Clutch Pedal & Flexible Hose ([05.1995 - ] (9505- )MTM) Diagram Toyota SPRINTER/ CARIB/ TRUENO
- Year
- 1997 - 2000
- Sales region
- Japan
- Frame
- AE111
- grade
- GT
- body
- SED
- ENGINE
- 4AGE
- TRANSMISSION
- MTM
- Model
- SPRINTER
- From
- 04.1997
- To
- 08.2000
- Gear Shift Type
- 6F
- Vehicle Model
- SPRINTER
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
31301
|
31301
31301-12420
Pedal Sub-Assy, Clutch
[04.1997 - 08.2000] AE11#,CE11#,EE111..MTM |
31301-12420 |
— | ||
|
31301A
|
31301A
90506-14063 Spring(For Clutch Pedal)[04.1997 - 08.2000] AE11#,CE11#,EE111..MTM |
90506-14063 |
US $2.62 |
||
|
31301B
|
31301B
90541-06036 Cushion, No.1(For Clutch Pedal)[04.1997 - 08.2000] AE11#,CE11#,EE111..MTM |
90541-06036 |
from US $0.94 |
||
| replacement | |||||
|
31301B
|
31301B
90541060361
CUSHION
[04.1997 - 08.2000] AE11#,CE11#,EE111..MTM |
90541060361 |
— | ||
|
31301C
|
31301C
90386-13015 Bush(For Clutch Pedal)[04.1997 - 08.2000] AE11#,CE11#,EE111..MTM |
90386-13015 |
from US $0.64 |
||
|
31301F
|
31301F
90101-10369 Bolt(For Clutch Pedal Stopper)[04.1997 - 08.2000] AE11#,CE11#,EE111..MTM |
90101-10369 |
from US $1.31 |
||
|
31301J
|
31301J
94120-41000 Nut(For Clutch Pedal Stopper)[04.1997 - 08.2000] AE11#,CE11#,EE111..MTM |
94120-41000 |
from US $0.76 |
||
| replacement | |||||
|
31301J
|
31301J
90170-A0002 Nut[04.1997 - 08.2000] AE11#,CE11#,EE111..MTM |
90170-A0002 |
US $2.33 |
||
|
31321
|
31321
31321-12040 Pad, Clutch Pedal[04.1997 - 08.2000] AE11#,CE11#,EE111..MTM |
31321-12040 |
from US $4.21 |
||
|
31324
|
31324
90101-10015 Shaft, Clutch Pedal[04.1997 - 08.2000] AE11#,CE11#,EE111..MTM |
90101-10015 |
from US $1.07 |
||
| replacement | |||||
|
31324
|
31324
90101100151
Bolt, Hexagon
[04.1997 - 08.2000] AE11#,CE11#,EE111..MTM |
90101100151 |
— | ||
|
31324A
|
31324A
90387-10003 Collar, Clutch Pedal Shaft[04.1997 - 08.2000] AE11#,CE11#,EE111..MTM |
90387-10003 |
from US $3.94 |
||
|
31453A
|
31453A
47148-12030 Pin, W/hole(For Clutch Master Cylinder Push Rod Clevis)[04.1997 - 08.2000] AE11#,CE11#,EE111..MTM 長さ＝３０．０ |
47148-12030 |
US $3.86 |
||
|
31453B
|
31453B
90386-08002 Bush(For Clutch Pedal Over Center Spring Pin)[04.1997 - 08.2000] AE11#,CE11#,EE111..MTM |
90386-08002 |
from US $3.22 |
||
|
55107A
|
55107A
55107-12170
Support Sub-Assy, Clutch Pedal
[04.1997 - 08.2000] AE11#,CE11#,EE111..MTM |
55107-12170 |
— | ||
|
9046816142
|
9046816142
90468-16142 Clip(For Push Rod Clevis Pin) |
90468-16142 |
from US $0.82 |
||
|
9165160816
|
9165160816
91651-60816 BOLT |
91651-60816 |
from US $1.01 |
||
| replacement | |||||
|
9165160816
|
9165160816
90080-11396 BOLT |
90080-11396 |
US $3.32 |
||
|
9411051000
|
9411051000
94110-51000 Nut(For Steering Center Arm) |
94110-51000 |
from US $0.76 |
||
|
9451201000
|
9451201000
94512-01000 Washer, No.1 (For Propeller Shaft & Differential Setting) |
94512-01000 |
from US $0.80 |
||
