Valve Body & Oil Strainer (Atm) ([07.2003 - 03.2005] U241E (0307-0503)4FC) Diagram Toyota SOLARA
- Year
- 2003 - 2005
- Sales region
- U.S.A.
- Frame
- ACV30
- grade
- SE
- body
- CP
- ENGINE
- 2AZFE
- DESTINATION
- USA
- From
- 07.2003
- To
- 03.2005
- Gear Shift Type
- 4FC
- Vehicle Model
- SOLARA
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
35195A
|
35195A
35195-21010 Clamp, Transaxle Apply Tube, No.1[07.2003 - 05.2006] ACV30,MCV31..4FC,5FC |
35195-21010 |
US $4.89 |
||
|
35196
|
35196
35196-21010 Clamp, Transaxle Apply Tube, No.2[07.2003 - 05.2006] ACV30,MCV31..4FC,5FC |
35196-21010 |
US $3.06 |
||
|
35251
|
35251
35251-30020 Body, Check Ball[07.2003 - 03.2005] ACV30..4FC |
35251-30020 |
US $14.50 |
||
|
35251A
|
35251A
90080-50308
Spring, Compression (For Check Ball Body)
[07.2003 - 03.2005] ACV30..4FC (L) |
90080-50308 |
— | ||
|
35251A
|
35251A
90501-03005 Spring, Compression (For Check Ball Body)[07.2003 - 03.2005] ACV30..4FC (J) |
90501-03005 |
from US $0.79 |
||
|
35409
|
35409
35409-21010 Spring Sub-Assy, Manual Detent[07.2003 - 03.2005] ACV30..4FC |
35409-21010 |
US $5.39 |
||
|
35599
|
35599
35599-21010 Cover, Manual Detent Spring[07.2003 - 03.2005] ACV30..4FC |
35599-21010 |
US $3.06 |
||
|
35666D
|
35666D
35666-06020
Tube, Brake Apply
[07.2003 - 03.2005] ACV30..4FC (L) |
35666-06020 |
— | ||
|
35666D
|
35666D
35666-32010 Tube, Brake Apply[07.2003 - 03.2005] ACV30..4FC (J) |
35666-32010 |
US $6.99 |
||
|
35882A
|
35882A
35882-06020
Tube, Differential Gear Lube Apply
[07.2003 - 03.2005] ACV30..4FC (L) |
35882-06020 |
— | ||
|
35882A
|
35882A
35882-32020 Tube, Differential Gear Lube Apply[07.2003 - 03.2005] ACV30..4FC (J) |
35882-32020 |
US $4.37 |
||
|
35895
|
35895
35895-06010
Tube, Front Clutch Apply
[07.2003 - 03.2005] ACV30..4FC (L) |
35895-06010 |
— | ||
|
35895
|
35895
35895-21010 Tube, Front Clutch Apply[07.2003 - 03.2005] ACV30..4FC (J) |
35895-21010 |
US $5.39 |
||
|
82125J
|
82125J
82125-06010
Wire, Transmission
[07.2003 - 03.2005] ACV30..4FC (L) |
82125-06010 |
— | ||
|
82125J
|
82125J
82125-28180 Wire, Transmission[07.2003 - 03.2005] ACV30..4FC (J) |
82125-28180 |
US $47.71 |
||
|
82125L
|
82125L
90301-21009 Ring, O(For Transmission Wire)[07.2003 - 03.2005] ACV30..4FC |
90301-21009 |
from US $2.17 |
||
|
91611B0616
|
91611B0616
91611-B0616 Bolt(For Transaxle Case Receiver) |
91611-B0616 |
from US $0.84 |
||
|
3548206010
|
3548206010
35482-06010
Valve, Governor
|
35482-06010 |
— | ||
|
3548221020
|
3548221020
35482-21020 Clamp, Temperature Sensor |
35482-21020 |
US $1.75 |
||
|
9008010164
|
9008010164
90080-10164 New Genuine Part |
90080-10164 |
US $2.67 |
||
|
9008010238
|
9008010238
90080-10238
New Genuine Part
|
90080-10238 |
— | ||
|
9008010244
|
9008010244
90080-10244
New Genuine Part
|
90080-10244 |
— | ||
|
9008011495
|
9008011495
90080-11495
New Genuine Part
|
90080-11495 |
— | ||
|
9008011600
|
9008011600
90080-11600
New Genuine Part
|
90080-11600 |
— | ||
|
9010505023
|
9010505023
90105-05023 New Genuine Part |
90105-05023 |
US $1.02 |
||
|
9010506079
|
9010506079
90105-06079 BOLT |
90105-06079 |
US $0.52 |
||
|
9151180614
|
9151180614
91511-80614 BOLT FLANGE |
91511-80614 |
US $1.25 |
||
|
9161160620
|
9161160620
91611-60620 Screw Or Bolt(For Valve Rocker Shaft Lock) |
91611-60620 |
US $1.61 |
