Front Axle Housing & Differential ([06.1998 - 07.2001] A140E (9806-0107)SXV20..ATM) Diagram Toyota SOLARA
- Year
- 1998 - 2001
- Sales region
- U.S.A.
- Frame
- SXV20
- body
- CP
- ENGINE
- 5SFE
- TRANSMISSION
- ATM
- DESTINATION
- CND
- From
- 06.1998
- To
- 07.2001
- Vehicle Model
- SOLARA
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
33481X
|
33481X
33481-32020 Gear, Speedometer Drive (Mtm)[06.1998 - 07.2001] SXV20..ATM |
33481-32020 |
from US $31.39 |
||
|
41039A
|
41039A
41039-33020 Gear Kit, Differential[06.1998 - 07.2001] SXV20..ATM |
41039-33020 |
US $272.27 |
||
|
41109
|
41109
41109-20011
Cage Sub-Assy, Differential Drive Pinion Bearing
[06.1998 - 07.2001] SXV20..ATM |
41109-20011 |
— | ||
|
41109A
|
41109A
90310-34005 Seal, Oil (For Differential Drive Pinion Bearing Cage)[06.1998 - 07.2001] SXV20..ATM |
90310-34005 |
US $3.58 |
||
|
41109B
|
41109B
90301-65003 Ring, O (For Differential Drive Pinion Bearing Cage)[06.1998 - 07.2001] SXV20..ATM |
90301-65003 |
US $9.26 |
||
|
41109C
|
41109C
90521-76002
Ring, Hole Snap (For Diff. Drive Pinion Bearing Cage)
[06.1998 - 07.2001] SXV20..ATM |
90521-76002 |
— | ||
|
41141F
|
41141F
41141-32041
Retainer, Front Differential Side Bearing
[06.1998 - 07.2001] SXV20..ATM |
41141-32041 |
— | ||
|
41141G
|
41141G
90301-99018 Ring, O(For Front Differential Side Bearing Retainer)[06.1998 - 07.2001] SXV20..ATM |
90301-99018 |
from US $8.06 |
||
|
41141H
|
41141H
90311-35019 Seal, Oil, No.2(For Transaxle Case)[06.1998 - 07.2001] SXV20..ATM |
90311-35019 |
from US $7.17 |
||
|
41141J
|
41141J
91611-60825
Bolt(For Head To Camshaft Bearing Cap)
[06.1998 - 07.2001] SXV20..ATM *8-1.25PX25-25 |
91611-60825 |
— | ||
| replacement | |||||
|
41141J
|
41141J
91611-B0825 Bolt(For Clutch Release Cylinder Setting)[06.1998 - 07.2001] SXV20..ATM *8-1.25PX25-25 |
91611-B0825 |
from US $1.08 |
||
|
41181
|
41181
41181-32012 Cover, Front Differential Carrier[06.1998 - 07.2001] SXV20..ATM |
41181-32012 |
US $198.02 |
||
|
41181B
|
41181B
90080-10153
Bolt (For Front Differential Carrier Cover Setting)
[06.1998 - 07.2001] SXV20..ATM *8-1.25PX29-26.5 |
90080-10153 |
— | ||
|
41181B
|
41181B
90105-08062 Bolt (For Overdrive Case & Transaxle Case Setting)[06.1998 - 07.2001] SXV20..ATM *8-1.25PX29-24 |
90105-08062 |
US $2.34 |
||
|
41181C
|
41181C
90930-03031 Plug, Breather(For Parking Cover)[06.1998 - 07.2001] SXV20..ATM |
90930-03031 |
from US $6.18 |
||
|
41181D
|
41181D
90341-18038 Plug(For Manual Transmission Filler)[06.1998 - 07.2001] SXV20..ATM |
90341-18038 |
from US $3.94 |
||
|
41181E
|
41181E
90341-18021 Plug, Filler(Hv)[06.1998 - 12.2002] MCV20,SXV20..ATM |
90341-18021 |
from US $2.26 |
||
|
41181F
|
41181F
90430-18008 Gasket[06.1998 - 07.2001] SXV20..ATM |
90430-18008 |
from US $0.84 |
||
| replacement | |||||
|
41181F
|
41181F
90430-T0021 Gasket(For Manual Transmission Filler Plug)[06.1998 - 07.2001] SXV20..ATM |
90430-T0021 |
US $0.99 |
||
|
41181G
|
41181G
90430-18008 Gasket[06.1998 - 12.2002] MCV20,SXV20..ATM |
90430-18008 |
from US $0.84 |
||
| replacement | |||||
|
41181G
|
41181G
90430-T0021 Gasket(For Manual Transmission Filler Plug)[06.1998 - 12.2002] MCV20,SXV20..ATM |
90430-T0021 |
US $0.99 |
||
|
41182A
|
41182A
41182-32010 Gasket, Differential Carrier Cover[06.1998 - 07.2001] SXV20..ATM |
41182-32010 |
US $3.32 |
||
|
41211
|
41211
41211-32090 Pinion, Differential Drive[06.1998 - 07.2001] SXV20..ATM |
41211-32090 |
US $266.45 |
||
|
41211A
|
41211A
90366-35084 Bearing, Tapered Roller (For Front Drive Pinion Front)[06.1998 - 07.2001] SXV20..ATM |
90366-35084 |
US $24.11 |
||
|
41211B
|
41211B
90366-40010 Bearing (For Rear Drive Pinion Front)[06.1998 - 07.2001] SXV20..ATM |
90366-40010 |
from US $31.01 |
||
|
41214C
|
41214C
41214-32010 Slinger, Rear Differential Drive Pinion Oil[06.1998 - 07.2001] SXV20..ATM |
41214-32010 |
US $3.20 |
||
|
41221
|
41221
41221-32090 Gear, Front Differential Ring[06.1998 - 07.2001] SXV20 |
41221-32090 |
US $171.81 |
||
|
41222B
|
41222B
90101-11003 Bolt (For Rear Differential Ring Gear Set)[06.1998 - 07.2001] SXV20..ATM |
90101-11003 |
US $0.96 |
||
|
41222F
|
41222F
41222-32010 Plate, Rear Differential Ring Gear Set Bolt Lock[06.1998 - 07.2001] SXV20..ATM |
41222-32010 |
from US $2.06 |
||
|
41231A
|
41231A
90179-20004 Nut(For Counter Driven Gear)[06.1998 - 07.2001] SXV20..ATM |
90179-20004 |
US $4.69 |
||
|
41231F
|
41231F
41231-32010
Spacer, Rear Differential Drive Pinion Bearing
[06.1998 - 07.2001] SXV20..ATM |
41231-32010 |
— | ||
|
41311
|
41311
41301-32071 Case, Front Differential[06.1998 - 05.1999] SXV20..ATM |
41301-32071 |
US $564.93 |
||
|
41311
|
41311
41301-33060 Case, Front Differential[05.1999 - 07.2001] SXV20..ATM |
41301-33060 |
US $569.30 |
||
|
41311C
|
41311C
90564-49001
Shim (For Front Differential Case Rear)
[06.1998 - 07.2001] SXV20..ATM T=1.90,MARK 01 |
90564-49001 |
— | ||
|
41311C
|
41311C
90564-49002 Shim (For Front Differential Case Rear)[06.1998 - 07.2001] SXV20..ATM T=1.95,MARK 02 |
90564-49002 |
US $3.20 |
||
|
41311C
|
41311C
90564-49003 Shim (For Front Differential Case Rear)[06.1998 - 07.2001] SXV20..ATM T=2.00,MARK 03 |
90564-49003 |
US $3.20 |
||
|
41311C
|
41311C
90564-49004 Shim (For Front Differential Case Rear)[06.1998 - 07.2001] SXV20..ATM T=2.05,MARK 04 |
90564-49004 |
US $3.20 |
||
|
41311C
|
41311C
90564-49005 Shim (For Front Differential Case Rear)[06.1998 - 07.2001] SXV20..ATM T=2.10,MARK 05 |
90564-49005 |
US $3.20 |
||
|
41311C
|
41311C
90564-49006 Shim (For Front Differential Case Rear)[06.1998 - 07.2001] SXV20..ATM T=2.15,MARK 06 |
90564-49006 |
US $3.20 |
||
|
41311C
|
41311C
90564-49007 Shim (For Front Differential Case Rear)[06.1998 - 07.2001] SXV20..ATM T=2.20,MARK 07 |
90564-49007 |
US $3.20 |
||
|
41311C
|
41311C
90564-49008
Shim (For Front Differential Case Rear)
[06.1998 - 07.2001] SXV20..ATM T=2.25,MARK 08 |
90564-49008 |
— | ||
|
41311C
|
41311C
90564-49009 Shim (For Front Differential Case Rear)[06.1998 - 07.2001] SXV20..ATM T=2.30,MARK 09 |
90564-49009 |
US $3.20 |
||
|
41311C
|
41311C
90564-49010 Shim (For Front Differential Case Rear)[06.1998 - 07.2001] SXV20..ATM T=2.35,MARK 10 |
90564-49010 |
US $3.20 |
||
|
41311C
|
41311C
90564-49011 Shim (For Front Differential Case Rear)[06.1998 - 07.2001] SXV20..ATM T=2.40,MARK 11 |
90564-49011 |
US $3.20 |
||
|
41311C
|
41311C
90564-49012 Shim (For Front Differential Case Rear)[06.1998 - 07.2001] SXV20..ATM T=2.45,MARK 12 |
90564-49012 |
US $3.20 |
||
|
41311C
|
41311C
90564-49013 Shim (For Front Differential Case Rear)[06.1998 - 07.2001] SXV20..ATM T=2.50,MARK 13 |
90564-49013 |
US $3.20 |
||
|
41311C
|
41311C
90564-49014 Shim (For Front Differential Case Rear)[06.1998 - 07.2001] SXV20..ATM T=2.55,MARK 14 |
90564-49014 |
US $3.20 |
||
|
41311C
|
41311C
90564-49015 Shim (For Front Differential Case Rear)[06.1998 - 07.2001] SXV20..ATM T=2.60,MARK 15 |
90564-49015 |
US $3.20 |
||
|
41311C
|
41311C
90564-49016
Shim (For Front Differential Case Rear)
[06.1998 - 07.2001] SXV20..ATM T=2.65,MARK 16 |
90564-49016 |
— | ||
|
41311C
|
41311C
90564-49017 Shim (For Front Differential Case Rear)[06.1998 - 07.2001] SXV20..ATM T=2.70,MARK 17 |
90564-49017 |
US $3.20 |
||
|
41311C
|
41311C
90564-49018 Shim (For Front Differential Case Rear)[06.1998 - 07.2001] SXV20..ATM T=2.75,MARK 18 |
90564-49018 |
US $3.20 |
||
|
41311C
|
41311C
90564-49019 Shim (For Front Differential Case Rear)[06.1998 - 07.2001] SXV20..ATM T=2.80,MARK 19 |
90564-49019 |
US $3.20 |
||
|
41311D
|
41311D
90564-45011 Shim(For Rear Differential Case)[06.1998 - 07.2001] SXV20 T=2.40,MARK 11 |
90564-45011 |
US $3.93 |
||
|
41311E
|
41311E
90366-40016 Bearing(For Rear Differential Case)[06.1998 - 07.2001] SXV20 |
90366-40016 |
from US $25.33 |
||
|
41311F
|
41311F
90366-44001 Bearing(For Rear Differential Case)[06.1998 - 07.2001] SXV20..ATM |
90366-44001 |
from US $25.33 |
||
|
41342A
|
41342A
90250-06058 Pin, Straight(For Timing Gear Case)[06.1998 - 12.2002] MCV20..ATM;ACV20,SXV20 |
90250-06058 |
from US $2.03 |
||
|
41342F
|
41342F
41342-32020
Shaft, Rear Differential Pinion
[06.1998 - 07.2001] SXV20 |
41342-32020 |
— | ||
| replacement | |||||
|
41342F
|
41342F
41342-52060 Shaft, Front Differential Pinion, No.1[06.1998 - 07.2001] SXV20 |
41342-52060 |
US $15.03 |
||
|
41351F
|
41351F
41351-32010 Washer, Rear Differential Pinion Thrust[06.1998 - 07.2001] SXV20 |
41351-32010 |
from US $1.29 |
||
|
41361F
|
41361F
41361-17010 Washer, Rear Differential Side Gear Thrust, No.1[06.1998 - 07.2001] SXV20..ATM T=0.95 |
41361-17010 |
US $3.14 |
||
|
41361F
|
41361F
41361-17020 Washer, Rear Differential Side Gear Thrust, No.1[06.1998 - 07.2001] SXV20..ATM T=1.00 |
41361-17020 |
US $2.62 |
||
|
41361F
|
41361F
41361-17030 Washer, Rear Differential Side Gear Thrust, No.1[06.1998 - 07.2001] SXV20..ATM T=1.05 |
41361-17030 |
US $2.62 |
||
|
41361F
|
41361F
41361-17040 Washer, Rear Differential Side Gear Thrust, No.1[06.1998 - 07.2001] SXV20..ATM T=1.10 |
41361-17040 |
US $2.62 |
||
|
41361F
|
41361F
41361-17050 Washer, Rear Differential Side Gear Thrust, No.1[06.1998 - 07.2001] SXV20..ATM T=1.15 |
41361-17050 |
US $2.62 |
||
|
41361F
|
41361F
41361-17060 Washer, Rear Differential Side Gear Thrust, No.1[06.1998 - 07.2001] SXV20..ATM T=1.20 |
41361-17060 |
US $2.62 |
||
|
9151161035
|
9151161035
91511-61035
Bolt(For Transaxle Case & Engine Setting)
|
91511-61035 |
— | ||
| replacement | |||||
|
9151161035
|
9151161035
91512-61035 Bolt(For Transaxle Case & Engine Setting) |
91512-61035 |
from US $0.95 |
||
