Brake Pedal & Bracket ([01.1996 - ] (9601- )) Diagram Toyota STARLET
- Year
- 1996 - 1999
- Sales region
- General
- Frame
- EP90
- ENGINE
- 2E
- TRANSMISSION
- ATM
- From
- 01.1996
- To
- 07.1999
- Gear Shift Type
- 3FC
- No.of Doors
- 5D
- Vehicle Model
- STARLET
- Driver's Position
- RHD
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
47101
|
47101
47101-10260 Pedal Sub-Assy, Brake[12.1997 -] EP9#..RHD..3FC |
47101-10260 |
US $37.56 |
||
| replacement | |||||
|
47101
|
47101
47101-16220 Pedal Sub-Assy, Brake[12.1997 -] EP9#..RHD..3FC |
47101-16220 |
US $37.56 |
||
|
47101
|
47101
47101-16180 Pedal Sub-Assy, Brake[01.1996 - 12.1997] EP9#..RHD..3FC |
47101-16180 |
US $34.51 |
||
|
47101A
|
47101A
90507-14038 Spring(For Brake Pedal Return)[01.1996 -] EP9# |
90507-14038 |
US $3.49 |
||
|
47101B
|
47101B
90386-13015 Bush(For Clutch Pedal)[01.1996 -] EP9# |
90386-13015 |
from US $0.64 |
||
|
47121
|
47121
47121-12020 Pad, Brake Pedal[01.1996 -] EP9#..3FC |
47121-12020 |
from US $4.91 |
||
|
47124
|
47124
90101-10015 Shaft, Clutch Pedal[01.1996 -] EP9# |
90101-10015 |
from US $1.07 |
||
| replacement | |||||
|
47124
|
47124
90101100151
Bolt, Hexagon
[01.1996 -] EP9# |
90101100151 |
— | ||
|
47124A
|
47124A
90387-10003 Collar, Clutch Pedal Shaft[01.1996 -] EP9# |
90387-10003 |
from US $3.94 |
||
|
47131
|
47131
90541-06036 Cushion, No.1(For Clutch Pedal)[01.1996 -] EP9# |
90541-06036 |
from US $0.94 |
||
| replacement | |||||
|
47131
|
47131
90541060361
CUSHION
[01.1996 -] EP9# |
90541060361 |
— | ||
|
47264A
|
47264A
90249-08051 Pin, W/hole(For Clutch Master Cylinder Push Rod Clevis)[01.1996 -] EP9# |
90249-08051 |
US $3.05 |
||
|
55106
|
55106
55106-10240 Support Sub-Assy, Brake Pedal[12.1997 -] EP9#..RHD |
55106-10240 |
US $53.87 |
||
|
55106
|
55106
55106-16150 Support Sub-Assy, Brake Pedal[01.1996 - 12.1997] EP9#..RHD |
55106-16150 |
US $45.43 |
||
|
9046816142
|
9046816142
90468-16142 Clip(For Push Rod Clevis Pin) |
90468-16142 |
from US $0.82 |
||
|
9162660820
|
9162660820
91626-60820 BOLT WWASHER |
91626-60820 |
US $1.75 |
||
| replacement | |||||
|
9162660820
|
9162660820
91621-B0816 BOLT WWASHER |
91621-B0816 |
from US $0.84 |
||
|
9165160816
|
9165160816
91651-60816 BOLT |
91651-60816 |
from US $1.01 |
||
| replacement | |||||
|
9165160816
|
9165160816
90080-11396 BOLT |
90080-11396 |
US $3.32 |
||
|
9411051000
|
9411051000
94110-51000 Nut(For Steering Center Arm) |
94110-51000 |
from US $0.76 |
||
|
9451201000
|
9451201000
94512-01000 Washer, No.1 (For Propeller Shaft & Differential Setting) |
94512-01000 |
from US $0.80 |
||
