||||
|
41221
|
41221
41221-20400 Gear, Front Differential RingFRONT DIFFERENTIAL RING [07.2003 - 03.2005] ACV30..5F |
41221-20400 |
US $151.42 |
||
|
41222B
|
41222B
90105-12319 Bolt (For Front Differential Ring Gear Set)[07.2003 - 05.2006] ACV30..5F |
90105-12319 |
US $1.97 |
||
|
41301L
|
41301L
41301-28070 Case Sub-Assy, Front Differential, No.1[07.2003 - 05.2006] ACV30..5F |
41301-28070 |
US $410.59 |
||
|
41311C
|
41311C
90564-56055 Shim (For Front Differential Case Rear)[07.2003 - 05.2006] ACV30..5F T=2.00,MARK 0 |
90564-56055 |
US $3.35 |
||
|
41311C
|
41311C
90564-56056 Shim (For Front Differential Case Rear)[07.2003 - 05.2006] ACV30..5F T=2.05,MARK 1 |
90564-56056 |
US $3.35 |
||
|
41311C
|
41311C
90564-56057 Shim (For Front Differential Case Rear)[07.2003 - 05.2006] ACV30..5F T=2.10,MARK 2 |
90564-56057 |
US $3.35 |
||
|
41311C
|
41311C
90564-56058 Shim (For Front Differential Case Rear)[07.2003 - 05.2006] ACV30..5F T=2.15,MARK 3 |
90564-56058 |
US $3.35 |
||
|
41311C
|
41311C
90564-56059 Shim (For Front Differential Case Rear)[07.2003 - 05.2006] ACV30..5F T=2.20,MARK 4 |
90564-56059 |
US $4.37 |
||
|
41311C
|
41311C
90564-56060 Shim (For Front Differential Case Rear)[07.2003 - 05.2006] ACV30..5F T=2.25,MARK 5 |
90564-56060 |
US $4.37 |
||
|
41311C
|
41311C
90564-56061 Shim (For Front Differential Case Rear)[07.2003 - 05.2006] ACV30..5F T=2.30,MARK 6 |
90564-56061 |
US $4.37 |
||
|
41311C
|
41311C
90564-56062 Shim (For Front Differential Case Rear)[07.2003 - 05.2006] ACV30..5F T=2.35,MARK 7 |
90564-56062 |
US $4.37 |
||
|
41311C
|
41311C
90564-56063 Shim (For Front Differential Case Rear)[07.2003 - 05.2006] ACV30..5F T=2.40,MARK 8 |
90564-56063 |
US $4.37 |
||
|
41311C
|
41311C
90564-56064 Shim (For Front Differential Case Rear)[07.2003 - 05.2006] ACV30..5F T=2.45,MARK 9 |
90564-56064 |
US $4.37 |
||
|
41311C
|
41311C
90564-56065 Shim (For Front Differential Case Rear)[07.2003 - 05.2006] ACV30..5F T=2.50,MARK A |
90564-56065 |
US $4.37 |
||
|
41311C
|
41311C
90564-56066 Shim (For Front Differential Case Rear)[07.2003 - 05.2006] ACV30..5F T=2.55,MARK B |
90564-56066 |
US $4.37 |
||
|
41311C
|
41311C
90564-56067 Shim (For Front Differential Case Rear)[07.2003 - 05.2006] ACV30..5F T=2.60,MARK C |
90564-56067 |
US $4.37 |
||
|
41311C
|
41311C
90564-56068 Shim (For Front Differential Case Rear)[07.2003 - 05.2006] ACV30..5F T=2.65,MARK D |
90564-56068 |
US $4.37 |
||
|
41311C
|
41311C
90564-56069 Shim (For Front Differential Case Rear)[07.2003 - 05.2006] ACV30..5F T=2.70,MARK E |
90564-56069 |
US $4.37 |
||
|
41311C
|
41311C
90564-56070 Shim (For Front Differential Case Rear)[07.2003 - 05.2006] ACV30..5F T=2.75,MARK F |
90564-56070 |
US $4.37 |
||
|
41311C
|
41311C
90564-56071 Shim (For Front Differential Case Rear)[07.2003 - 05.2006] ACV30..5F T=2.80,MARK G |
90564-56071 |
US $4.37 |
||
|
41311C
|
41311C
90564-56072 Shim (For Front Differential Case Rear)[07.2003 - 05.2006] ACV30..5F T=2.85,MARK H |
90564-56072 |
US $4.37 |
||
|
41311E
|
41311E
90366-57001 Bearing(For Rear Differential Case)[07.2003 - 05.2006] ACV30..5F |
90366-57001 |
from US $48.89 |
||
|
41311F
|
41311F
90366-50072 Bearing, Tapered Roller (For Front Differential Case Rear)[07.2003 - 05.2006] ACV30..5F |
90366-50072 |
US $47.88 |
||
|
41331F
|
41331F
41331-12140
Gear, Front Differential Side
[04.2008 - 08.2008] ACV30..5F |
41331-12140 |
— | ||
|
41331F
|
41331F
41331-28020 Gear, Front Differential Side[07.2003 - 05.2006] ACV30..5F |
41331-28020 |
US $55.04 |
||
| replacement | |||||
|
41331F
|
41331F
41331-28040 Gear, Front Differential Side[07.2003 - 05.2006] ACV30..5F |
41331-28040 |
US $50.52 |
||
|
41341F
|
41341F
41341-12090
Pinion, Front Differential
[04.2008 - 08.2008] ACV30..5F |
41341-12090 |
— | ||
|
41341F
|
41341F
41341-28010 Pinion, Front Differential[07.2003 - 05.2006] ACV30..5F |
41341-28010 |
US $31.30 |
||
| replacement | |||||
|
41341F
|
41341F
41341-28030 Pinion, Front Differential[07.2003 - 05.2006] ACV30..5F |
41341-28030 |
US $28.68 |
||
|
41342A
|
41342A
90250-06058 Pin, Straight(For Timing Gear Case)[07.2003 - 05.2006] ACV30 |
90250-06058 |
from US $2.03 |
||
|
41342F
|
41342F
41342-28010 Shaft, Front Differential Pinion, No.1[07.2003 - 05.2006] ACV30..5F |
41342-28010 |
US $19.51 |
||
|
41351F
|
41351F
41351-30060 Washer, Rear Differential Pinion Thrust[07.2003 - 05.2006] ACV30..5F |
41351-30060 |
from US $2.01 |
||
|
41361F
|
41361F
41361-28230 Washer, Front Differential Side Gear Thrust, No.1[07.2003 - 05.2006] ACV30 T=1.0,MARK 1 |
41361-28230 |
US $2.62 |
||
|
41361F
|
41361F
41361-28240 Washer, Front Differential Side Gear Thrust, No.1[07.2003 - 05.2006] ACV30 T=1.1,MARK 2 |
41361-28240 |
US $2.62 |
||
|
41361F
|
41361F
41361-28250 Washer, Front Differential Side Gear Thrust, No.1[07.2003 - 05.2006] ACV30 T=1.2,MARK 3 |
41361-28250 |
US $2.62 |
||
|
41361F
|
41361F
41361-28260 Washer, Front Differential Side Gear Thrust, No.1[07.2003 - 05.2006] ACV30 T=1.3,MARK 4 |
41361-28260 |
US $2.62 |
||
