Front Door Lock & Handle ([07.2015 - ] PASSENGER SIDE (1507- )) Diagram Toyota SPADE
- Year
- 2015 - 2018
- Sales region
- General
- Frame
- NSP141
- grade
- F
- ENGINE
- 2NRFKE
- TRANSMISSION
- CVT
- DESTINATION
- HON
- From
- 07.2015
- Vehicle Model
- SPADE
- Driver's Position
- RHD
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
68058
|
68058
68058-52010 Guide Sub-Assy, Fr Side Door[07.2015 -] NSP141 |
68058-52010 |
US $12.67 |
||
|
69060B
|
69060B
69060-52270 Lock Assy, Slide Door Full Open Stop, No.1 Lh[07.2015 -] NSP141 |
69060-52270 |
US $59.70 |
||
|
69120A
|
69120A
69140-58020 Actuator Assy, Front Door Lock, LhREAR DOOR LOCK, LH [07.2015 -] NSP141 |
69140-58020 |
US $128.76 |
||
|
69180B
|
69180B
69180-52030 Control Assy, Slide Door Half Open Stoper[07.2015 -] NSP141 |
69180-52030 |
US $39.40 |
||
|
69202
|
69202
69204-52110 Handle Sub-Assy, Door Outside, Lh[07.2015 -] NSP141 |
69204-52110 |
US $59.74 |
||
|
69206B
|
69206B
69208-58020-E1 Handle Sub-Assy, Front Door Inside, Lh[07.2015 -] NSP141..F PLUM,TRIM0#,4#; NSP141..Y PLUM,TRIM4# |
69208-58020-E1 |
US $43.24 |
||
|
69217F
|
69217F
69227-28050-B8 Cover, Front Door Outside Handle, Lh[07.2015 -] NSP141 SILVER ME.,070 ,1F7 ,209 ,221 ,3P0 ,3R9 ,4U3 ,588 ,5B8 ,6W2 ,8S1 ,8T7 |
69227-28050-B8 |
US $15.68 |
||
|
69220
|
69220
69213-28010-B8 Handle Assy, Front Door Outside, Lh[07.2015 -] NSP141 SILVER ME.,070 ,1F7 ,209 ,221 ,3P0 ,3R9 ,4U3 ,588 ,5B8 ,6W2 ,8S1 ,8T7 |
69213-28010-B8 |
US $32.53 |
||
|
69242C
|
69242C
69241-28060 Pad, Front Door Outside Handle, Rh[07.2015 -] NSP141 |
69241-28060 |
from US $0.90 |
||
|
69242H
|
69242H
69242-60030 Pad, Front Door Outside Handle, Lh[07.2015 -] NSP141 |
69242-60030 |
from US $6.81 |
||
|
69293H
|
69293H
69293-30030 Snap, Front Door Outside Handle[07.2015 -] NSP141 |
69293-30030 |
US $4.32 |
||
|
69294B
|
69294B
69293-12030 Snap, Front Door Outside Handle[07.2015 -] NSP141 |
69293-12030 |
from US $2.09 |
||
|
69300C
|
69300C
69300-52061 Lock Assy, Power Slide Door, No.1 Lh[07.2015 -] NSP141 |
69300-52061 |
US $376.60 |
||
|
69380E
|
69380E
69380-52060 Lock Assy, Slide Door, Front Lh[07.2015 -] NSP141 |
69380-52060 |
US $59.70 |
||
|
69420C
|
69420C
69420-52011 Plate Assy, Door Lock Striker[07.2015 -] NSP141 |
69420-52011 |
US $13.48 |
||
|
69440C
|
69440C
69440-52010 Plate Assy, Slide Door Front Lock Striker[07.2015 -] NSP141 |
69440-52010 |
US $16.87 |
||
|
69470F
|
69470F
69470-28120 Plate Assy, Slide Door Lock Striker[07.2015 -] NSP141 |
69470-28120 |
US $17.63 |
||
|
69480A
|
69480A
69481-52020 Hook Assy, Slide Door Front Lock[07.2015 -] NSP141 |
69481-52020 |
US $12.93 |
||
|
69486F
|
69486F
69486-52040 Striker, Slide Door Open, Lh[07.2015 -] NSP141 |
69486-52040 |
US $19.66 |
||
|
69490F
|
69490F
69490-52030 Stoper Assy, Slide Door Half Open[07.2015 -] NSP141 |
69490-52030 |
US $37.71 |
||
|
69620A
|
69620A
69640-52060 Control Assy, Front Door Lock Remote, Lh[07.2015 -] NSP141 |
69640-52060 |
US $154.34 |
||
|
69730G
|
69730G
69730-52200 Cable Assy, Side Door Lock Remote Control, No.1[07.2015 -] NSP141 |
69730-52200 |
US $21.99 |
||
|
69730H
|
69730H
69730-52210 Cable Assy, Side Door Lock Remote Control, No.2[07.2015 -] NSP141 |
69730-52210 |
US $18.93 |
||
|
69730J
|
69730J
69730-52221 Cable Assy, Side Door Lock Remote Control, No.3[07.2015 -] NSP141 |
69730-52221 |
US $18.93 |
||
|
69730K
|
69730K
69730-52231 Cable Assy, Side Door Lock Remote Control, No.4[07.2015 -] NSP141 |
69730-52231 |
US $18.93 |
||
|
69730L
|
69730L
69730-52240 Cable Assy, Side Door Lock Remote Control, No.5[07.2015 -] NSP141 |
69730-52240 |
US $15.72 |
||
|
69736A
|
69736A
69736-52010 Guide, Front Door Lock Link[07.2015 -] NSP141 |
69736-52010 |
US $6.56 |
||
|
91621J0614
|
91621J0614
91621-J0614 BOLT W-WASHER |
91621-J0614 |
US $1.76 |
||
|
5852252020
|
5852252020
58522-52020 Hook, Male, No.3 |
58522-52020 |
US $4.64 |
||
|
6929648010
|
6929648010
69296-48010 Screw, Door Inside Handle |
69296-48010 |
US $2.40 |
||
|
8561828010
|
8561828010
85618-28010 New Genuine Part |
85618-28010 |
US $2.08 |
||
|
9010508474
|
9010508474
90105-08474 New Genuine Part |
90105-08474 |
US $1.28 |
||
|
9014860082
|
9014860082
90148-60082 New Genuine Part |
90148-60082 |
US $0.96 |
||
|
9014880040
|
9014880040
90148-80040 Screw Hex Lobular |
90148-80040 |
from US $0.74 |
||
|
9015940202
|
9015940202
90159-40202 SCREW WWASHER |
90159-40202 |
US $0.96 |
||
|
9017905118
|
9017905118
90179-05118 New Genuine Part |
90179-05118 |
US $1.76 |
||
|
9017906274
|
9017906274
90179-06274 Nut |
90179-06274 |
from US $0.74 |
||
|
9017910186
|
9017910186
90179-10186 New Genuine Part |
90179-10186 |
US $1.28 |
||
|
9038608066
|
9038608066
90386-08066 Bush(For Rear Door Outside Handle) |
90386-08066 |
US $2.24 |
||
|
9095901626
|
9095901626
90959-01626 New Genuine Part |
90959-01626 |
US $2.40 |
||
|
9155180610
|
9155180610
91551-80610 BOLT FLANGE |
91551-80610 |
US $0.96 |
||
|
9155380612
|
9155380612
91553-80612 BOLT FLANGE |
91553-80612 |
from US $0.72 |
