Front Axle Housing & Differential ([05.1995 - ] C40,C50,C51,C160 (9505- )AE110,111,EE111..MTM) Diagram Toyota SPRINTER/ CARIB/ TRUENO
- Year
- 1997 - 2000
- Sales region
- Japan
- Frame
- AE111
- grade
- GT
- body
- SED
- ENGINE
- 4AGE
- TRANSMISSION
- MTM
- Model
- SPRINTER
- From
- 04.1997
- To
- 08.2000
- Gear Shift Type
- 6F
- Vehicle Model
- SPRINTER
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
31105A
|
31105A
90331-08002 Plug, Tight(For Front Transaxle Case)[04.1997 - 08.2000] AE110,111,EE111..MTM |
90331-08002 |
US $1.46 |
||
|
31105D
|
31105D
90311-25011
Seal, Oil, No.1(For Front Transaxle Case)
[04.1997 - 08.2000] AE111..6F |
90311-25011 |
— | ||
| replacement | |||||
|
31105D
|
31105D
90311-25028 Seal, Oil, No.1(For Front Transaxle Case)[04.1997 - 08.2000] AE111..6F |
90311-25028 |
from US $4.84 |
||
|
31115C
|
31115C
31115-16042
Case, Front Transaxle(Mtm)
[04.1997 - 08.2000] AE110,111..MTM |
31115-16042 |
— | ||
|
33449
|
33449
33449-12020 Magnet, Transmission[04.1997 - 08.2000] AE110,111,EE111..MTM |
33449-12020 |
US $8.91 |
||
|
33481
|
33481
33481-12040 Gear, Speedometer Drive (Mtm)[04.1997 - 08.2000] AE110,111,EE111..MTM 歯数＝３５，マーク ３５Ｘ２９−３１ |
33481-12040 |
from US $6.99 |
||
|
41221
|
41221
41221-12380
Gear, Front Differential Ring
[04.1997 - 08.2000] AE111..6F |
41221-12380 |
— | ||
| replacement | |||||
|
41221
|
41221
41221-12500 Gear, Front Differential Ring[04.1997 - 08.2000] AE111..6F |
41221-12500 |
US $164.24 |
||
|
41222B
|
41222B
90105-11040 Bolt (For Rear Differential Ring Gear Set)[04.1997 - 08.2000] AE110,111,CE110,113,EE111..MTM |
90105-11040 |
US $2.33 |
||
|
41311
|
41311
41301-12041 Case, Front Differential[04.1997 - 08.2000] AE110,111,EE111..MTM |
41301-12041 |
US $291.20 |
||
|
41311E
|
41311E
90366-38004 Bearing(For Counter Driven Gear)[04.1997 - 05.1998] AE110,111,EE111..MTM |
90366-38004 |
from US $33.17 |
||
|
41311F
|
41311F
90368-38010 Bearing(For Rear Differential Case)[04.1997 - 08.2000] AE111..6F;AE110,EE111..4F,4FC,5F |
90368-38010 |
from US $28.06 |
||
|
41311G
|
41311G
90201-41012 Washer, Plate (For Front Differential Case Front)[04.1997 - 05.1998] AE110,111,EE111..3FC,4F,5F,6F 厚さ＝２．１０ |
90201-41012 |
US $5.39 |
||
|
41311G
|
41311G
90560-41003 Shim(For Rear Differential Case)[08.1999 - 08.2000] AE111..6F 厚さ＝２．１ |
90560-41003 |
US $4.30 |
||
|
41311H
|
41311H
90201-41046 Washer, Plate (For Front Differential Case Rear)[04.1997 - 08.1999] AE110,111,EE111..MTM 厚さ＝２．１０，マーク Ａ |
90201-41046 |
US $5.39 |
||
| replacement | |||||
|
41311H
|
41311H
90564-41014 Washer, Plate (For Front Differential Case Rear)[04.1997 - 08.1999] AE110,111,EE111..MTM 厚さ＝２．１０，マーク Ａ |
90564-41014 |
US $3.14 |
||
|
41311H
|
41311H
90201-41047 Washer, Plate (For Front Differential Case Rear)[04.1997 - 08.1999] AE110,111,EE111..MTM 厚さ＝２．１５，マーク Ｂ |
90201-41047 |
US $5.39 |
||
| replacement | |||||
|
41311H
|
41311H
90564-41015 Washer, Plate (For Front Differential Case Rear)[04.1997 - 08.1999] AE110,111,EE111..MTM 厚さ＝２．１５，マーク Ｂ |
90564-41015 |
US $3.14 |
||
|
41311H
|
41311H
90201-41048 Washer, Plate (For Front Differential Case Rear)[04.1997 - 08.1999] AE110,111,EE111..MTM 厚さ＝２．２０，マーク Ｃ |
90201-41048 |
US $5.39 |
||
| replacement | |||||
|
41311H
|
41311H
90564-41016 Washer, Plate (For Front Differential Case Rear)[04.1997 - 08.1999] AE110,111,EE111..MTM 厚さ＝２．２０，マーク Ｃ |
90564-41016 |
US $3.14 |
||
|
41311H
|
41311H
90201-41049
Washer, Plate (For Front Differential Case Rear)
[04.1997 - 08.1999] AE110,111,EE111..MTM 厚さ＝２．２５，マーク Ｄ |
90201-41049 |
— | ||
| replacement | |||||
|
41311H
|
41311H
90564-41017 Washer, Plate (For Front Differential Case Rear)[04.1997 - 08.1999] AE110,111,EE111..MTM 厚さ＝２．２５，マーク Ｄ |
90564-41017 |
US $3.32 |
||
|
41311H
|
41311H
90201-41050
Washer, Plate (For Front Differential Case Rear)
[04.1997 - 08.1999] AE110,111,EE111..MTM 厚さ＝２．３０，マーク Ｅ |
90201-41050 |
— | ||
| replacement | |||||
|
41311H
|
41311H
90564-41018 Washer, Plate (For Front Differential Case Rear)[04.1997 - 08.1999] AE110,111,EE111..MTM 厚さ＝２．３０，マーク Ｅ |
90564-41018 |
US $4.54 |
||
|
41311H
|
41311H
90201-41051
Washer, Plate (For Front Differential Case Rear)
[04.1997 - 08.1999] AE110,111,EE111..MTM 厚さ＝２．３５，マーク Ｆ |
90201-41051 |
— | ||
| replacement | |||||
|
41311H
|
41311H
90564-41019 Washer, Plate (For Front Differential Case Rear)[04.1997 - 08.1999] AE110,111,EE111..MTM 厚さ＝２．３５，マーク Ｆ |
90564-41019 |
US $5.73 |
||
|
41311H
|
41311H
90201-41052 Washer, Plate (For Front Differential Case Rear)[04.1997 - 08.1999] AE110,111,EE111..MTM 厚さ＝２．４０，マーク Ｇ |
90201-41052 |
US $6.99 |
||
| replacement | |||||
|
41311H
|
41311H
90564-41020 Washer, Plate (For Front Differential Case Rear)[04.1997 - 08.1999] AE110,111,EE111..MTM 厚さ＝２．４０，マーク Ｇ |
90564-41020 |
US $4.54 |
||
|
41311H
|
41311H
90201-41053 Washer, Plate (For Front Differential Case Rear)[04.1997 - 08.1999] AE110,111,EE111..MTM 厚さ＝２．４５，マーク Ｈ |
90201-41053 |
US $6.99 |
||
| replacement | |||||
|
41311H
|
41311H
90564-41021 Washer, Plate (For Front Differential Case Rear)[04.1997 - 08.1999] AE110,111,EE111..MTM 厚さ＝２．４５，マーク Ｈ |
90564-41021 |
US $4.54 |
||
|
41311H
|
41311H
90201-41054 Washer, Plate (For Front Differential Case Rear)[04.1997 - 08.1999] AE110,111,EE111..MTM 厚さ＝２．５０，マーク Ｊ |
90201-41054 |
US $6.99 |
||
| replacement | |||||
|
41311H
|
41311H
90564-41022 Washer, Plate (For Front Differential Case Rear)[04.1997 - 08.1999] AE110,111,EE111..MTM 厚さ＝２．５０，マーク Ｊ |
90564-41022 |
US $4.54 |
||
|
41311H
|
41311H
90201-41055 Washer, Plate (For Front Differential Case Rear)[04.1997 - 08.1999] AE110,111,EE111..MTM 厚さ＝２．５５，マーク Ｋ |
90201-41055 |
US $6.99 |
||
| replacement | |||||
|
41311H
|
41311H
90564-41023 Washer, Plate (For Front Differential Case Rear)[04.1997 - 08.1999] AE110,111,EE111..MTM 厚さ＝２．５５，マーク Ｋ |
90564-41023 |
US $4.54 |
||
|
41311H
|
41311H
90201-41056 Washer, Plate (For Front Differential Case Rear)[04.1997 - 08.1999] AE110,111,EE111..MTM 厚さ＝２．６０，マーク Ｌ |
90201-41056 |
US $6.99 |
||
| replacement | |||||
|
41311H
|
41311H
90564-41024 Washer, Plate (For Front Differential Case Rear)[04.1997 - 08.1999] AE110,111,EE111..MTM 厚さ＝２．６０，マーク Ｌ |
90564-41024 |
US $4.22 |
||
|
41311H
|
41311H
90201-41057 Washer, Plate (For Front Differential Case Rear)[04.1997 - 08.1999] AE110,111,EE111..MTM 厚さ＝２．６５，マーク Ｍ |
90201-41057 |
US $6.99 |
||
| replacement | |||||
|
41311H
|
41311H
90564-41025 Washer, Plate (For Front Differential Case Rear)[04.1997 - 08.1999] AE110,111,EE111..MTM 厚さ＝２．６５，マーク Ｍ |
90564-41025 |
US $4.22 |
||
|
41311H
|
41311H
90201-41058 Washer, Plate (For Front Differential Case Rear)[04.1997 - 08.1999] AE110,111,EE111..MTM 厚さ＝２．７０，マーク Ｎ |
90201-41058 |
US $6.99 |
||
| replacement | |||||
|
41311H
|
41311H
90564-41026 Washer, Plate (For Front Differential Case Rear)[04.1997 - 08.1999] AE110,111,EE111..MTM 厚さ＝２．７０，マーク Ｎ |
90564-41026 |
US $4.22 |
||
|
41311H
|
41311H
90201-41059 Washer, Plate (For Front Differential Case Rear)[04.1997 - 08.1999] AE110,111,EE111..MTM 厚さ＝２．７５，マーク Ｐ |
90201-41059 |
US $6.99 |
||
| replacement | |||||
|
41311H
|
41311H
90564-41027 Washer, Plate (For Front Differential Case Rear)[04.1997 - 08.1999] AE110,111,EE111..MTM 厚さ＝２．７５，マーク Ｐ |
90564-41027 |
US $4.22 |
||
|
41311H
|
41311H
90201-41060 Washer, Plate (For Front Differential Case Rear)[04.1997 - 08.1999] AE110,111,EE111..MTM 厚さ＝２．８０，マーク Ｑ |
90201-41060 |
US $6.99 |
||
| replacement | |||||
|
41311H
|
41311H
90564-41028 Washer, Plate (For Front Differential Case Rear)[04.1997 - 08.1999] AE110,111,EE111..MTM 厚さ＝２．８０，マーク Ｑ |
90564-41028 |
US $4.22 |
||
|
41311H
|
41311H
90201-41061 Washer, Plate (For Front Differential Case Rear)[04.1997 - 08.1999] AE110,111,EE111..MTM 厚さ＝２．８５，マーク Ｒ |
90201-41061 |
US $8.15 |
||
| replacement | |||||
|
41311H
|
41311H
90564-41029 Washer, Plate (For Front Differential Case Rear)[04.1997 - 08.1999] AE110,111,EE111..MTM 厚さ＝２．８５，マーク Ｒ |
90564-41029 |
US $4.95 |
||
|
41311H
|
41311H
90201-41062 Washer, Plate (For Front Differential Case Rear)[04.1997 - 08.1999] AE110,111,EE111..MTM 厚さ＝２．９０，マーク Ｓ |
90201-41062 |
US $8.15 |
||
| replacement | |||||
|
41311H
|
41311H
90564-41030 Washer, Plate (For Front Differential Case Rear)[04.1997 - 08.1999] AE110,111,EE111..MTM 厚さ＝２．９０，マーク Ｓ |
90564-41030 |
US $4.95 |
||
|
41311H
|
41311H
90201-41063 Washer, Plate (For Front Differential Case Rear)[04.1997 - 08.1999] AE110,111,EE111..MTM 厚さ＝２．９５，マーク Ｔ |
90201-41063 |
US $8.15 |
||
| replacement | |||||
|
41311H
|
41311H
90564-41031 Washer, Plate (For Front Differential Case Rear)[04.1997 - 08.1999] AE110,111,EE111..MTM 厚さ＝２．９５，マーク Ｔ |
90564-41031 |
US $4.95 |
||
|
41311H
|
41311H
90201-41064 Washer, Plate (For Front Differential Case Rear)[04.1997 - 08.1999] AE110,111,EE111..MTM 厚さ＝３．００，マーク Ｕ |
90201-41064 |
US $8.15 |
||
| replacement | |||||
|
41311H
|
41311H
90564-41032 Washer, Plate (For Front Differential Case Rear)[04.1997 - 08.1999] AE110,111,EE111..MTM 厚さ＝３．００，マーク Ｕ |
90564-41032 |
US $4.95 |
||
|
41311H
|
41311H
90564-41014 Washer, Plate (For Front Differential Case Rear)[08.1999 - 08.2000] AE110,111,EE111..MTM 厚さ＝２．１０，マーク ＡＡ |
90564-41014 |
US $3.14 |
||
|
41311H
|
41311H
90564-41015 Washer, Plate (For Front Differential Case Rear)[08.1999 - 08.2000] AE110,111,EE111..MTM 厚さ＝２．１５，マーク ＢＢ |
90564-41015 |
US $3.14 |
||
|
41311H
|
41311H
90564-41016 Washer, Plate (For Front Differential Case Rear)[08.1999 - 08.2000] AE110,111,EE111..MTM 厚さ＝２．２０，マーク ＣＣ |
90564-41016 |
US $3.14 |
||
|
41311H
|
41311H
90564-41017 Washer, Plate (For Front Differential Case Rear)[08.1999 - 08.2000] AE110,111,EE111..MTM 厚さ＝２．２５，マーク ＤＤ |
90564-41017 |
US $3.32 |
||
|
41311H
|
41311H
90564-41018 Washer, Plate (For Front Differential Case Rear)[08.1999 - 08.2000] AE110,111,EE111..MTM 厚さ＝２．３０，マーク ＥＥ |
90564-41018 |
US $4.54 |
||
|
41311H
|
41311H
90564-41019 Washer, Plate (For Front Differential Case Rear)[08.1999 - 08.2000] AE110,111,EE111..MTM 厚さ＝２．３５，マーク ＦＦ |
90564-41019 |
US $5.73 |
||
|
41311H
|
41311H
90564-41020 Washer, Plate (For Front Differential Case Rear)[08.1999 - 08.2000] AE110,111,EE111..MTM 厚さ＝２．４０，マーク ＧＧ |
90564-41020 |
US $4.54 |
||
|
41311H
|
41311H
90564-41021 Washer, Plate (For Front Differential Case Rear)[08.1999 - 08.2000] AE110,111,EE111..MTM 厚さ＝２．４５，マーク ＨＨ |
90564-41021 |
US $4.54 |
||
|
41311H
|
41311H
90564-41022 Washer, Plate (For Front Differential Case Rear)[08.1999 - 08.2000] AE110,111,EE111..MTM 厚さ＝２．５０，マーク ＪＪ |
90564-41022 |
US $4.54 |
||
|
41311H
|
41311H
90564-41023 Washer, Plate (For Front Differential Case Rear)[08.1999 - 08.2000] AE110,111,EE111..MTM 厚さ＝２．５５，マーク ＫＫ |
90564-41023 |
US $4.54 |
||
|
41311H
|
41311H
90564-41024 Washer, Plate (For Front Differential Case Rear)[08.1999 - 08.2000] AE110,111,EE111..MTM 厚さ＝２．６０，マーク ＬＬ |
90564-41024 |
US $4.22 |
||
|
41311H
|
41311H
90564-41025 Washer, Plate (For Front Differential Case Rear)[08.1999 - 08.2000] AE110,111,EE111..MTM 厚さ＝２．６５，マーク ＭＭ |
90564-41025 |
US $4.22 |
||
|
41311H
|
41311H
90564-41026 Washer, Plate (For Front Differential Case Rear)[08.1999 - 08.2000] AE110,111,EE111..MTM 厚さ＝２．７０，マーク ＮＮ |
90564-41026 |
US $4.22 |
||
|
41311H
|
41311H
90564-41027 Washer, Plate (For Front Differential Case Rear)[08.1999 - 08.2000] AE110,111,EE111..MTM 厚さ＝２．７５，マーク ＰＰ |
90564-41027 |
US $4.22 |
||
|
41311H
|
41311H
90564-41028 Washer, Plate (For Front Differential Case Rear)[08.1999 - 08.2000] AE110,111,EE111..MTM 厚さ＝２．８０，マーク ＱＱ |
90564-41028 |
US $4.22 |
||
|
41311H
|
41311H
90564-41029 Washer, Plate (For Front Differential Case Rear)[08.1999 - 08.2000] AE110,111,EE111..MTM 厚さ＝２．８５，マーク ＲＲ |
90564-41029 |
US $4.95 |
||
|
41311H
|
41311H
90564-41030 Washer, Plate (For Front Differential Case Rear)[08.1999 - 08.2000] AE110,111,EE111..MTM 厚さ＝２．９０，マーク ＳＳ |
90564-41030 |
US $4.95 |
||
|
41311H
|
41311H
90564-41031 Washer, Plate (For Front Differential Case Rear)[08.1999 - 08.2000] AE110,111,EE111..MTM 厚さ＝２．９５，マーク ＴＴ |
90564-41031 |
US $4.95 |
||
|
41311H
|
41311H
90564-41032 Washer, Plate (For Front Differential Case Rear)[08.1999 - 08.2000] AE110,111,EE111..MTM 厚さ＝３．００，マーク ＵＵ |
90564-41032 |
US $4.95 |
||
|
41331F
|
41331F
41331-12011 Gear, Rear Differential Side[04.1997 - 08.2000] AE110,111,EE111 |
41331-12011 |
from US $32.15 |
||
|
41341F
|
41341F
41341-12030 Pinion, Rear Differential[04.1997 - 08.2000] AE110,111,EE111 |
41341-12030 |
US $23.06 |
||
|
41342A
|
41342A
90250-06058 Pin, Straight(For Timing Gear Case)[04.1997 - 08.2000] AE110,111,CE110,113,EE111 |
90250-06058 |
from US $1.87 |
||
|
41342F
|
41342F
41342-12140 Shaft, Front Differential Pinion, No.1[04.1997 - 08.2000] AE111..6F;AE110,EE111 |
41342-12140 |
US $15.24 |
||
|
41351F
|
41351F
41351-12020 Washer, Rear Differential Pinion Thrust[04.1997 - 08.2000] AE110,111,EE111 |
41351-12020 |
from US $1.41 |
||
|
41361F
|
41361F
41361-22020 Washer, Rear Differential Side Gear Thrust, No.1[04.1997 - 08.1997] AE110,111,CE110,EE111..3FC,4F,5F,6F 厚さ＝１．００，マーク ０２ |
41361-22020 |
US $2.80 |
||
|
41361F
|
41361F
41361-22030 Washer, Rear Differential Side Gear Thrust, No.1[04.1997 - 08.1997] AE110,111,CE110,EE111..3FC,4F,5F,6F 厚さ＝１．１０，マーク ０３ |
41361-22030 |
US $2.80 |
||
|
41361F
|
41361F
41361-22040 Washer, Rear Differential Side Gear Thrust, No.1[04.1997 - 08.1997] AE110,111,CE110,EE111..3FC,4F,5F,6F 厚さ＝１．２０，マーク ０４ |
41361-22040 |
from US $3.92 |
||
|
41361F
|
41361F
41361-22140 Washer, Rear Differential Side Gear Thrust, No.1[04.1997 - 08.1997] AE110,111,CE110,EE111..3FC,4F,5F,6F 厚さ＝０．９５，マーク １４ |
41361-22140 |
US $2.53 |
||
|
41361F
|
41361F
41361-22150 Washer, Rear Differential Side Gear Thrust, No.1[04.1997 - 08.1997] AE110,111,CE110,EE111..3FC,4F,5F,6F 厚さ＝１．０５，マーク １５ |
41361-22150 |
US $2.62 |
||
|
41361F
|
41361F
41361-22160 Washer, Rear Differential Side Gear Thrust, No.1[04.1997 - 08.1997] AE110,111,CE110,EE111..3FC,4F,5F,6F 厚さ＝１．１５，マーク １６ |
41361-22160 |
US $2.62 |
||
